Hersteller: UNI-T
Category: Accessories for Oscilloscopes - Others
Description: Expansion option; for oscilloscopes
Related items: MSO2102; MSO2102-S; MSO2104; MSO2104-S; MSO2202; MSO2202-S; MSO2204; MSO2204-S; UPO2072E; UPO2074E; UPO2102; UPO2102E; UPO2104; UPO2104E; UPO2202; UPO2204
Test accessories features: Bode plot loop test analysis
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Accessories for Oscilloscopes - Others
Description: Expansion option; for oscilloscopes
Related items: MSO2102; MSO2102-S; MSO2104; MSO2104-S; MSO2202; MSO2202-S; MSO2204; MSO2204-S; UPO2072E; UPO2074E; UPO2102; UPO2102E; UPO2104; UPO2104E; UPO2202; UPO2204
Test accessories features: Bode plot loop test analysis
Type of test accessories: expansion option
Application: for oscilloscopes
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: AudioBus triggering and decoding

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: automotive serial triggering and decoding

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: arbitrary waveform generator

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: serial triggering and decoding
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: bandwidth upgrade from 100MHz to 200MHz
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: bandwidth upgrade from 100MHz to 300MHz
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: bandwidth upgrade from 200MHz to 300MHz
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: CAN triggering and decoding

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: CAN FD triggering and decoding
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: FlexRay triggering and decoding
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: LIN triggering and decoding
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: power analysis
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Related items: MSO2104X; MSO2204X; MSO2304X
Test accessories features: automotive sensor bus trigger and analysis
Type of test accessories: expansion option
Application: for oscilloscopes

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Interface: AUX; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...20V/div
Time base: 2n...1ks/div
Memory record length: 56Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 5Gsps; 100Mpts; 2n÷1ks/div
Number of channels: 4
Standard equipment: BNC cable; expansion option MSO2000X-AWG; expansion option MSO2000X-BND; expansion option MSO2000X-PWR; mains cable; test probe x4; USB cable
Display resolution: 1280x800
Input impedance: 1MΩ/16pF
Dimensions: 378x218x120mm
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 500µV/div...10V/div
Time base: 2n...1ks/div
Memory record length: 100Mpts
Kind of display used: LCD TFT 10,1"; touch screen
Supply voltage: 100...240V AC
Interface: AUX; HDMI; LAN; USB device; USB Host; VGA

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 2 Gs/s; 56Mpts; LCD TFT 8"
Supply voltage: 100...240V AC
Interface: AUX; LAN; USB device; USB Host; VGA
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 370x185x115mm
Related items: MSO/UPO2000-AUTO; MSO/UPO2000-BND; MSO/UPO2000-CAN; MSO/UPO2000-CANF; MSO/UPO2000-COM; MSO/UPO2000-EMBD; MSO/UPO2000-FR; MSO/UPO2000-I2C; MSO/UPO2000-LIN; MSO/UPO2000-SPI
Standard equipment: BNC cable; mains cable; test probe x2; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2 Gs/s
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...20V/div
Time base: 1n...1ks/div
Memory record length: 56Mpts
Kind of display used: LCD TFT 8"
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 200MHz; 5Gsps; 100Mpts; 2n÷1ks/div
Number of channels: 4
Interface: AUX; HDMI; LAN; USB device; USB Host; VGA
Display resolution: 1280x800
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 378x218x120mm
Kind of display used: LCD TFT 10,1"; touch screen
Standard equipment: BNC cable; expansion option MSO2000X-AWG; expansion option MSO2000X-BND; expansion option MSO2000X-PWR; mains cable; test probe x4; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 200MHz
Rise time: ≤1.8ns
Input sensitivity: 500µV/div...10V/div
Time base: 2n...1ks/div
Memory record length: 100Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 300MHz; 5Gsps; 100Mpts; 1n÷1ks/div
Number of channels: 4
Interface: AUX; HDMI; LAN; USB device; USB Host; VGA
Display resolution: 1280x800
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 378x218x120mm
Kind of display used: LCD TFT 10,1"; touch screen
Standard equipment: BNC cable; expansion option MSO2000X-AWG; expansion option MSO2000X-BND; expansion option MSO2000X-PWR; mains cable; test probe x4; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 500µV/div...10V/div
Time base: 1n...1ks/div
Memory record length: 100Mpts

Hersteller: UNI-T
MSO3000CS-S-BODE Accessories for Oscilloscopes - Others

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO3034X; MSO3054X
Test accessories features: arbitrary waveform generator

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Application: for oscilloscopes
Related items: MSO3034X; MSO3054X

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Test acces: expansion option; for oscilloscopes
Type of test accessories: expansion option
Related items: MSO3034X; MSO3054X
Application: for oscilloscopes
Test accessories features: MIL-STD-1553B triggering and decoding

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 5Gsps; 2Mpts; 1n÷1ks/div; ≤1ns
Number of channels: 4
Interface: AUX; HDMI; LAN; USB device; USB Host; VGA
Display resolution: 1280x800
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 378x218x120mm
Kind of display used: LCD TFT 10,1"; touch screen
Standard equipment: BNC cable; mains cable; test probe x4; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; I2C/SPI Serial Decode; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 12bit
Band: 350MHz
Rise time: ≤1ns
Input sensitivity: 500µV/div...10V/div
Time base: 1n...1ks/div
Memory record length: 2Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 5Gsps; 2Mpts; 500p÷1ks/div
Number of channels: 4
Interface: AUX; HDMI; LAN; USB device; USB Host; VGA
Display resolution: 1280x800
Supply voltage: 100...240V AC
Input impedance: 1MΩ/16pF
Dimensions: 378x218x120mm
Kind of display used: LCD TFT 10,1"; touch screen
Standard equipment: BNC cable; mains cable; test probe x4; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; I2C/SPI Serial Decode; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; runt; slope; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 12bit
Band: 500MHz
Rise time: ≤0.8ns
Input sensitivity: 500µV/div...10V/div
Time base: 0.5n...1ks/div
Memory record length: 2Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 150MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 150MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 150MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 150MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 150MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 4
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 150MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 150MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 4
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 150MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 2
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 4
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 250MHz; 2,5Gsps; 70Mpts; LCD TFT 8"
Number of channels: 4
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x195x125mm
Kind of display used: LCD TFT 8"
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Measuring instrument features: digital signal generator; mathematical functions: addition, subtraction, division, multiplication and FFT; MIN/MAX function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 250MHz
Input sensitivity: 1mV/div...20V/div
Time base: 2n...40s/div
Memory record length: 70Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 350MHz
Rise time: ≤1ns
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 2
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 350MHz
Rise time: ≤1ns
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 4
Band: 350MHz
Sampling: 2,5Gsps
Memory record length: 250Mpts
Kind of display used: LCD TFT 8"
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Time base: 1n...1ks/div
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Rise time: ≤1ns
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Dimensions: 370x185x115mm
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Supply voltage: 100...240V AC
Display resolution: 800x480

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 4
Band: 350MHz
Sampling: 2,5Gsps
Memory record length: 250Mpts
Kind of display used: LCD TFT 8"
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Time base: 1n...1ks/div
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Rise time: ≤1ns
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Dimensions: 370x185x115mm
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Supply voltage: 100...240V AC
Display resolution: 800x480
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 350MHz
Rise time: ≤1ns
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 350MHz
Rise time: ≤1ns
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 500MHz
Sampling: 2,5Gsps
Memory record length: 250Mpts
Kind of display used: LCD TFT 8"
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Time base: 1n...1ks/div
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Rise time: ≤750ps
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Dimensions: 370x185x115mm
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Supply voltage: 100...240V AC
Display resolution: 800x480

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 500MHz
Sampling: 2,5Gsps
Memory record length: 250Mpts
Kind of display used: LCD TFT 8"
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Time base: 1n...1ks/div
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Rise time: ≤750ps
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Dimensions: 370x185x115mm
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Supply voltage: 100...240V AC
Display resolution: 800x480
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 500MHz
Rise time: ≤750ps
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 500MHz
Rise time: ≤750ps
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts
Anzahl je Verpackung: 1 Stücke

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 2,5Gsps; 250Mpts; LCD TFT 8"
Number of channels: 4
Related items: MSO/UPO3000CS-AUTO; MSO/UPO3000CS-BND; MSO/UPO3000CS-CAN; MSO/UPO3000CS-CANF; MSO/UPO3000CS-COM; MSO/UPO3000CS-EMBD; MSO/UPO3000CS-FR; MSO/UPO3000CS-I2C; MSO/UPO3000CS-LIN; MSO/UPO3000CS-SPI
Interface: AUX; EXT Trig; LAN; USB device; USB Host; VGA
Display resolution: 800x480
Supply voltage: 100...240V AC
Input impedance: 1MΩ/18pF
Dimensions: 370x185x115mm
Kind of display used: LCD TFT 8"
Standard equipment: BNC cable; mains cable; oscilloscope probe x3; USB cable
Measuring instrument features: arbitrary waveform generator; automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 2,5Gsps
Type of oscilloscope: digital
Trigger: falling-edge; Nth Edge; pattern; pulse; rising-edge; runt; slope; timeout; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Band: 500MHz
Rise time: ≤750ps
Input sensitivity: 1mV/div...1V/div (50Ω); 1mV/div...10V/div (1MΩ)
Time base: 1n...1ks/div
Memory record length: 250Mpts
