Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
SPU0410LR5H-QB SPU0410LR5H-QB Syntiant SPU0410LR5H-QB_RevH_3-27-13.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.118" W (3.76mm x 3.00mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 160 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 80 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0410LR5H-QB SPU0410LR5H-QB Syntiant SPU0410LR5H-QB_RevH_3-27-13.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.118" W (3.76mm x 3.00mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 160 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 80 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0414HR5H-SB SPU0414HR5H-SB Syntiant SPU0414HR5H-SB.pdf Description: MIC MEMS ANALOG OMNI -22DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -22dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 220 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0414HR5H-SB SPU0414HR5H-SB Syntiant SPU0414HR5H-SB.pdf Description: MIC MEMS ANALOG OMNI -22DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -22dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 220 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPUL409HE5H-PB SPUL409HE5H-PB Syntiant SPUL409HE5H-PB.pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -42dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 300 Ohms
Current - Supply: 190 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPUL409HE5H-PB SPUL409HE5H-PB Syntiant SPUL409HE5H-PB.pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -42dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 300 Ohms
Current - Supply: 190 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV0142LR5H-1 SPV0142LR5H-1 Syntiant SPV0142LR5H-1_DS.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Part Status: Active
Voltage - Rated: 1.8 V
Impedance: 400 Ohms
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 50 Hz ~ 10 kHz
auf Bestellung 3611 Stücke:
Lieferzeit 10-14 Tag (e)
13+1.39 EUR
16+1.13 EUR
25+1.04 EUR
50+0.98 EUR
100+0.92 EUR
250+0.85 EUR
500+0.83 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
SPV0142LR5H-1 SPV0142LR5H-1 Syntiant SPV0142LR5H-1_DS.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Part Status: Active
Voltage - Rated: 1.8 V
Impedance: 400 Ohms
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 50 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV08A0LR5H-1 SPV08A0LR5H-1 Syntiant SPV08A0LR5H-1_DS.pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV08A0LR5H-1 SPV08A0LR5H-1 Syntiant SPV08A0LR5H-1_DS.pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
auf Bestellung 5290 Stücke:
Lieferzeit 10-14 Tag (e)
11+1.67 EUR
13+1.36 EUR
25+1.26 EUR
50+1.18 EUR
100+1.11 EUR
250+1.02 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
SPV1142LR5H-1 SPV1142LR5H-1 Syntiant spv1142lr5h-1_quartz_datasheet.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.035" (0.90mm)
Voltage - Rated: 1.8 V
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 25 Hz ~ 16 kHz
auf Bestellung 12747 Stücke:
Lieferzeit 10-14 Tag (e)
11+1.65 EUR
14+1.35 EUR
25+1.25 EUR
50+1.17 EUR
100+1.10 EUR
250+1.01 EUR
500+0.95 EUR
1000+0.90 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
SPV1142LR5H-1 SPV1142LR5H-1 Syntiant spv1142lr5h-1_quartz_datasheet.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.035" (0.90mm)
Voltage - Rated: 1.8 V
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 25 Hz ~ 16 kHz
auf Bestellung 5900 Stücke:
Lieferzeit 10-14 Tag (e)
5900+0.82 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
SPV1840LR5H-B SPV1840LR5H-B Syntiant spv1840lr5h-b-rev-b-datasheet.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (0.98mm)
Impedance: 400 Ohms
Current - Supply: 60 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
auf Bestellung 472000 Stücke:
Lieferzeit 10-14 Tag (e)
5900+0.75 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
SPV1840LR5H-B SPV1840LR5H-B Syntiant spv1840lr5h-b-rev-b-datasheet.pdf Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (0.98mm)
Impedance: 400 Ohms
Current - Supply: 60 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
auf Bestellung 477924 Stücke:
Lieferzeit 10-14 Tag (e)
12+1.53 EUR
15+1.25 EUR
25+1.15 EUR
50+1.08 EUR
100+1.02 EUR
250+0.94 EUR
500+0.88 EUR
1000+0.83 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
SPV21A0LR5H-1V SPV21A0LR5H-1V Syntiant mic-selection-guide-v062822-(1).pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Impedance: 300 Ohms
Current - Supply: 200 µA
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 45 Hz ~ 15.5 kHz
auf Bestellung 2085 Stücke:
Lieferzeit 10-14 Tag (e)
10+1.81 EUR
12+1.48 EUR
25+1.36 EUR
50+1.28 EUR
100+1.20 EUR
250+1.11 EUR
500+1.04 EUR
1000+0.98 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
SPV21A0LR5H-1V SPV21A0LR5H-1V Syntiant mic-selection-guide-v062822-(1).pdf Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Impedance: 300 Ohms
Current - Supply: 200 µA
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 45 Hz ~ 15.5 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV61A0LR5H-1 SPV61A0LR5H-1 Syntiant SPV61A0LR5H-1.pdf Description: ROBIN ANALOG BOTTOM PART MIC
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -40dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 35 Hz ~ 18.5 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV61A0LR5H-1 SPV61A0LR5H-1 Syntiant SPV61A0LR5H-1.pdf Description: ROBIN ANALOG BOTTOM PART MIC
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -40dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 35 Hz ~ 18.5 kHz
auf Bestellung 1922 Stücke:
Lieferzeit 10-14 Tag (e)
10+1.80 EUR
13+1.46 EUR
25+1.34 EUR
50+1.26 EUR
100+1.19 EUR
250+1.10 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
SPW0690LM4H-1 SPW0690LM4H-1 Syntiant SPW0690LM4H-1_DS.pdf Description: MIC MEMS DIGITAL PDM OMNI -41DB
Packaging: Tape & Reel (TR)
Output Type: Digital, PDM
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -41dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.037" (0.95mm)
Current - Supply: 2 mA
Voltage Range: 1.65 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPW0690LM4H-1 SPW0690LM4H-1 Syntiant SPW0690LM4H-1_DS.pdf Description: MIC MEMS DIGITAL PDM OMNI -41DB
Packaging: Cut Tape (CT)
Output Type: Digital, PDM
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -41dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.037" (0.95mm)
Current - Supply: 2 mA
Voltage Range: 1.65 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
auf Bestellung 2837 Stücke:
Lieferzeit 10-14 Tag (e)
7+2.90 EUR
10+2.36 EUR
25+2.18 EUR
50+2.04 EUR
100+1.92 EUR
250+1.77 EUR
500+1.67 EUR
1000+1.57 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
SPW0878LR5H-1 SPW0878LR5H-1 Syntiant SPW0878LR5H-1_DS.pdf Description: MIC MEMS ANLG ELLEN OMNI -44DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -44dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.042" (1.06mm)
Impedance: 380 Ohms
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 15 Hz ~ 24 kHz
auf Bestellung 7630 Stücke:
Lieferzeit 10-14 Tag (e)
9+2.01 EUR
11+1.64 EUR
25+1.51 EUR
50+1.42 EUR
100+1.34 EUR
250+1.23 EUR
500+1.16 EUR
1000+1.09 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
SPW0878LR5H-1 SPW0878LR5H-1 Syntiant SPW0878LR5H-1_DS.pdf Description: MIC MEMS ANLG ELLEN OMNI -44DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -44dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.042" (1.06mm)
Impedance: 380 Ohms
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 15 Hz ~ 24 kHz
auf Bestellung 5700 Stücke:
Lieferzeit 10-14 Tag (e)
5700+1.01 EUR
Mindestbestellmenge: 5700
Im Einkaufswagen  Stück im Wert von  UAH
V2S200D V2S200D Syntiant Syntiant+V2S200D+Datasheet+Rev+B-1.pdf Description: DIGITAL VOICE VIBRATION SENSOR (
Packaging: Tape & Reel (TR)
Package / Case: 6-TLGA
Output Type: Voltage
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Power - Rated: 1.65V ~ 3.3V / 700µA
auf Bestellung 5900 Stücke:
Lieferzeit 10-14 Tag (e)
5900+3.96 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
V2S200D V2S200D Syntiant Syntiant+V2S200D+Datasheet+Rev+B-1.pdf Description: DIGITAL VOICE VIBRATION SENSOR (
Packaging: Cut Tape (CT)
Package / Case: 6-TLGA
Output Type: Voltage
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Power - Rated: 1.65V ~ 3.3V / 700µA
auf Bestellung 11458 Stücke:
Lieferzeit 10-14 Tag (e)
3+6.39 EUR
5+5.71 EUR
10+5.46 EUR
25+5.16 EUR
50+4.96 EUR
100+4.78 EUR
500+4.40 EUR
1000+4.26 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
SPU0410LR5H-QB SPU0410LR5H-QB_RevH_3-27-13.pdf
SPU0410LR5H-QB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.118" W (3.76mm x 3.00mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 160 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 80 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0410LR5H-QB SPU0410LR5H-QB_RevH_3-27-13.pdf
SPU0410LR5H-QB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.118" W (3.76mm x 3.00mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 160 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 80 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0414HR5H-SB SPU0414HR5H-SB.pdf
SPU0414HR5H-SB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -22DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -22dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 220 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPU0414HR5H-SB SPU0414HR5H-SB.pdf
SPU0414HR5H-SB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -22DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -22dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 400 Ohms
Current - Supply: 220 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPUL409HE5H-PB SPUL409HE5H-PB.pdf
SPUL409HE5H-PB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -42dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 300 Ohms
Current - Supply: 190 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPUL409HE5H-PB SPUL409HE5H-PB.pdf
SPUL409HE5H-PB
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.148" L x 0.116" W (3.76mm x 2.95mm)
Sensitivity: -42dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 59dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Top
Height (Max): 0.047" (1.20mm)
Impedance: 300 Ohms
Current - Supply: 190 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV0142LR5H-1 SPV0142LR5H-1_DS.pdf
SPV0142LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Part Status: Active
Voltage - Rated: 1.8 V
Impedance: 400 Ohms
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 50 Hz ~ 10 kHz
auf Bestellung 3611 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
13+1.39 EUR
16+1.13 EUR
25+1.04 EUR
50+0.98 EUR
100+0.92 EUR
250+0.85 EUR
500+0.83 EUR
Mindestbestellmenge: 13
Im Einkaufswagen  Stück im Wert von  UAH
SPV0142LR5H-1 SPV0142LR5H-1_DS.pdf
SPV0142LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Part Status: Active
Voltage - Rated: 1.8 V
Impedance: 400 Ohms
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 50 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV08A0LR5H-1 SPV08A0LR5H-1_DS.pdf
SPV08A0LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV08A0LR5H-1 SPV08A0LR5H-1_DS.pdf
SPV08A0LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
auf Bestellung 5290 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
11+1.67 EUR
13+1.36 EUR
25+1.26 EUR
50+1.18 EUR
100+1.11 EUR
250+1.02 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
SPV1142LR5H-1 spv1142lr5h-1_quartz_datasheet.pdf
SPV1142LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.035" (0.90mm)
Voltage - Rated: 1.8 V
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 25 Hz ~ 16 kHz
auf Bestellung 12747 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
11+1.65 EUR
14+1.35 EUR
25+1.25 EUR
50+1.17 EUR
100+1.10 EUR
250+1.01 EUR
500+0.95 EUR
1000+0.90 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
SPV1142LR5H-1 spv1142lr5h-1_quartz_datasheet.pdf
SPV1142LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 63dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.035" (0.90mm)
Voltage - Rated: 1.8 V
Current - Supply: 185 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 25 Hz ~ 16 kHz
auf Bestellung 5900 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5900+0.82 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
SPV1840LR5H-B spv1840lr5h-b-rev-b-datasheet.pdf
SPV1840LR5H-B
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (0.98mm)
Impedance: 400 Ohms
Current - Supply: 60 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
auf Bestellung 472000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5900+0.75 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
SPV1840LR5H-B spv1840lr5h-b-rev-b-datasheet.pdf
SPV1840LR5H-B
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -38DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -38dB ±3dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 62.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (0.98mm)
Impedance: 400 Ohms
Current - Supply: 60 µA
Voltage Range: 1.5 V ~ 3.6 V
Frequency Range: 100 Hz ~ 10 kHz
auf Bestellung 477924 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
12+1.53 EUR
15+1.25 EUR
25+1.15 EUR
50+1.08 EUR
100+1.02 EUR
250+0.94 EUR
500+0.88 EUR
1000+0.83 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
SPV21A0LR5H-1V mic-selection-guide-v062822-(1).pdf
SPV21A0LR5H-1V
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Impedance: 300 Ohms
Current - Supply: 200 µA
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 45 Hz ~ 15.5 kHz
auf Bestellung 2085 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
10+1.81 EUR
12+1.48 EUR
25+1.36 EUR
50+1.28 EUR
100+1.20 EUR
250+1.11 EUR
500+1.04 EUR
1000+0.98 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
SPV21A0LR5H-1V mic-selection-guide-v062822-(1).pdf
SPV21A0LR5H-1V
Hersteller: Syntiant
Description: MIC MEMS ANALOG OMNI -42DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -42dB ±1dB
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Impedance: 300 Ohms
Current - Supply: 200 µA
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 45 Hz ~ 15.5 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV61A0LR5H-1 SPV61A0LR5H-1.pdf
SPV61A0LR5H-1
Hersteller: Syntiant
Description: ROBIN ANALOG BOTTOM PART MIC
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -40dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 35 Hz ~ 18.5 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPV61A0LR5H-1 SPV61A0LR5H-1.pdf
SPV61A0LR5H-1
Hersteller: Syntiant
Description: ROBIN ANALOG BOTTOM PART MIC
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.108" L x 0.073" W (2.75mm x 1.85mm)
Sensitivity: -40dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.039" (1.00mm)
Voltage - Rated: 2.75 V
Current - Supply: 200 µA
Voltage Range: 2.3 V ~ 3.6 V
Frequency Range: 35 Hz ~ 18.5 kHz
auf Bestellung 1922 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
10+1.80 EUR
13+1.46 EUR
25+1.34 EUR
50+1.26 EUR
100+1.19 EUR
250+1.10 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
SPW0690LM4H-1 SPW0690LM4H-1_DS.pdf
SPW0690LM4H-1
Hersteller: Syntiant
Description: MIC MEMS DIGITAL PDM OMNI -41DB
Packaging: Tape & Reel (TR)
Output Type: Digital, PDM
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -41dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.037" (0.95mm)
Current - Supply: 2 mA
Voltage Range: 1.65 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SPW0690LM4H-1 SPW0690LM4H-1_DS.pdf
SPW0690LM4H-1
Hersteller: Syntiant
Description: MIC MEMS DIGITAL PDM OMNI -41DB
Packaging: Cut Tape (CT)
Output Type: Digital, PDM
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -41dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 66.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.037" (0.95mm)
Current - Supply: 2 mA
Voltage Range: 1.65 V ~ 3.6 V
Frequency Range: 20 Hz ~ 10 kHz
auf Bestellung 2837 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
7+2.90 EUR
10+2.36 EUR
25+2.18 EUR
50+2.04 EUR
100+1.92 EUR
250+1.77 EUR
500+1.67 EUR
1000+1.57 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
SPW0878LR5H-1 SPW0878LR5H-1_DS.pdf
SPW0878LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANLG ELLEN OMNI -44DB
Packaging: Cut Tape (CT)
Output Type: Analog
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -44dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.042" (1.06mm)
Impedance: 380 Ohms
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 15 Hz ~ 24 kHz
auf Bestellung 7630 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
9+2.01 EUR
11+1.64 EUR
25+1.51 EUR
50+1.42 EUR
100+1.34 EUR
250+1.23 EUR
500+1.16 EUR
1000+1.09 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
SPW0878LR5H-1 SPW0878LR5H-1_DS.pdf
SPW0878LR5H-1
Hersteller: Syntiant
Description: MIC MEMS ANLG ELLEN OMNI -44DB
Packaging: Tape & Reel (TR)
Output Type: Analog
Size / Dimension: 0.122" L x 0.098" W (3.10mm x 2.50mm)
Sensitivity: -44dB ±1dB @ 94dB SPL
Shape: Rectangular
Type: MEMS (Silicon)
S/N Ratio: 64.5dB
Termination: Solder Pads
Direction: Omnidirectional
Port Location: Bottom
Height (Max): 0.042" (1.06mm)
Impedance: 380 Ohms
Voltage Range: 1.6 V ~ 3.6 V
Frequency Range: 15 Hz ~ 24 kHz
auf Bestellung 5700 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5700+1.01 EUR
Mindestbestellmenge: 5700
Im Einkaufswagen  Stück im Wert von  UAH
V2S200D Syntiant+V2S200D+Datasheet+Rev+B-1.pdf
V2S200D
Hersteller: Syntiant
Description: DIGITAL VOICE VIBRATION SENSOR (
Packaging: Tape & Reel (TR)
Package / Case: 6-TLGA
Output Type: Voltage
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Power - Rated: 1.65V ~ 3.3V / 700µA
auf Bestellung 5900 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5900+3.96 EUR
Mindestbestellmenge: 5900
Im Einkaufswagen  Stück im Wert von  UAH
V2S200D Syntiant+V2S200D+Datasheet+Rev+B-1.pdf
V2S200D
Hersteller: Syntiant
Description: DIGITAL VOICE VIBRATION SENSOR (
Packaging: Cut Tape (CT)
Package / Case: 6-TLGA
Output Type: Voltage
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Power - Rated: 1.65V ~ 3.3V / 700µA
auf Bestellung 11458 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
3+6.39 EUR
5+5.71 EUR
10+5.46 EUR
25+5.16 EUR
50+4.96 EUR
100+4.78 EUR
500+4.40 EUR
1000+4.26 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 2
