VZAB0P2BAA YASKAWA

Category: One Phase Inverters, Description: Inverter; Max motor power: 0.25kW; Usup: 200÷240VAC; 0.1÷400Hz, Type of module: Inverter, Max motor power: 0.25kW, Supply voltage: 200...240V AC, Inverter output voltage: 3 x 230V AC, Input 1 properties: 2 inputs for setting motor rotational speed by signals 0...10V, 4...20mA, 0...20mA, The programming method: keypad, Electrical connection: screw terminals, Additional functions: 17 step speed regulation; disturbance filter; programmable digital inputs x6; programmable input digital x1; programmable output analogue x1; programmable relay output NO + NC; RS485/422 (max 115kB/s); safety input x2; three-phase power supply, Protection: anti-overload OPP; anti-overvoltage OVP; motor blockade; overheating OTP; short circuit protection SCP; voltage drop BOP, Mounting: for wall mounting, Operating temperature: -10...40°C, Output frequency: 0.1...400Hz, Number of inputs: 11, Number of analog inputs: 2, Starting/stopping time: 0.01...6000/0.01...6000s, Kind of display used: LED, Current consumption: 1.6A, Digitally/analogously set output frequency accuracy: 0.01/0.1%, Manufacturer series: V1000, Voltage output: 0...10V.
