MF60101V2-1000U-A99 SUNON
Hersteller: SUNONCategory: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x10mm; 24.17m3/h; 25dBA; Vapo; 3500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x10mm
Power consumption: 0.9W
Current rating: 75mA
Fan efficiency: 24.17m3/h
Noise level: 25dBA
Kind of Bearing: Vapo
Rotational rate/speed: 3500rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.29m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 2.54mm H2O
Wire size: 26AWG
auf Bestellung 1685 Stücke:
Lieferzeit 14-21 Tag (e)
| Anzahl | Preis |
|---|---|
| 16+ | 4.58 EUR |
| 50+ | 3.52 EUR |
| 100+ | 3.25 EUR |
| 200+ | 3.16 EUR |
