9GE0412P3K03 9GE0412P3K03 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1D2103A600C7&compId=9GE0412P3K03.pdf?ci_sign=43e9657de5a750bf8d58893952daaf7cdb2a8562 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 45.6m3/h; 58dBA; ball; 16500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 40x40x28mm
Power consumption: 10.08W
Current rating: 0.84A
Fan efficiency: 45.6m3/h
Noise level: 58dBA
Kind of Bearing: ball
Rotational rate/speed: 16500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.32m
Operating temperature: -20...60°C
Additional functions: lock sensor; PWM; reverse polarity protection
Operating voltage: 10.8...13.2V DC
Flammability rating: UL94V-0
auf Bestellung 33 Stücke:
Lieferzeit 14-21 Tag (e)
3+25.15 EUR
5+22.98 EUR
10+21.32 EUR
25+19.32 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9G0848H101 9G0848H101 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1547143140C7&compId=9G0848H101.pdf?ci_sign=951be205b9b497a12deeeff375c6b952513e9faf Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 80x80x38mm; 136.8m3/h; 49dBA; ball; 5700rpm
Enclosure material: plastic
Kind of fan: axial
Kind of Bearing: ball
Type of fan: DC
Kind of material: flame retardant
Leads: leads x3
Additional functions: lock sensor; reverse polarity protection
Impeller material: plastic
Flammability rating: UL94V-0
Operating temperature: -20...70°C
Fan dimensions: 80x80x38mm
Current rating: 0.2A
Lead length: 0.3m
Operating voltage: 40.8...55.2V DC
Power consumption: 9.6W
Noise level: 49dBA
Supply voltage: 48V DC
Fan efficiency: 136.8m3/h
Rotational rate/speed: 5700rpm
Min. insulation resistance: 10MΩ
auf Bestellung 58 Stücke:
Lieferzeit 14-21 Tag (e)
3+27.26 EUR
54+25 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9SG5748P5G01 9SG5748P5G01 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD23200DF560C7&compId=9SG5748P5G01.pdf?ci_sign=83b90147173e11932145f698349fb1dbb2dacc48 Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 172x150x51mm; 927.6m3/h; 78dBA; ball; 8600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V DC
Fan dimensions: 172x150x51mm
Power consumption: 140W
Current rating: 2.91A
Fan efficiency: 927.6m3/h
Noise level: 78dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...60°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
auf Bestellung 13 Stücke:
Lieferzeit 14-21 Tag (e)
1+129.31 EUR
8+106.99 EUR
Im Einkaufswagen  Stück im Wert von  UAH
9GP5748P5G001 9GP5748P5G001 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1D53AD2800C7&compId=9GP5748P5G001.pdf?ci_sign=113b19f0b9cd43e52c7edd05089b6fa68f7e4c05 Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 172x150x51mm; 966m3/h; 83dBA; ball; 10500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V DC
Fan dimensions: 172x150x51mm
Power consumption: 240W
Current rating: 5A
Fan efficiency: 966m3/h
Noise level: 83dBA
Kind of Bearing: ball
Rotational rate/speed: 10500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
1+384.81 EUR
Im Einkaufswagen  Stück im Wert von  UAH
9G1224E401 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1657624280C7&compId=9G1224E401.pdf?ci_sign=7b683f9fdf570bbb3afd670570b95adb539c3a08 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 195m3/h; 48dBA; ball; 3650rpm
Kind of Bearing: ball
Type of fan: DC
Kind of material: flame retardant
Leads: leads x3
Enclosure material: plastic
Impeller material: plastic
Flammability rating: UL94V-1
Operating temperature: -20...70°C
Fan dimensions: 120x120x25mm
Current rating: 0.37A
Lead length: 0.3m
Power consumption: 8.88W
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Fan efficiency: 195m3/h
Noise level: 48dBA
Rotational rate/speed: 3650rpm
Min. insulation resistance: 10MΩ
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624P6G001 9GA0624P6G001 SANYO DENKI 9GA0624P6G001.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 52.8m3/h; 43dBA; ball; 6850rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 2.88W
Current rating: 0.12A
Fan efficiency: 52.8m3/h
Noise level: 43dBA
Kind of Bearing: ball
Rotational rate/speed: 6850rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 118 Stücke:
Lieferzeit 14-21 Tag (e)
3+25.24 EUR
5+23.15 EUR
10+20.39 EUR
20+19.25 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9WF0624H601 SANYO DENKI 9WF0624H601.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 41.4m3/h; 42dBA; ball; 6600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.6W
Current rating: 0.15A
Fan efficiency: 41.4m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 6600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624M6001 SANYO DENKI 9GA0624M6001.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 20.4m3/h; 18dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 0.72W
Current rating: 30mA
Fan efficiency: 20.4m3/h
Noise level: 18dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0624H601 SANYO DENKI 109P0624H601.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 20.4...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.68W
Current rating: 70mA
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0624W601 SANYO DENKI 109P0624W601.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...30V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.68W
Current rating: 70mA
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0648H6D01 SANYO DENKI 109P0648H6D01.pdf Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 60x60x20mm; 33m3/h; 41dBA; ball; 5600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 43...53V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.36W
Current rating: 70mA
Fan efficiency: 33m3/h
Noise level: 41dBA
Kind of Bearing: ball
Rotational rate/speed: 5600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624M6D001 SANYO DENKI page=60GA20 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 20.4m3/h; 18dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 0.72W
Current rating: 30mA
Fan efficiency: 20.4m3/h
Noise level: 18dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WFA0624G6001 SANYO DENKI 9WFA0624G6001.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 47.4m3/h; 48dBA; ball; 7700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 15...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.8W
Current rating: 0.16A
Fan efficiency: 47.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 7700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109R0612S401 109R0612S401 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD0DD9244320C7&compId=109R0612S401.pdf?ci_sign=481bca8ba1c867ec118cee6dfefdac97d8a39042 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 39m3/h; 33dBA; ball; 4600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 2.04W
Current rating: 0.17A
Fan efficiency: 39m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 4600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 43 Stücke:
Lieferzeit 14-21 Tag (e)
5+16.03 EUR
10+14.89 EUR
25+14.84 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
109R0612J4021 109R0612J4021 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 63.6m3/h; 44dBA; ball; 7600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.8...13.2V DC
Fan dimensions: 60x60x25mm
Power consumption: 5.64W
Current rating: 0.47A
Fan efficiency: 63.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 7600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x2
Operating temperature: -20...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 31 Stücke:
Lieferzeit 14-21 Tag (e)
5+15.36 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
109R0612J4011 109R0612J4011 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD0DD92441E0C7&compId=109R0612J4011.pdf?ci_sign=fe84e45d3f09cc9ace45f3912c7e27f48293cff0 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 63.6m3/h; 44dBA; ball; 7600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.8...13.2V DC
Fan dimensions: 60x60x25mm
Power consumption: 5.64W
Current rating: 0.47A
Fan efficiency: 63.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 7600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 48 Stücke:
Lieferzeit 14-21 Tag (e)
3+24.4 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9GA0824P1H61 9GA0824P1H61 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1A423575A0C7&compId=9GA0824P1H61.pdf?ci_sign=6a7e4c7f0c1a3b26153d5dc84c65f47a6523b710 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 135m3/h; 55dBA; ball; 8250rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 7.2W
Current rating: 0.3A
Fan efficiency: 135m3/h
Noise level: 55dBA
Kind of Bearing: ball
Rotational rate/speed: 8250rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
auf Bestellung 51 Stücke:
Lieferzeit 14-21 Tag (e)
2+41.2 EUR
10+36.24 EUR
27+34.43 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
9HV0824P1G0011 9HV0824P1G0011 SANYO DENKI 9HV0824P1G0011.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 222m3/h; 69dBA; ball; 14900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 80x80x38mm
Power consumption: 40.8W
Current rating: 1.7A
Fan efficiency: 222m3/h
Noise level: 69dBA
Kind of Bearing: ball
Rotational rate/speed: 14900rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 106 Stücke:
Lieferzeit 14-21 Tag (e)
2+59.87 EUR
10+57.87 EUR
20+55.88 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
109-153 109-153 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3720C7&compId=San_Ace_handy_E.pdf?ci_sign=03d691b3183031c9f9b54dcdd886783284ccdd4e Category: AC115V Fans
Description: Fan: AC; axial; 80x80x38mm; 54m3/h; 35dBA; ball; 2700rpm; 115VAC
Type of fan: AC
Kind of fan: axial
Fan dimensions: 80x80x38mm
Power consumption: 9W
Current rating: 0.11A
Fan efficiency: 54m3/h
Noise level: 35dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Operating temperature: -30...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 115V AC
Rated voltage: 115V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109-154 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3720C7&compId=San_Ace_handy_E.pdf?ci_sign=03d691b3183031c9f9b54dcdd886783284ccdd4e Category: AC230V Fans
Description: Fan: AC; axial; 80x80x38mm; 54m3/h; 35dBA; ball; 2700rpm; 230VAC
Type of fan: AC
Kind of fan: axial
Fan dimensions: 80x80x38mm
Power consumption: 9W
Current rating: 60mA
Fan efficiency: 54m3/h
Noise level: 35dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Operating temperature: -30...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 230V AC
Rated voltage: 230V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G101 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD15110A5FE0C7&compId=9G0824G101.pdf?ci_sign=1d293b81ae3f8c597d9f86449feee140d7759c2b Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G102 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0812G1D01 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.2W
Current rating: 1.1A
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 7...13.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G1021 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0848G101 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD15110A6120C7&compId=9G0848G101.pdf?ci_sign=dcb844ea6935c3911a43b5970ed7cadae7d04cb4 Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 80x80x38mm
Power consumption: 13W
Current rating: 0.27A
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 40.8...55.2V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GV0812G101 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x38mm; 234m3/h; 65dBA; ball; 10200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x38mm
Power consumption: 45.6W
Current rating: 3.8A
Fan efficiency: 234m3/h
Noise level: 65dBA
Kind of Bearing: ball
Rotational rate/speed: 10200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 10.8...13.2V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WP0824H4011 9WP0824H4011 SANYO DENKI 9WP0824H4011.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 61.8m3/h; 29dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10.2...13.8V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 61.8m3/h
Noise level: 29dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 15 Stücke:
Lieferzeit 14-21 Tag (e)
3+35.55 EUR
5+33.39 EUR
10+30.59 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
103H7822-0110P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 1.17Nm; 1A
Type of motor: DC
Standard: NEMA 24
Motors features: step 1,8°
Body dimensions: 60x60x53.8mm
Current rating: 1A
Nominal torque: 1.17Nm
Supply voltage: 24V DC
Kind of motor: 2-phase; stepper; unipolar
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H201 SANYO DENKI San_Ace_92WF32_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H202 SANYO DENKI San_Ace_92WF32_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H2D01 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial
Kind of fan: axial
Type of fan: DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S2011 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H2011 SANYO DENKI San_Ace_92WF32_E.pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4011 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H402 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4D01 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4D011 SANYO DENKI Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S202 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S2D01 SANYO DENKI page=Oil_Proof_Fan Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-5010P SANYO DENKI SANMOTION_F2_E.pdf Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.28Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 2A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0412K3023 109P0412K3023 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3820C7&compId=TR16e_e_en.pdf?ci_sign=3f0f422027800f7a688e848e5f6617dc2e7759dd Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball; 15500rpm
Kind of material: flame retardant
Leads: leads x2
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Impeller material: plastic
Flammability rating: UL94V-1
Operating temperature: -20...70°C
Fan dimensions: 40x40x28mm
Lead length: 0.32m
Current rating: 0.55A
Power consumption: 6.6W
Operating voltage: 8...13.2V DC
Supply voltage: 12V DC
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Min. insulation resistance: 10MΩ
Kind of fan: axial
Kind of Bearing: ball
Type of fan: DC
auf Bestellung 126 Stücke:
Lieferzeit 14-21 Tag (e)
5+15.19 EUR
6+13.77 EUR
10+13.13 EUR
25+12.64 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
103H6703-5040 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.49Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.49Nm
Current rating: 2A
Body dimensions: 50x50x51.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6703-5040P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.49Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.49Nm
Current rating: 2A
Body dimensions: 50x50x51.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5210-0410P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.37Nm
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.37Nm
Current rating: 1.2A
Body dimensions: 42x42x48mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5209-5110P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.41Nm; 0.5A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.41Nm
Current rating: 0.5A
Body dimensions: 42x42x41mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7823-0430P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 2.1Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 2.1Nm
Current rating: 2A
Body dimensions: 60x60x84.5mm
Standard: NEMA 24
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6704-0440 103H6704-0440 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.52Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.52Nm
Current rating: 2A
Body dimensions: 50x50x55.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6704-0440P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.52Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.52Nm
Current rating: 2A
Body dimensions: 50x50x55.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7822-1740P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 1.37Nm; 4A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 1.37Nm
Current rating: 4A
Body dimensions: 60x60x53.8mm
Standard: NEMA 24
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-0740 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.28Nm; 3A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 3A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-0740P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.28Nm; 3A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 3A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-5040P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.28Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 2A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5210-5249 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5208-5040P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.35Nm
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.35Nm
Current rating: 0.25A
Body dimensions: 42x42x39mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7126-5710P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 1.6Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 1.6Nm
Current rating: 2A
Body dimensions: 56x56x75.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WL1412P5S001 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD25178D58E0C7&compId=9WL1412P5S001.pdf?ci_sign=41ec9759cd1376645facbdaeee71412082ca8faa Category: DC12V Fans
Description: Fan: DC; axial; 10.2÷13.8VDC; 140x140x51mm; 360m3/h; 57dBA; ball
Type of fan: DC
Kind of fan: axial
Supply voltage: 10.2...13.8V DC
Operating voltage: 12V DC
Fan dimensions: 140x140x51mm
Power consumption: 22W
Current rating: 1.83A
Fan efficiency: 360m3/h
Noise level: 57dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: steel
Enclosure material: aluminium
IP rating: IP68
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9LG1412P5S001 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD2126036340C7&compId=9LG1412P5S001.pdf?ci_sign=de3df66737220f37aab458cca5a25d26b4b220bd Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 140x140x51mm; 360m3/h; 57dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V DC
Fan dimensions: 140x140x51mm
Power consumption: 22W
Current rating: 1.83A
Fan efficiency: 360m3/h
Noise level: 57dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7124-0110 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.98Nm; 1A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.98Nm
Current rating: 1A
Body dimensions: 56x56x63.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7124-0110P SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.98Nm; 1A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.98Nm
Current rating: 1A
Body dimensions: 56x56x63.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103F5208-4041 SANYO DENKI pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GE0412P3K03 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1D2103A600C7&compId=9GE0412P3K03.pdf?ci_sign=43e9657de5a750bf8d58893952daaf7cdb2a8562
9GE0412P3K03
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 45.6m3/h; 58dBA; ball; 16500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 40x40x28mm
Power consumption: 10.08W
Current rating: 0.84A
Fan efficiency: 45.6m3/h
Noise level: 58dBA
Kind of Bearing: ball
Rotational rate/speed: 16500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.32m
Operating temperature: -20...60°C
Additional functions: lock sensor; PWM; reverse polarity protection
Operating voltage: 10.8...13.2V DC
Flammability rating: UL94V-0
auf Bestellung 33 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+25.15 EUR
5+22.98 EUR
10+21.32 EUR
25+19.32 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9G0848H101 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1547143140C7&compId=9G0848H101.pdf?ci_sign=951be205b9b497a12deeeff375c6b952513e9faf
9G0848H101
Hersteller: SANYO DENKI
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 80x80x38mm; 136.8m3/h; 49dBA; ball; 5700rpm
Enclosure material: plastic
Kind of fan: axial
Kind of Bearing: ball
Type of fan: DC
Kind of material: flame retardant
Leads: leads x3
Additional functions: lock sensor; reverse polarity protection
Impeller material: plastic
Flammability rating: UL94V-0
Operating temperature: -20...70°C
Fan dimensions: 80x80x38mm
Current rating: 0.2A
Lead length: 0.3m
Operating voltage: 40.8...55.2V DC
Power consumption: 9.6W
Noise level: 49dBA
Supply voltage: 48V DC
Fan efficiency: 136.8m3/h
Rotational rate/speed: 5700rpm
Min. insulation resistance: 10MΩ
auf Bestellung 58 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+27.26 EUR
54+25 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9SG5748P5G01 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD23200DF560C7&compId=9SG5748P5G01.pdf?ci_sign=83b90147173e11932145f698349fb1dbb2dacc48
9SG5748P5G01
Hersteller: SANYO DENKI
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 172x150x51mm; 927.6m3/h; 78dBA; ball; 8600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V DC
Fan dimensions: 172x150x51mm
Power consumption: 140W
Current rating: 2.91A
Fan efficiency: 927.6m3/h
Noise level: 78dBA
Kind of Bearing: ball
Rotational rate/speed: 8600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...60°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
auf Bestellung 13 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+129.31 EUR
8+106.99 EUR
Im Einkaufswagen  Stück im Wert von  UAH
9GP5748P5G001 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1D53AD2800C7&compId=9GP5748P5G001.pdf?ci_sign=113b19f0b9cd43e52c7edd05089b6fa68f7e4c05
9GP5748P5G001
Hersteller: SANYO DENKI
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 172x150x51mm; 966m3/h; 83dBA; ball; 10500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 36...72V DC
Fan dimensions: 172x150x51mm
Power consumption: 240W
Current rating: 5A
Fan efficiency: 966m3/h
Noise level: 83dBA
Kind of Bearing: ball
Rotational rate/speed: 10500rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
auf Bestellung 7 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
1+384.81 EUR
Im Einkaufswagen  Stück im Wert von  UAH
9G1224E401 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1657624280C7&compId=9G1224E401.pdf?ci_sign=7b683f9fdf570bbb3afd670570b95adb539c3a08
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 195m3/h; 48dBA; ball; 3650rpm
Kind of Bearing: ball
Type of fan: DC
Kind of material: flame retardant
Leads: leads x3
Enclosure material: plastic
Impeller material: plastic
Flammability rating: UL94V-1
Operating temperature: -20...70°C
Fan dimensions: 120x120x25mm
Current rating: 0.37A
Lead length: 0.3m
Power consumption: 8.88W
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Fan efficiency: 195m3/h
Noise level: 48dBA
Rotational rate/speed: 3650rpm
Min. insulation resistance: 10MΩ
Additional functions: lock sensor; reverse polarity protection
Kind of fan: axial
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624P6G001 9GA0624P6G001.pdf
9GA0624P6G001
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 52.8m3/h; 43dBA; ball; 6850rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 2.88W
Current rating: 0.12A
Fan efficiency: 52.8m3/h
Noise level: 43dBA
Kind of Bearing: ball
Rotational rate/speed: 6850rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 118 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+25.24 EUR
5+23.15 EUR
10+20.39 EUR
20+19.25 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9WF0624H601 9WF0624H601.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 41.4m3/h; 42dBA; ball; 6600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.6W
Current rating: 0.15A
Fan efficiency: 41.4m3/h
Noise level: 42dBA
Kind of Bearing: ball
Rotational rate/speed: 6600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624M6001 9GA0624M6001.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 20.4m3/h; 18dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 0.72W
Current rating: 30mA
Fan efficiency: 20.4m3/h
Noise level: 18dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0624H601 109P0624H601.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 20.4...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.68W
Current rating: 70mA
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0624W601 109P0624W601.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 25.2m3/h; 31dBA; ball; 4200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 12...30V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.68W
Current rating: 70mA
Fan efficiency: 25.2m3/h
Noise level: 31dBA
Kind of Bearing: ball
Rotational rate/speed: 4200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0648H6D01 109P0648H6D01.pdf
Hersteller: SANYO DENKI
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 60x60x20mm; 33m3/h; 41dBA; ball; 5600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Operating voltage: 43...53V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.36W
Current rating: 70mA
Fan efficiency: 33m3/h
Noise level: 41dBA
Kind of Bearing: ball
Rotational rate/speed: 5600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GA0624M6D001 page=60GA20
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 20.4m3/h; 18dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 60x60x20mm
Power consumption: 0.72W
Current rating: 30mA
Fan efficiency: 20.4m3/h
Noise level: 18dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WFA0624G6001 9WFA0624G6001.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 47.4m3/h; 48dBA; ball; 7700rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 15...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 3.8W
Current rating: 0.16A
Fan efficiency: 47.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 7700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109R0612S401 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD0DD9244320C7&compId=109R0612S401.pdf?ci_sign=481bca8ba1c867ec118cee6dfefdac97d8a39042
109R0612S401
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 39m3/h; 33dBA; ball; 4600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 2.04W
Current rating: 0.17A
Fan efficiency: 39m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 4600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 43 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
5+16.03 EUR
10+14.89 EUR
25+14.84 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
109R0612J4021 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4
109R0612J4021
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 63.6m3/h; 44dBA; ball; 7600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.8...13.2V DC
Fan dimensions: 60x60x25mm
Power consumption: 5.64W
Current rating: 0.47A
Fan efficiency: 63.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 7600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x2
Operating temperature: -20...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 31 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
5+15.36 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
109R0612J4011 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD0DD92441E0C7&compId=109R0612J4011.pdf?ci_sign=fe84e45d3f09cc9ace45f3912c7e27f48293cff0
109R0612J4011
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 63.6m3/h; 44dBA; ball; 7600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.8...13.2V DC
Fan dimensions: 60x60x25mm
Power consumption: 5.64W
Current rating: 0.47A
Fan efficiency: 63.6m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 7600rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Operating temperature: -20...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Lead length: 0.3m
auf Bestellung 48 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+24.4 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
9GA0824P1H61 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD1A423575A0C7&compId=9GA0824P1H61.pdf?ci_sign=6a7e4c7f0c1a3b26153d5dc84c65f47a6523b710
9GA0824P1H61
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 135m3/h; 55dBA; ball; 8250rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 7.2W
Current rating: 0.3A
Fan efficiency: 135m3/h
Noise level: 55dBA
Kind of Bearing: ball
Rotational rate/speed: 8250rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
auf Bestellung 51 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+41.2 EUR
10+36.24 EUR
27+34.43 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
9HV0824P1G0011 9HV0824P1G0011.pdf
9HV0824P1G0011
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 222m3/h; 69dBA; ball; 14900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 21.6...26.4V DC
Fan dimensions: 80x80x38mm
Power consumption: 40.8W
Current rating: 1.7A
Fan efficiency: 222m3/h
Noise level: 69dBA
Kind of Bearing: ball
Rotational rate/speed: 14900rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 106 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+59.87 EUR
10+57.87 EUR
20+55.88 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
109-153 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3720C7&compId=San_Ace_handy_E.pdf?ci_sign=03d691b3183031c9f9b54dcdd886783284ccdd4e
109-153
Hersteller: SANYO DENKI
Category: AC115V Fans
Description: Fan: AC; axial; 80x80x38mm; 54m3/h; 35dBA; ball; 2700rpm; 115VAC
Type of fan: AC
Kind of fan: axial
Fan dimensions: 80x80x38mm
Power consumption: 9W
Current rating: 0.11A
Fan efficiency: 54m3/h
Noise level: 35dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Operating temperature: -30...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 115V AC
Rated voltage: 115V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109-154 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3720C7&compId=San_Ace_handy_E.pdf?ci_sign=03d691b3183031c9f9b54dcdd886783284ccdd4e
Hersteller: SANYO DENKI
Category: AC230V Fans
Description: Fan: AC; axial; 80x80x38mm; 54m3/h; 35dBA; ball; 2700rpm; 230VAC
Type of fan: AC
Kind of fan: axial
Fan dimensions: 80x80x38mm
Power consumption: 9W
Current rating: 60mA
Fan efficiency: 54m3/h
Noise level: 35dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Operating temperature: -30...60°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 230V AC
Rated voltage: 230V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G101 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD15110A5FE0C7&compId=9G0824G101.pdf?ci_sign=1d293b81ae3f8c597d9f86449feee140d7759c2b
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G102 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0812G1D01 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.2W
Current rating: 1.1A
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 7...13.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0824G1021 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x38mm
Power consumption: 13.4W
Current rating: 560mA
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 20.4...27.6V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9G0848G101 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD15110A6120C7&compId=9G0848G101.pdf?ci_sign=dcb844ea6935c3911a43b5970ed7cadae7d04cb4
Hersteller: SANYO DENKI
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 80x80x38mm; 153m3/h; 51dBA; ball; 6300rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 80x80x38mm
Power consumption: 13W
Current rating: 0.27A
Fan efficiency: 153m3/h
Noise level: 51dBA
Kind of Bearing: ball
Rotational rate/speed: 6300rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 40.8...55.2V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9GV0812G101 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F826898C000C7&compId=San_Ace_E.pdf?ci_sign=2083367ca1160a3ebedcf50abd7c9f5dbe02e2a4
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x38mm; 234m3/h; 65dBA; ball; 10200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x38mm
Power consumption: 45.6W
Current rating: 3.8A
Fan efficiency: 234m3/h
Noise level: 65dBA
Kind of Bearing: ball
Rotational rate/speed: 10200rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; PWM; reverse polarity protection
Kind of material: flame retardant
Operating voltage: 10.8...13.2V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WP0824H4011 9WP0824H4011.pdf
9WP0824H4011
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 61.8m3/h; 29dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10.2...13.8V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 0.13A
Fan efficiency: 61.8m3/h
Noise level: 29dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: plastic
Leads: leads x3
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-1
Additional functions: lock sensor; reverse polarity protection
Kind of material: flame retardant
auf Bestellung 15 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
3+35.55 EUR
5+33.39 EUR
10+30.59 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
103H7822-0110P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 1.17Nm; 1A
Type of motor: DC
Standard: NEMA 24
Motors features: step 1,8°
Body dimensions: 60x60x53.8mm
Current rating: 1A
Nominal torque: 1.17Nm
Supply voltage: 24V DC
Kind of motor: 2-phase; stepper; unipolar
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H201 San_Ace_92WF32_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H202 San_Ace_92WF32_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H2D01 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial
Kind of fan: axial
Type of fan: DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S2011 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H2011 San_Ace_92WF32_E.pdf
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4011 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: tach output
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H402 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4D01 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924H4D011
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm; ribless
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Version: ribless
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S202 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WF0924S2D01 page=Oil_Proof_Fan
Hersteller: SANYO DENKI
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 92x92x32mm; 56dBA; ball; 6500rpm
Current rating: 0.35A
Leads: leads x3
Operating temperature: -10...70°C
Kind of fan: axial
Min. insulation resistance: 10MΩ
Kind of Bearing: ball
Type of fan: DC
Additional functions: lock sensor
Impeller material: plastic
Fan dimensions: 92x92x32mm
Lead length: 0.3m
Operating voltage: 20.4...27.6V DC
Supply voltage: 24V DC
Noise level: 56dBA
Rotational rate/speed: 6500rpm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-5010P SANMOTION_F2_E.pdf
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.28Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 2A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
109P0412K3023 pVersion=0046&contRep=ZT&docId=005056AB90B41EDC848F82403C3820C7&compId=TR16e_e_en.pdf?ci_sign=3f0f422027800f7a688e848e5f6617dc2e7759dd
109P0412K3023
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x28mm; 35.4m3/h; 50dBA; ball; 15500rpm
Kind of material: flame retardant
Leads: leads x2
Additional functions: lock sensor; reverse polarity protection
Enclosure material: plastic
Impeller material: plastic
Flammability rating: UL94V-1
Operating temperature: -20...70°C
Fan dimensions: 40x40x28mm
Lead length: 0.32m
Current rating: 0.55A
Power consumption: 6.6W
Operating voltage: 8...13.2V DC
Supply voltage: 12V DC
Fan efficiency: 35.4m3/h
Noise level: 50dBA
Rotational rate/speed: 15500rpm
Min. insulation resistance: 10MΩ
Kind of fan: axial
Kind of Bearing: ball
Type of fan: DC
auf Bestellung 126 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
5+15.19 EUR
6+13.77 EUR
10+13.13 EUR
25+12.64 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
103H6703-5040 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.49Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.49Nm
Current rating: 2A
Body dimensions: 50x50x51.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6703-5040P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.49Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.49Nm
Current rating: 2A
Body dimensions: 50x50x51.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5210-0410P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.37Nm
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.37Nm
Current rating: 1.2A
Body dimensions: 42x42x48mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5209-5110P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.41Nm; 0.5A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.41Nm
Current rating: 0.5A
Body dimensions: 42x42x41mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7823-0430P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 2.1Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 2.1Nm
Current rating: 2A
Body dimensions: 60x60x84.5mm
Standard: NEMA 24
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6704-0440 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
103H6704-0440
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.52Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.52Nm
Current rating: 2A
Body dimensions: 50x50x55.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6704-0440P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.52Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.52Nm
Current rating: 2A
Body dimensions: 50x50x55.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7822-1740P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 1.37Nm; 4A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 1.37Nm
Current rating: 4A
Body dimensions: 60x60x53.8mm
Standard: NEMA 24
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-0740 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.28Nm; 3A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 3A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-0740P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.28Nm; 3A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 3A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H6701-5040P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.28Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.28Nm
Current rating: 2A
Body dimensions: 50x50x39.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5210-5249 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H5208-5040P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 0.35Nm
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.35Nm
Current rating: 0.25A
Body dimensions: 42x42x39mm
Standard: NEMA 17
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7126-5710P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°; 1.6Nm; 2A
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 1.6Nm
Current rating: 2A
Body dimensions: 56x56x75.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9WL1412P5S001 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD25178D58E0C7&compId=9WL1412P5S001.pdf?ci_sign=41ec9759cd1376645facbdaeee71412082ca8faa
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 10.2÷13.8VDC; 140x140x51mm; 360m3/h; 57dBA; ball
Type of fan: DC
Kind of fan: axial
Supply voltage: 10.2...13.8V DC
Operating voltage: 12V DC
Fan dimensions: 140x140x51mm
Power consumption: 22W
Current rating: 1.83A
Fan efficiency: 360m3/h
Noise level: 57dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: steel
Enclosure material: aluminium
IP rating: IP68
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
9LG1412P5S001 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA1FD2126036340C7&compId=9LG1412P5S001.pdf?ci_sign=de3df66737220f37aab458cca5a25d26b4b220bd
Hersteller: SANYO DENKI
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 140x140x51mm; 360m3/h; 57dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 10.2...13.8V DC
Fan dimensions: 140x140x51mm
Power consumption: 22W
Current rating: 1.83A
Fan efficiency: 360m3/h
Noise level: 57dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: plastic
Enclosure material: aluminium
Leads: leads x4
Lead length: 0.3m
Operating temperature: -20...70°C
Flammability rating: UL94V-0
Additional functions: lock sensor; PWM; reverse polarity protection
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7124-0110 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.98Nm; 1A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.98Nm
Current rating: 1A
Body dimensions: 56x56x63.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103H7124-0110P pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,stepper,unipolar; 24VDC; step 1,8°; 0.98Nm; 1A
Type of motor: DC
Kind of motor: 2-phase; stepper; unipolar
Supply voltage: 24V DC
Motors features: step 1,8°
Nominal torque: 0.98Nm
Current rating: 1A
Body dimensions: 56x56x63.8mm
Standard: NEMA 23
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
103F5208-4041 pVersion=0046&contRep=ZT&docId=005056AB90B41EDABBB96F0BC72B40C7&compId=SANMOTION_F2_E.pdf?ci_sign=25e11a2d3feb899953e7685e38bc5db44ae4042e
Hersteller: SANYO DENKI
Category: Electric Motors
Description: Motor: DC; 2-phase,bipolar,stepper; 24VDC; step 1,8°
Type of motor: DC
Kind of motor: 2-phase; bipolar; stepper
Supply voltage: 24V DC
Motors features: step 1,8°
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 11 22 33 44 55 66 77 88 99 104 105 106 107 108 109 110 111 112 113  [ Nächste Seite >> ]
