Hersteller: SELEC
Category: Current Transformers
Description: Transformer: current; Iin: 400A; Iout: 5A; 0.5@max3.75VA; 50÷60Hz
Type of Transformer: current
Manufacturer series: SPCT 62/40
Input current: 400A
Output current: 5A
Mounting: for DIN rail mounting (optional); on panel
Accuracy class: 0.5 @max 3.75VA
Internal diameter: 30.5mm
Operating frequency: 50...60Hz
Dimensions (a x b x c): 62x80.5x67mm
Operating temperature: 0...50°C
Conductor rail size: 40mmx10mm

Hersteller: SELEC
Category: Current Transformers
Description: Transformer: current; Iin: 400A; Iout: 5A; 0.5@max5VA; Øint: 30.5mm
Type of Transformer: current
Manufacturer series: SPCT 62/40
Input current: 400A
Output current: 5A
Mounting: for DIN rail mounting (optional); on panel
Accuracy class: 0.5 @max 5VA
Internal diameter: 30.5mm
Operating frequency: 50...60Hz
Dimensions (a x b x c): 62x80.5x67mm
Operating temperature: 0...50°C
Conductor rail size: 40mmx10mm

Hersteller: SELEC
Category: Digital Panel Meters - Others
Description: Meter: temperature controller; on panel; LED; 4 digit; Unit: °C,°F
Type of meter: temperature controller
Mounting: on panel
Kind of display used: LED
Display parameters: 4 digit
Supply voltage: 90...270V AC; 90...270V DC
Operating temperature: 0...50°C
Dimensions (W x H x D): 52x52x79.5mm
Kind of temperature sensor: Pt100; thermocouple J; thermocouple K; thermocouple R; thermocouple S; thermocouple T
Kind of input 1: RTD; thermocouple
Frequency: 50/60Hz
Regulation for output 1: AUTOTUNING; ON-OFF; PID
Measuring unit: °C; °F

Hersteller: SELEC
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; on panel; digital,mounting; LED
Type of meter: network parameters
Measurement: AC current; AC voltage; frequency; rpm velocity; time
Kind of meter: digital; mounting
Mounting: on panel
Kind of display used: LED
Display parameters: 3 digit
Supply voltage: 230V AC
Operating temperature: -10...55°C
Dimensions (W x H x D): 99x99x50mm
Kind of measurement: indirect with 5A current transformer
True effective value measurement: True RMS
AC current measuring range: 5...10kA
AC voltage measuring range: 100...500kV
Mounting hole diameter: 91.5x91.5mm
Maximum current: 6A
Operating frequency: 50...60Hz
Max. input voltage: 300V
Kind of network: 3-wire; 4-wire; three-phase

Hersteller: SELEC
Category: Digital Panel Meters - Others
Description: Meter: counter; digital,mounting; on panel; LED; 6 digits; 0÷50°C
Supply voltage: 90...270V AC; 90...270V DC
Measuring range: 999999
Type of meter: counter
Kind of meter: digital; mounting
Kind of display used: LED
Kind of input: NPN; PNP
Measurement: number of pulses; time
Mounting: on panel
Input: voltage 5...30V DC
Operating temperature: 0...50°C
Dimensions (W x H x D): 76x34.5x67.5mm
Display parameters: 6 digits

Hersteller: SELEC
Category: Digital Panel Meters - Others
Description: Meter: programmable; digital,mounting; on panel; LED; 6 digits
Type of meter: programmable
Measurement: number of pulses; time
Kind of meter: digital; mounting
Mounting: on panel
Kind of display used: LED
Display parameters: 6 digits
Measuring range: 0,0001...999999
Output: relay x2
Kind of input: NPN; PNP
Input: voltage 5...30V DC
Accuracy: 0.05%
Supply voltage: 90...270V AC; 90...270V DC
Operating temperature: 0...50°C
Dimensions (W x H x D): 48x48x72mm
