UT196 UNI-T
Hersteller: UNI-TCategory: PV and EVSE Testers and Meters
Description: Meter: digital multimeter; VAC accuracy: ±(0.8%+3digit); IP65
Type of meter: digital multimeter
Kind of display used: LCD
Display parameters: (5999)
Illumination: yes
True effective value measurement: True RMS
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1.7kV
DC voltage measuring accuracy: ±(0.2% + 5 digit)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 1.5kV
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Resistance measuring accuracy: ±(0.8%+2 digit)
Capacitance measuring range: 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF
Capacitance measuring accuracy: ±(1.9%+ 5 digit)
Frequency measuring range: 60Hz...1MHz
Frequency measuring accuracy: ±(0.08%+4 digit)
Diode test: 3V
Test: diodes
Continuity test: acoustic indication; <10Ω
Measurement: AC voltage; capacitance; DC voltage; frequency; resistance
Measuring instrument features: automatic power-off; autoranging; built-in torch; contactless voltage detector; HOLD function; low-pass filter; MIN/MAX/REL function
Dimensions (W x H x D): 195x95x58mm
Pollution degree: 2
Power supply: battery 6F22 9V x1
Battery/ rechargeable battery: battery 6F22 9V x1
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Resistance to: fall from 2m height
Measuring instruments application: for solar panels; photovoltaics
IP rating: IP65
Standard equipment: test leads
Bargraph: yes
Operating temperature: 0...40°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 23 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 153.15 EUR |
| 3+ | 144.14 EUR |
