Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
RM84-2012-35-1048 RM84-2012-35-1048 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 48VDC; 8A; 8A/250VAC; 8A/24VDC
Contact material: AgNi
Manufacturer series: RM84
Contacts configuration: DPDT
Type of relay: electromagnetic
Mounting: PCB
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
IP rating: IP67
Relay variant: miniature
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Height: 15.7mm
DC contacts rating @R: 8A / 24V DC
Contact resistance: 100mΩ
Coil power consumption: 480mW
Number of pins: 8
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
Coil voltage min.: 33.6V DC
Rated coil voltage: 48V DC
Coil voltage max.: 122.4V DC
Switched voltage: max. 250V DC; max. 440V AC
Coil resistance: 5.7kΩ
Mechanical durability: 30000000 cycles
OEM number: 600337
Anzahl je Verpackung: 1 Stücke
auf Bestellung 737 Stücke:
Lieferzeit 7-14 Tag (e)
21+3.55 EUR
24+3.1 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 21
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1060 RM84-2012-35-1060 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 60VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600338
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 42V DC
Rated coil voltage: 60V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 153V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 7.5kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 478 Stücke:
Lieferzeit 7-14 Tag (e)
20+3.65 EUR
22+3.29 EUR
30+2.39 EUR
32+2.26 EUR
100+2.23 EUR
500+2.17 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1110 RELPOL 8A; 110V; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-1110 miniature relay P RM84p110-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 40 Stücke:
Lieferzeit 7-14 Tag (e)
20+13.08 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1110 RM84-2012-35-1110 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 110VDC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 110V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 25.2kΩ
Coil voltage min.: 77V DC
Coil voltage max.: 280V DC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 480mW
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Body colour: white
OEM number: 600339
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1529 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.76 EUR
21+3.43 EUR
23+3.25 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5012 RM84-2012-35-5012 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VAC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 852385
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 0.75VA
Coil voltage min.: 9.6V AC
Rated coil voltage: 12V AC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 13.2V AC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 100Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 689 Stücke:
Lieferzeit 7-14 Tag (e)
20+3.58 EUR
22+3.35 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 RM84-2012-35-5024 RELPOL 2366559.pdf Description: RELPOL - RM84-2012-35-5024 - Leistungsrelais, DPDT-2NC / 2NO, 24 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364190
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 400ohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 24VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 74 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 RELPOL 8A; 24VAC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-5024 miniature relay P RM84p024-20wz
Anzahl je Verpackung: 20 Stücke
auf Bestellung 40 Stücke:
Lieferzeit 7-14 Tag (e)
20+7.12 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 RELPOL 8A; 24VAC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-5024 miniature relay P RM84p024-20wz
Anzahl je Verpackung: 20 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
20+7.12 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 RM84-2012-35-5024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VAC; 8A; 8A/250VAC; 8A/24VDC
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 400Ω
Coil voltage min.: 19.2V AC
Coil voltage max.: 28.8V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 0.75VA
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Body colour: white
OEM number: 604615
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1105 Stücke:
Lieferzeit 7-14 Tag (e)
20+3.65 EUR
21+3.42 EUR
41+1.76 EUR
43+1.67 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5048 RM84-2012-35-5048 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 48VAC; 8A; 8A/250VAC; 8A/24VDC
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 48V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.55kΩ
Coil voltage min.: 43.2V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Coil power consumption: 0.75VA
Mechanical durability: 30000000 cycles
Contact resistance: 100mΩ
Coil voltage max.: 52.8V AC
Body colour: white
Anzahl je Verpackung: 1000 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5060 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 60VAC; Icontacts max: 8A; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 60V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 400V AC
Relay variant: miniature
Mounting: PCB; socket
Coil resistance: 2.6kΩ
Coil voltage min.: 48V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...70°C
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Current rating: 8A
Contact resistance: 100mΩ
Coil voltage max.: 72V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5110 RM84-2012-35-5110 RELPOL 2366559.pdf Description: RELPOL - RM84-2012-35-5110 - Leistungsrelais, DPDT-2NC / 2NO, 110 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364900
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 8.9kohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 110VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 8 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5110 RM84-2012-35-5110 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 110VAC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 604618
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 0.75VA
Coil voltage min.: 88V AC
Rated coil voltage: 110V AC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 132V AC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 8.9kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 321 Stücke:
Lieferzeit 7-14 Tag (e)
20+3.65 EUR
22+3.29 EUR
32+2.29 EUR
34+2.16 EUR
500+2.09 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5120 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 120VAC; Icontacts max: 8A
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 120V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 400V AC
Relay variant: miniature
Mounting: PCB; socket
Coil resistance: 10.2kΩ
Coil voltage min.: 96V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...70°C
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Current rating: 8A
Contact resistance: 100mΩ
Coil voltage max.: 144V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 RM84-2012-35-5230 RELPOL 2366559.pdf Description: RELPOL - RM84-2012-35-5230 - Leistungsrelais, DPDT-2NC / 2NO, 230 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364900
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 38.5kohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 230VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 12 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 RELPOL 8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 21 Stücke:
Lieferzeit 7-14 Tag (e)
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 RELPOL 8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 160 Stücke:
Lieferzeit 7-14 Tag (e)
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 RELPOL 8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 15 Stücke:
Lieferzeit 7-14 Tag (e)
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 RM84-2012-35-5230 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 230VAC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 230V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 38.5kΩ
Coil voltage min.: 184V AC
Coil voltage max.: 276V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Coil power consumption: 0.75VA
Body colour: white
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2896 Stücke:
Lieferzeit 7-14 Tag (e)
12+6.31 EUR
16+4.52 EUR
17+4.28 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-1024 RELPOL RM84-2022-25-1024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-1024-01 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; Icontacts max: 8A
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Contacts configuration: DPST-NO
Type of relay: electromagnetic
Manufacturer series: RM84
IP rating: IP40
Relay variant: miniature
Mounting: PCB; socket
Operating temperature: -20...70°C
Release time: 3ms
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Contact current max.: 8A
Current rating: 8A
DC contacts rating @R: 8A / 24V DC
AC contacts rating @R: 8A / 250V AC
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
Switched voltage: max. 400V AC
Coil voltage max.: 61.2V DC
Coil resistance: 1.44kΩ
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-5230 RELPOL RM84-2022-25-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1005 RM84-2022-35-1005 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 5VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600463
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 3.5V DC
Rated coil voltage: 5V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 12.7V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 60Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1199 Stücke:
Lieferzeit 7-14 Tag (e)
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1006 RELPOL RM84-2022-35-1006 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1009 RELPOL RM84-2022-35-1009 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1012 RM84-2022-35-1012 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 12VDC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPST-NO
Rated coil voltage: 12V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Coil voltage min.: 8.4V DC
Coil voltage max.: 30.6V DC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 480mW
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 6
Body colour: white
OEM number: 600466
Anzahl je Verpackung: 1 Stücke
auf Bestellung 278 Stücke:
Lieferzeit 7-14 Tag (e)
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1024 RM84-2022-35-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600468
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 788 Stücke:
Lieferzeit 7-14 Tag (e)
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1048 RELPOL RM84-2022-35-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1060 RELPOL RM84-2022-35-1060 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1110 RELPOL RM84-2022-35-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-1024 RM84-2312-35-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi/Au 5μm
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 201 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.75 EUR
9+8.17 EUR
10+7.72 EUR
500+7.52 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-1110 RELPOL RM84-2312-35-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-5230 RELPOL RM84-2312-35-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1012 RELPOL RM84-3012-25-1012 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1024 RM84-3012-25-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 72 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1024-01 RELPOL RM84301225102401 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1110 RELPOL RM84-3012-25-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-5230 RELPOL RM84-3012-25-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-5230-01 RELPOL RM84301225523001 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1005 RELPOL RM84-3012-35-1005 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1012 RM84-3012-35-1012 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 8.4V DC
Rated coil voltage: 12V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 30.6V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 360Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 481 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024 RELPOL 8A; 24V; DPST; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 3012 35 1024 miniature relay P RM84z024-30w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 4 Stücke:
Lieferzeit 7-14 Tag (e)
20+5.38 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024 RELPOL 8A; 24V; DPST; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 3012 35 1024 miniature relay P RM84z024-30w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 20 Stücke:
Lieferzeit 7-14 Tag (e)
20+5.38 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024 RM84-3012-35-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 944 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1048 RELPOL RM84-3012-35-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1060 RELPOL RM84-3012-35-1060 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-5024 RELPOL RM84-3012-35-5024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-5230 RELPOL RM84-3012-35-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-25-1024 RELPOL RM84-3022-25-1024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-25-1048 RELPOL RM84-3022-25-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-35-1024 RM84-3022-35-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89 Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3859 Stücke:
Lieferzeit 7-14 Tag (e)
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-P-5V (Analogon RM84-2012-35-1005)
+1
 		RM84-P-5V (Analogon RM84-2012-35-1005)
Produktcode: 61907
zu Favoriten hinzufügen Lieblingsprodukt

Relpol RM84.pdf Relais
Relaistyp: Relais
Beschreibung: Тип контактів: DPDT, Uкотушки: 5B; Iкомутації: 8A
Abmessungen: 29x12,7x15,7 mm
Spulenspannung: 5 VDC
Strom max: 8 A
Kontaktkonfiguration: DPDT(2C)
Schaltspannung: 250 VAC; 24 VDC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-1024 RM85-2011-25-1024 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600053
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP40
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 316 Stücke:
Lieferzeit 14-21 Tag (e)
26+2.8 EUR
29+2.53 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-1024-01 RM85-2011-25-1024-01 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V DC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Coil voltage min.: 16.8V DC
Coil voltage max.: 61.2V DC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 480mW
Body colour: transparent
OEM number: 859720
Current rating: 16A
Max surge current: 30A
auf Bestellung 447 Stücke:
Lieferzeit 14-21 Tag (e)
13+5.95 EUR
15+4.79 EUR
16+4.52 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-5024-01 RM85-2011-25-5024-01 RELPOL Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VAC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V AC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 400Ω
Coil voltage min.: 19.2V AC
Coil voltage max.: 28.8V AC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 0.75VA
Body colour: transparent
OEM number: 859814
Current rating: 16A
Max surge current: 30A
auf Bestellung 38 Stücke:
Lieferzeit 14-21 Tag (e)
12+6.29 EUR
15+4.78 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-5230-01 RM85-2011-25-5230-01 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 230VAC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 230V AC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 38.5kΩ
Coil voltage min.: 184V AC
Coil voltage max.: 276V AC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 0.75VA
Body colour: transparent
OEM number: 859721
Current rating: 16A
Max surge current: 30A
auf Bestellung 37 Stücke:
Lieferzeit 14-21 Tag (e)
8+9.57 EUR
10+7.24 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1005 RM85-2011-35-1005 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 16A; RM85
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600017
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 3.5V DC
Rated coil voltage: 5V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 12.7V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 60Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 1959 Stücke:
Lieferzeit 14-21 Tag (e)
33+2.23 EUR
35+2.07 EUR
41+1.76 EUR
43+1.67 EUR
100+1.6 EUR
Mindestbestellmenge: 33
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1009 RM85-2011-35-1009 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 9VDC; Icontacts max: 16A; RM85
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600019
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 6.3V DC
Rated coil voltage: 9V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 22.9V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 200Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 1005 Stücke:
Lieferzeit 14-21 Tag (e)
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1012 RM85-2011-35-1012 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600020
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 8.4V DC
Rated coil voltage: 12V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 360Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 2241 Stücke:
Lieferzeit 14-21 Tag (e)
13+5.55 EUR
19+3.78 EUR
41+1.76 EUR
43+1.67 EUR
100+1.66 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1024 RM85-2011-35-1024 RELPOL pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600021
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 4401 Stücke:
Lieferzeit 14-21 Tag (e)
36+2.03 EUR
39+1.84 EUR
41+1.76 EUR
44+1.63 EUR
100+1.6 EUR
Mindestbestellmenge: 36
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1048 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-1048
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 48VDC; 8A; 8A/250VAC; 8A/24VDC
Contact material: AgNi
Manufacturer series: RM84
Contacts configuration: DPDT
Type of relay: electromagnetic
Mounting: PCB
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
IP rating: IP67
Relay variant: miniature
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Height: 15.7mm
DC contacts rating @R: 8A / 24V DC
Contact resistance: 100mΩ
Coil power consumption: 480mW
Number of pins: 8
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
Coil voltage min.: 33.6V DC
Rated coil voltage: 48V DC
Coil voltage max.: 122.4V DC
Switched voltage: max. 250V DC; max. 440V AC
Coil resistance: 5.7kΩ
Mechanical durability: 30000000 cycles
OEM number: 600337
Anzahl je Verpackung: 1 Stücke
auf Bestellung 737 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
21+3.55 EUR
24+3.1 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 21
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1060 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-1060
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 60VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600338
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 42V DC
Rated coil voltage: 60V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 153V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 7.5kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 478 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+3.65 EUR
22+3.29 EUR
30+2.39 EUR
32+2.26 EUR
100+2.23 EUR
500+2.17 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1110
Hersteller: RELPOL
8A; 110V; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-1110 miniature relay P RM84p110-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 40 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+13.08 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-1110 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-1110
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 110VDC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 110V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 25.2kΩ
Coil voltage min.: 77V DC
Coil voltage max.: 280V DC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 480mW
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Body colour: white
OEM number: 600339
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1529 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.76 EUR
21+3.43 EUR
23+3.25 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5012 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-5012
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VAC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 852385
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 0.75VA
Coil voltage min.: 9.6V AC
Rated coil voltage: 12V AC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 13.2V AC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 100Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 689 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+3.58 EUR
22+3.35 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 2366559.pdf
RM84-2012-35-5024
Hersteller: RELPOL
Description: RELPOL - RM84-2012-35-5024 - Leistungsrelais, DPDT-2NC / 2NO, 24 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364190
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 400ohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 24VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 74 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024
Hersteller: RELPOL
8A; 24VAC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-5024 miniature relay P RM84p024-20wz
Anzahl je Verpackung: 20 Stücke
auf Bestellung 40 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+7.12 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024
Hersteller: RELPOL
8A; 24VAC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets equivalent: AZ743P, 41.52, JQX-115F/HF115F RM84 2012-35-5024 miniature relay P RM84p024-20wz
Anzahl je Verpackung: 20 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+7.12 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-5024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VAC; 8A; 8A/250VAC; 8A/24VDC
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 24V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 400Ω
Coil voltage min.: 19.2V AC
Coil voltage max.: 28.8V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 0.75VA
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Body colour: white
OEM number: 604615
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1105 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+3.65 EUR
21+3.42 EUR
41+1.76 EUR
43+1.67 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5048 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-5048
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 48VAC; 8A; 8A/250VAC; 8A/24VDC
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 48V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.55kΩ
Coil voltage min.: 43.2V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Coil power consumption: 0.75VA
Mechanical durability: 30000000 cycles
Contact resistance: 100mΩ
Coil voltage max.: 52.8V AC
Body colour: white
Anzahl je Verpackung: 1000 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5060
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 60VAC; Icontacts max: 8A; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 60V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 400V AC
Relay variant: miniature
Mounting: PCB; socket
Coil resistance: 2.6kΩ
Coil voltage min.: 48V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...70°C
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Current rating: 8A
Contact resistance: 100mΩ
Coil voltage max.: 72V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5110 2366559.pdf
RM84-2012-35-5110
Hersteller: RELPOL
Description: RELPOL - RM84-2012-35-5110 - Leistungsrelais, DPDT-2NC / 2NO, 110 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364900
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 8.9kohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 110VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 8 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5110
RM84-2012-35-5110
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 110VAC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 604618
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 0.75VA
Coil voltage min.: 88V AC
Rated coil voltage: 110V AC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 132V AC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 8.9kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 321 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+3.65 EUR
22+3.29 EUR
32+2.29 EUR
34+2.16 EUR
500+2.09 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5120
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 120VAC; Icontacts max: 8A
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 120V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 400V AC
Relay variant: miniature
Mounting: PCB; socket
Coil resistance: 10.2kΩ
Coil voltage min.: 96V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...70°C
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Current rating: 8A
Contact resistance: 100mΩ
Coil voltage max.: 144V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 2366559.pdf
RM84-2012-35-5230
Hersteller: RELPOL
Description: RELPOL - RM84-2012-35-5230 - Leistungsrelais, DPDT-2NC / 2NO, 230 VAC, 8 A, RM84, Sockel, AC
tariffCode: 85364900
rohsCompliant: YES
Relaisanschlüsse: Steckanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: AC
Kontaktmaterial: Silberlegierung
Kontaktstrom: 8A
usEccn: EAR99
Spulenwiderstand: 38.5kohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Sockel
Produktpalette: RM84
productTraceability: No
Spulenspannung: 230VAC
Kontaktkonfiguration: DPDT-2NC / 2NO
Kontaktspannung V AC: 440V
auf Bestellung 12 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230
Hersteller: RELPOL
8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 21 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230
Hersteller: RELPOL
8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 160 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230
Hersteller: RELPOL
8A; 230V AC; DPDT; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 2012-35-5230 miniature relay P RM84p230-20w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 15 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+13.02 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2012-35-5230 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2012-35-5230
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 230VAC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPDT
Rated coil voltage: 230V AC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 38.5kΩ
Coil voltage min.: 184V AC
Coil voltage max.: 276V AC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 8
Coil power consumption: 0.75VA
Body colour: white
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2896 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
12+6.31 EUR
16+4.52 EUR
17+4.28 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-1024
Hersteller: RELPOL
RM84-2022-25-1024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-1024-01
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; Icontacts max: 8A
Contact material: AgNi
Related items: EC50; GD50; GZF80; GZM80; GZS80; GZT80; PW80
Contacts configuration: DPST-NO
Type of relay: electromagnetic
Manufacturer series: RM84
IP rating: IP40
Relay variant: miniature
Mounting: PCB; socket
Operating temperature: -20...70°C
Release time: 3ms
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Contact current max.: 8A
Current rating: 8A
DC contacts rating @R: 8A / 24V DC
AC contacts rating @R: 8A / 250V AC
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
Switched voltage: max. 400V AC
Coil voltage max.: 61.2V DC
Coil resistance: 1.44kΩ
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-25-5230
Hersteller: RELPOL
RM84-2022-25-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1005 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2022-35-1005
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 5VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600463
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 3.5V DC
Rated coil voltage: 5V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 12.7V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 60Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1199 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1006
Hersteller: RELPOL
RM84-2022-35-1006 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1009
Hersteller: RELPOL
RM84-2022-35-1009 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1012 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2022-35-1012
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 12VDC; 8A; 8A/250VAC; RM84
Type of relay: electromagnetic
Contacts configuration: DPST-NO
Rated coil voltage: 12V DC
Contact current max.: 8A
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Manufacturer series: RM84
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Coil voltage min.: 8.4V DC
Coil voltage max.: 30.6V DC
Operate time: 7ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
Coil power consumption: 480mW
IP rating: IP67
Mechanical durability: 30000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Height: 15.7mm
Number of pins: 6
Body colour: white
OEM number: 600466
Anzahl je Verpackung: 1 Stücke
auf Bestellung 278 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2022-35-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600468
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 788 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1048
Hersteller: RELPOL
RM84-2022-35-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1060
Hersteller: RELPOL
RM84-2022-35-1060 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2022-35-1110
Hersteller: RELPOL
RM84-2022-35-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-2312-35-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgNi/Au 5μm
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 201 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.75 EUR
9+8.17 EUR
10+7.72 EUR
500+7.52 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-1110
Hersteller: RELPOL
RM84-2312-35-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-2312-35-5230
Hersteller: RELPOL
RM84-2312-35-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1012
Hersteller: RELPOL
RM84-3012-25-1012 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-3012-25-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 72 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1024-01
Hersteller: RELPOL
RM84301225102401 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-1110
Hersteller: RELPOL
RM84-3012-25-1110 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-5230
Hersteller: RELPOL
RM84-3012-25-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-25-5230-01
Hersteller: RELPOL
RM84301225523001 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1005
Hersteller: RELPOL
RM84-3012-35-1005 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1012 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-3012-35-1012
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 8.4V DC
Rated coil voltage: 12V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 30.6V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 360Ω
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 481 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024
Hersteller: RELPOL
8A; 24V; DPST; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 3012 35 1024 miniature relay P RM84z024-30w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 4 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+5.38 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024
Hersteller: RELPOL
8A; 24V; DPST; coil power 480mW; 29,0 x 12,7 x 15,7mm; IP67 SMT, for sockets RM84 3012 35 1024 miniature relay P RM84z024-30w
Anzahl je Verpackung: 20 Stücke
auf Bestellung 20 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
20+5.38 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-3012-35-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPDT; Ucoil: 24VDC; 8A; 8A/250VAC; 8A/24VDC
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 8
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPDT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 944 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1048
Hersteller: RELPOL
RM84-3012-35-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-1060
Hersteller: RELPOL
RM84-3012-35-1060 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-5024
Hersteller: RELPOL
RM84-3012-35-5024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3012-35-5230
Hersteller: RELPOL
RM84-3012-35-5230 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-25-1024
Hersteller: RELPOL
RM84-3022-25-1024 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-25-1048
Hersteller: RELPOL
RM84-3022-25-1048 Miniature Electromagnetic Relays
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM84-3022-35-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDFBD83067519BAE0DC&compId=RM84_EN.pdf?ci_sign=2047140502cc24e7e11474ce6167e6698d8a6b89
RM84-3022-35-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; DPST-NO; Ucoil: 24VDC; 8A; 8A/250VAC; RM84
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM84
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 7ms
Height: 15.7mm
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 8A / 250V AC
Number of pins: 6
Coil voltage max.: 61.2V DC
Contact current max.: 8A
DC contacts rating @R: 8A / 24V DC
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Mechanical durability: 30000000 cycles
Contact material: AgSnO2
Contacts configuration: DPST-NO
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3859 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
25+2.93 EUR
27+2.67 EUR
39+1.86 EUR
41+1.76 EUR
500+1.69 EUR
Mindestbestellmenge: 25
Im Einkaufswagen  Stück im Wert von  UAH
RM84-P-5V (Analogon RM84-2012-35-1005)
Produktcode: 61907
zu Favoriten hinzufügen Lieblingsprodukt

RM84.pdf
RM84-P-5V (Analogon RM84-2012-35-1005)
+1
Hersteller: Relpol
Relais
Relaistyp: Relais
Beschreibung: Тип контактів: DPDT, Uкотушки: 5B; Iкомутації: 8A
Abmessungen: 29x12,7x15,7 mm
Spulenspannung: 5 VDC
Strom max: 8 A
Kontaktkonfiguration: DPDT(2C)
Schaltspannung: 250 VAC; 24 VDC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-1024
RM85-2011-25-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600053
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP40
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 316 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
26+2.8 EUR
29+2.53 EUR
40+1.83 EUR
42+1.73 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-1024-01 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-25-1024-01
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V DC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Coil voltage min.: 16.8V DC
Coil voltage max.: 61.2V DC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 480mW
Body colour: transparent
OEM number: 859720
Current rating: 16A
Max surge current: 30A
auf Bestellung 447 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
13+5.95 EUR
15+4.79 EUR
16+4.52 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-5024-01
RM85-2011-25-5024-01
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VAC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V AC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 400Ω
Coil voltage min.: 19.2V AC
Coil voltage max.: 28.8V AC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 0.75VA
Body colour: transparent
OEM number: 859814
Current rating: 16A
Max surge current: 30A
auf Bestellung 38 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
12+6.29 EUR
15+4.78 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-25-5230-01 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-25-5230-01
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 230VAC; Icontacts max: 16A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 230V AC
Contact current max.: 16A
AC contacts rating @R: 16A / 250V AC
DC contacts rating @R: 16A / 24V DC
Manufacturer series: RM85
Switched voltage: max. 250V DC; max. 440V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 38.5kΩ
Coil voltage min.: 184V AC
Coil voltage max.: 276V AC
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Release time: 3ms
IP rating: IP67
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: AgNi
Terminal pitch: 5mm
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
Coil power consumption: 0.75VA
Body colour: transparent
OEM number: 859721
Current rating: 16A
Max surge current: 30A
auf Bestellung 37 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
8+9.57 EUR
10+7.24 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1005 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-35-1005
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 16A; RM85
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600017
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 3.5V DC
Rated coil voltage: 5V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 12.7V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 60Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 1959 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
33+2.23 EUR
35+2.07 EUR
41+1.76 EUR
43+1.67 EUR
100+1.6 EUR
Mindestbestellmenge: 33
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1009 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-35-1009
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 9VDC; Icontacts max: 16A; RM85
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600019
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 6.3V DC
Rated coil voltage: 9V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 22.9V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 200Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 1005 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
26+2.8 EUR
29+2.53 EUR
41+1.76 EUR
43+1.67 EUR
500+1.6 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1012 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-35-1012
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600020
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 8.4V DC
Rated coil voltage: 12V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 360Ω
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 2241 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
13+5.55 EUR
19+3.78 EUR
41+1.76 EUR
43+1.67 EUR
100+1.66 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
RM85-2011-35-1024 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEABDED0880707E0D6&compId=RM85EN.pdf?ci_sign=e0776cf17c9b16c7a1902b24aea46a96831bb09a
RM85-2011-35-1024
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 16A
Related items: GD50; GZ80; GZM80; GZM80-BK; GZT80; PW80
OEM number: 600021
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
IP rating: IP67
Manufacturer series: RM85
Body colour: white
Operating temperature: -40...85°C
Release time: 3ms
Terminal pitch: 5mm
Operate time: 8ms
Body dimensions: 29x12.7x15.7mm
Contact resistance: 100mΩ
Coil power consumption: 480mW
Coil voltage min.: 16.8V DC
Rated coil voltage: 24V DC
AC contacts rating @R: 16A / 250V AC
Coil voltage max.: 30.6V DC
Contact current max.: 16A
DC contacts rating @R: 16A / 24V DC
Current rating: 16A
Coil resistance: 1.44kΩ
Switched voltage: max. 250V DC; max. 440V AC
Contact material: AgNi
Contacts configuration: SPDT
auf Bestellung 4401 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
36+2.03 EUR
39+1.84 EUR
41+1.76 EUR
44+1.63 EUR
100+1.6 EUR
Mindestbestellmenge: 36
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 4 8 12 16 20 24 27 28 29 30 31 32 33 34 35 36 37 40 44 48 49  [ Nächste Seite >> ]
