UTD1025DL UNI-T

Category: Portable Oscilloscopes, Scopemeters, Description: Handheld oscilloscope; 25MHz; LCD TFT 3,5"; Ch: 2; 250Msps; 12kpts, Kind of display used: LCD TFT 3,5", Power supply: mains power supply; rechargeable battery Li-Ion 7,4V 3600mAh x1, Measuring instrument features: automatic measurement of many parameters, Standard equipment: current shunt; mains adapter; mains cable; test leads; test probe x1; USB cable, Interface: USB mini, Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 3600mAh x1, Display resolution: 320x240, Trigger: falling-edge; impulse width; rising-edge; slope; video signal, Type of oscilloscope: handheld oscilloscope, DC voltage measuring range: 400mV; 4V; 40V; 400V, AC voltage measuring range: 400mV; 4V; 40V; 400V, Time base: 10n...50s/div, Rise time: ≤14ns, Capacitance measuring range: 51.2nF; 512nF; 5.12µF; 51.2µF; 100µF, AC current measuring range: 0.4mA; 4mA; 40mA; 4A, DC current measuring range: 0.4mA; 4mA; 40mA; 4A, Resistance measuring range: 0.4kΩ; 4kΩ; 40kΩ; 400kΩ; 4MΩ; 40MΩ, Input sensitivity: 5mV/div...20V/div, DC voltage measuring accuracy: ±(1.2% + 5 digit), Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(40MΩ), AC voltage measuring accuracy: ±(1.2% + 5 digit), Dimensions: 199x118x49mm, Number of channels: 2, Capacitance measuring accuracy: ±(3%+ 5 digit), Memory record length: 12kpts, Band: 25MHz, Sampling: 250Msps, Display parameters: (3999), Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance, Anzahl je Verpackung: 1 Stücke.
