TS20100F070S
+1
 		TS20100F070S E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CB23B57DC60D3&compId=TS20100F070S.pdf?ci_sign=e6f3787b12105474c446da43165a682dcf19702c Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 0.1A/48VDC; without lever; SPST-NO
Mounting: THT
Leads: for soldering
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON); ON-(OFF)
Kind of package: reel; tape
Contacts configuration: SPST-NO
Switches features: without lever
Operating temperature: -25...85°C
Body dimensions: 8.6x4.8x3mm
DC contacts rating @R: 0.1A / 48V DC
Max. contact resistance:: 300mΩ
Operating Force: 0.7N
Number of positions: 2
Mechanical durability: 3000000 cycles
Electrical life: 3000000 cycles
Min. insulation resistance: 0.1GΩ
Manufacturer series: TS2
Button marking: blank
auf Bestellung 927 Stücke:
Lieferzeit 14-21 Tag (e)
88+0.82 EUR
106+0.68 EUR
118+0.61 EUR
Mindestbestellmenge: 88
Im Einkaufswagen  Stück im Wert von  UAH
SS0750301F020P1A E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CA7F2017D40D3&compId=SS0750301F020P1A.pdf?ci_sign=580485645aa3cae3c2756e7e405fe843e0c7d67e Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 1.5A/250VAC; with lever; SPDT; OFF-(ON)
Manufacturer series: SS
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPDT
Switches features: with lever
Operating temperature: -25...75°C
Key stroke: 1.6mm
Terminal pitch: 5.08mm
Body dimensions: 12.8x5.75x6.5mm
Max. contact resistance:: 100mΩ
Operating Force: 0.2N
Stable positions number: 1
AC contacts rating @R: 1.5A / 250V AC
Number of positions: 2
Electrical life: 10000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 0.1GΩ
Leads: for soldering; straight
Button marking: blank
Mounting: PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SS0750301F040V1A E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CA83534A220D3&compId=SS0750301F040V1A.pdf?ci_sign=3efa24931148977c67bc92b9b5f3d6fbde731b10 Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 1.5A/250VAC; with lever; SPDT; OFF-(ON)
Manufacturer series: SS
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPDT
Switches features: with lever
Operating temperature: -25...75°C
Key stroke: 1.6mm
Terminal pitch: 5.08mm
Body dimensions: 12.8x5.75x6.5mm
Max. contact resistance:: 100mΩ
Operating Force: 0.4N
Stable positions number: 1
AC contacts rating @R: 1.5A / 250V AC
Number of positions: 2
Electrical life: 10000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 0.1GΩ
Leads: angled; for soldering
Button marking: blank
Mounting: PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP9M2QE
+1
 		800AWSP9M2QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E277534560C7&compId=T833053.pdf?ci_sign=f2f2156e7f30265783fc204e97719b492b6aa34a pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EB773EAA0D3&compId=800AWSP9M2QE.pdf?ci_sign=2600a9fd248859c3917b7d3f1e66638a1ad158ae Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 18.85mm
Body dimensions: 8.13x5.08x13.39mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 313 Stücke:
Lieferzeit 14-21 Tag (e)
19+3.9 EUR
21+3.52 EUR
25+3.19 EUR
50+3.06 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
800SP9B6M6RE 800SP9B6M6RE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1B1BC74A0C7&compId=T811006.pdf?ci_sign=63e1e87be8b9d3872b6fca76a95f9054bff33637 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EF192C9A0D3&compId=800SP9B6M6RE.pdf?ci_sign=01c1b5ed5279c4e1b8cf2a615b3366567cdc8e2d Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 3.53mm
Body dimensions: 8.13x5.08x14.68mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 540 Stücke:
Lieferzeit 14-21 Tag (e)
20+3.7 EUR
22+3.3 EUR
25+3.19 EUR
50+2.76 EUR
100+2.69 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
800SP9B5M2QEH 800SP9B5M2QEH E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1203702A0C7&compId=ST811004.pdf?ci_sign=92ae0dc47ef52ac2fa72a755e198c419c60e89bc pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EF192C720D3&compId=800SP9B5M2QEH.pdf?ci_sign=f5567cb4321e34c31b81ca96bbe9ebd503f3c996 Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 18.17mm
Body dimensions: 8.13x5.08x14.23mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: silver
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 163 Stücke:
Lieferzeit 14-21 Tag (e)
24+3.02 EUR
30+2.39 EUR
Mindestbestellmenge: 24
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP9M6QE 800AWSP9M6QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E24F5A8C60C7&compId=T833005.pdf?ci_sign=19190b1407daa821dc9b1e831b6bab20aec01b40 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8E4D4E0400D3&compId=800AWSP9M6QE.pdf?ci_sign=441d51368abffcb919b7d12e783df6d6d0b195b5 Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 5.46mm
Body dimensions: 8x5.08x13.4mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 176 Stücke:
Lieferzeit 14-21 Tag (e)
17+4.28 EUR
19+3.85 EUR
100+3.4 EUR
Mindestbestellmenge: 17
Im Einkaufswagen  Stück im Wert von  UAH
700SP7B20M6QE 700SP7B20M6QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1F470A700C7&compId=T711010.pdf?ci_sign=222acd2d1be0c3a4d41a26d3e4d4241dc5fa4fce pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8E0E82CD80D3&compId=700SP7B20M6QE.pdf?ci_sign=97eee934494aaf14827b601072281f5d8cf13e88 Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 1A/250VAC; 3A/28VDC; ON-(ON)
Contacts configuration: SPDT
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 5.12mm
Body dimensions: 12.7x6.86x17.8mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 2.94N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Electrical life: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: ON-(ON)
Button shape: prominent; round
auf Bestellung 83 Stücke:
Lieferzeit 14-21 Tag (e)
12+6.33 EUR
13+5.58 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RR534DZ07Z0700 E-SWITCH Category: Rocker Switches
Description: ROCKER; SPST-NO; OFF-(ON); Leads: for soldering
Type of switch: ROCKER
Contacts configuration: SPST-NO
Switching method: OFF-(ON)
Leads: for soldering
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP1T8B13M2QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
Switching method: ON-ON
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for PCB
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 18mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EG2322 E-SWITCH EG2322.pdf Category: Slide Switches
Description: Switch: slide; Pos: 3; ON-ON-ON; THT; Leads: for PCB,angled; EG
Manufacturer series: EG
Contact material: copper
Switching method: ON-ON-ON
Contact plating: silver plated
Type of switch: slide
Mounting: THT
Operating temperature: -20...70°C
Knob height: 7mm
Body dimensions: 20x9.3x10mm
Stable positions number: 3
Number of positions: 3
Mechanical durability: 10000 cycles
Leads: angled; for PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV4F2B11343 E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1FD0ABE37466AFF720E2&compId=ULV4.pdf?ci_sign=548f1ca291a1a19e4533cc73de606d52831044b1 Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Body colour: black
Actuator colour: black
Button marking: blank
Backlight colour: blue
Leads: for soldering
Contacts configuration: SPDT
Manufacturer series: ULV4
Button shape: flat; round
IP rating: IP67
Illumination: LED; ring
Type of switch: vandal resistant
Switching method: ON-(ON)
Mounting: on panel
Contact material: silver
Operating temperature: -20...55°C
Panel thickness: 1...10mm
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø19mm
Body dimensions: Ø22x27.5mm
Max. contact resistance:: 50mΩ
Stable positions number: 1
Number of positions: 2
Operating Force: 2.5N
AC contacts rating @R: 3A / 250V AC
Illumination voltage: 6V
Electrical life: 50000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8F2G11343 E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1FD0ABE3A652A4E580E2&compId=ULV8.pdf?ci_sign=28264d4a171118ca67ec4fad58e938b58455256a Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; DPDT; 3A/250VAC; IP67; ON-ON; blue
Body material: aluminium anodised
Body colour: black
Actuator colour: black
Button marking: blank
Backlight colour: blue
Leads: for soldering
Contacts configuration: DPDT
Manufacturer series: ULV8
Button shape: flat; round
IP rating: IP67
Illumination: LED; ring
Type of switch: vandal resistant
Switching method: ON-ON
Mounting: on panel
Contact material: silver
Operating temperature: -20...55°C
Panel thickness: 1...10mm
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø25mm
Body dimensions: Ø28x29.4mm
Max. contact resistance:: 50mΩ
Stable positions number: 2
Number of positions: 2
Operating Force: 3.5N
AC contacts rating @R: 3A / 250V AC
Illumination voltage: 6V
Electrical life: 50000 cycles
Mechanical durability: 500000 cycles
Min. insulation resistance: 1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1QEH E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8713D56760D3&compId=100DP2T1B1M1QEH.pdf?ci_sign=f4125670640e5cfe426d3e3cecd7a9040663800d Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x10.41mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Panel cutout diameter: 6.35mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1RE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 0.02A/20VAC; 0.02A/20VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 20mA / 20V AC
DC contacts rating @R: 20mA / 20V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: gold-plated; nickel plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Panel cutout diameter: 6.35mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T7B13M1QE E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467 Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 13mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RB547A1100-136 E-SWITCH pVersion=0046&contRep=ZT&docId=005056AB281E1EDE9FC5553657D020D6&compId=RB5.pdf?ci_sign=df439e9124ce65e273d6ad1f2e927e084ec2ca69 Category: Rocker Switches
Description: ROCKER; DPDT; Pos: 3; ON-OFF-(ON); 16A/125VAC; black; IP67; LED; RB5
Type of switch: ROCKER
Contacts configuration: DPDT
Number of positions: 3
Stable positions number: 2
Switching method: ON-OFF-(ON)
AC contacts rating @R: 16A / 125V AC
Key button colour: black
IP rating: IP67
Illumination: LED
Manufacturer series: RB5
Backlight colour: red/green
Illumination voltage: 125V
Max. contact resistance:: 20mΩ
Body colour: black
Leads: connectors
Leads dimensions: 6.3x0.8mm
Electrical life: 10000 cycles
Mounting hole diameter: 30.2x22mm
Body dimensions: 29x21.5x25mm
Min. insulation resistance: 0.1GΩ
Mounting: on panel
Operating temperature: 0...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M2RE 800AWSP8M2RE E-SWITCH 800AWSP8M2RE.pdf Category: Detect Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.02A/20VDC; 0.02A/20VAC; 800A
Mounting: THT
DC contacts rating @R: 20mA / 20V DC
Stable positions number: 1
Number of positions: 2
Mechanical durability: 50000 cycles
Manufacturer series: 800A
Min. insulation resistance: 1GΩ
Leads: for PCB
Contact material: copper
Contact plating: gold-plated; nickel plated
Switching method: ON-(ON)
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Body dimensions: 8.13x5.08x8.89mm
Max. contact resistance:: 10mΩ
AC contacts rating @R: 20mA / 20V AC
auf Bestellung 883 Stücke:
Lieferzeit 14-21 Tag (e)
16+4.55 EUR
25+4.23 EUR
50+4.02 EUR
100+3.78 EUR
Mindestbestellmenge: 16
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M6QE E-SWITCH T833025.pdf 800AWSP8M6QE.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 1A/250VAC; 3A/28VDC; ON-(ON)
Mounting: THT
DC contacts rating @R: 3A / 28V DC
Stable positions number: 1
Operating Force: 1.96N
Number of positions: 2
Mechanical durability: 50000 cycles
Leads: angled; for PCB
Contact material: copper
Contact plating: silver plated
Switching method: ON-(ON)
Button shape: prominent; round
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Button height: 5.9mm
Body dimensions: 8.13x5.08x13.4mm
Max. contact resistance:: 20mΩ
AC contacts rating @R: 1A / 250V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M6RE E-SWITCH 800AWSP8M6RE.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; ON-(ON); Illumin: none; 1GΩ; THT
Mounting: THT
Stable positions number: 1
Operating Force: 2N
Number of positions: 2
Mechanical durability: 50000 cycles
Manufacturer series: 800A
Min. insulation resistance: 1GΩ
Leads: for soldering
Contact material: copper alloy
Contact plating: gold-plated
Illumination: none
Switching method: ON-(ON)
Button shape: round
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Body dimensions: 9.29x8.13x5.08mm
Max. contact resistance:: 20mΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS PV0H240SS E-SWITCH PV0.pdf 52-PV0H240SS.pdf PV0H240SS.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Mechanical durability: 1000000 cycles
auf Bestellung 107 Stücke:
Lieferzeit 14-21 Tag (e)
8+9.95 EUR
10+9.22 EUR
25+8.02 EUR
50+7.56 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-331 PV0H240SS-331 E-SWITCH PV0.pdf 52-PV0H240SS331.pdf PV0H240SS-331.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: green
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
auf Bestellung 113 Stücke:
Lieferzeit 14-21 Tag (e)
6+12.31 EUR
10+11.88 EUR
25+11.3 EUR
50+10.85 EUR
100+10.42 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-231 PV0H240SS-231 E-SWITCH PV0.pdf 52-PV0H240SS231.pdf PV0H240SS-231.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: green
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
2+35.75 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3R1 E-SWITCH PV0.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: RGB
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-301 E-SWITCH PV0H240SS-301.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: white
Leads: connectors; for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Manufacturer series: PV0
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Key stroke: 1.5mm
Operating temperature: -20...55°C
Contact plating: silver plated
Button marking: blank
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-311 E-SWITCH 52-PV0H240SS311.pdf PV0H240SS-311.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: red
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 1.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-201 E-SWITCH PV0H240SS-201.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; white; 2.8VDC; PV0; on panel
Type of switch: vandal resistant
Number of positions: 2
Backlight colour: white
Max. contact resistance:: 50mΩ
Manufacturer series: PV0
Mounting: on panel
Illumination voltage: 2.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-241 E-SWITCH 52-PV0H240SS241.pdf PV0H240SS-241.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: blue
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-321 E-SWITCH PV0.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: orange
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Illumination voltage: 1.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3G1 E-SWITCH PV0H240SS-3G1.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: green; red
Leads: connectors; for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Manufacturer series: PV0
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Key stroke: 1.5mm
Operating temperature: -20...55°C
Contact plating: silver plated
Button marking: blank
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3K1 E-SWITCH PV0.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: orange/green
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV4F23011-3K1-M01 E-SWITCH PV4F23011-3K1-M01.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 2A/24VDC; IP65; ON-ON; 2.8mm
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 2
Contacts configuration: SPDT
DC contacts rating @R: 2A / 24V DC
IP rating: IP65
Switching method: ON-ON
Illumination: LED; ring
Backlight colour: orange/green
Leads: connectors; for soldering
Leads dimensions: 2.8mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body colour: black
Manufacturer series: PV4
Contact plating: silver plated
Actuator colour: black
Button marking: POWER
Min. insulation resistance: 1GΩ
Panel thickness: max. 11mm
Mounting: on panel
Body dimensions: Ø22x30.7mm
Button height: 1.8mm
Key stroke: 2.8mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EG4208A
+1
 		EG4208A E-SWITCH EG4208A.pdf Category: Slide Switches
Description: Switch: slide; Pos: 2; 4PDT; BBM (non-shorting),ON-ON; THT; EG
Operating temperature: -20...70°C
Leads: angled; for PCB
Switching method: BBM (non-shorting); ON-ON
Contact material: copper
Mounting: THT
Contact plating: silver plated
Type of switch: slide
Terminal pitch: 2mm
Row pitch: 2.5mm
Knob height: 6mm
Body dimensions: 15x6x7.5mm
Stable positions number: 2
Number of positions: 2
Mechanical durability: 10000 cycles
Contacts configuration: 4PDT
Manufacturer series: EG
auf Bestellung 608 Stücke:
Lieferzeit 14-21 Tag (e)
47+1.53 EUR
57+1.27 EUR
Mindestbestellmenge: 47
Im Einkaufswagen  Stück im Wert von  UAH
LP4OA1PBCTG LP4OA1PBCTG E-SWITCH B240023.pdf LP4OA1PBCTG.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/30VDC; ON-(ON); Illumin: LED
Type of switch: push-button
Stable positions number: 1
Actuator colour: transparent
Illumination: LED
Button shape: round
Number of positions: 2
Operating temperature: -20...70°C
Leads: for PCB
Contacts configuration: DPDT
Backlight colour: green
Switching method: ON-(ON)
Mounting: THT
Button height: 19.7mm
Body dimensions: 7.5x8.7x7.3mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 0.1A / 30V DC
Operating Force: 2.45N
Mechanical durability: 50000 cycles
Body colour: black
auf Bestellung 938 Stücke:
Lieferzeit 14-21 Tag (e)
20+3.75 EUR
21+3.47 EUR
25+3.1 EUR
50+3.03 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
LP4OA1PBCTR LP4OA1PBCTR E-SWITCH B240001.pdf LP4OA1PBCTR.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/30VDC; ON-(ON); Illumin: LED
Type of switch: push-button
Stable positions number: 1
Actuator colour: transparent
Illumination: LED
Button shape: round
Number of positions: 2
Operating temperature: -20...70°C
Leads: for PCB
Contacts configuration: DPDT
Backlight colour: red
Switching method: ON-(ON)
Mounting: THT
Button height: 19.7mm
Body dimensions: 7.5x8.7x7.3mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 0.1A / 30V DC
Operating Force: 2.45N
Mechanical durability: 50000 cycles
Body colour: black
auf Bestellung 177 Stücke:
Lieferzeit 14-21 Tag (e)
26+2.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
ULV4F23SS514 E-SWITCH ULV4.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-ON; red
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 2
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-ON
Illumination: LED
Backlight colour: red
Illumination voltage: 12V
Leads: for soldering
Leads dimensions: 2.8x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV4
Contact material: silver
Button material: stainless steel
Actuator colour: silver
Button marking: POWER
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø22x27.5mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1000-116 E-SWITCH RSC141D1000-116.pdf Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; transparent; LED; RSC
Manufacturer series: RSC
Body colour: black
Button marking: blank
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: LED
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Backlight colour: red
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: transparent
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1A81 E-SWITCH RSC141D1A81.pdf Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; black-red; none; RSC
Manufacturer series: RSC
Body colour: black
Button marking: O-I
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: none
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black-red
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1121 E-SWITCH RSC141D1121.pdf Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; black; none; RSC
Manufacturer series: RSC
Body colour: black
Button marking: O-I
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: none
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC144D1100 E-SWITCH RSC144D1100.pdf Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; OFF-(ON); 16A/250VAC; none; RSC; Body: black
Manufacturer series: RSC
Body colour: black
Leads: connectors
Illumination: none
Type of switch: ROCKER
Switching method: OFF-(ON)
Mounting: on panel
Contacts configuration: SPST-NO
Operating temperature: -20...65°C
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 1
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC145C1100 E-SWITCH RSC145C1100.pdf Category: Rocker Switches
Description: ROCKER; SPST; Pos: 3; ON-OFF-ON; 15A/125VAC; black; RSC; Body: black
Manufacturer series: RSC
Body colour: black
Leads: connectors
Type of switch: ROCKER
Switching method: ON-OFF-ON
Mounting: on panel
Contacts configuration: SPST
Operating temperature: -20...65°C
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 3
Number of positions: 3
AC contacts rating @R: 15A / 125V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PS1023ABLK PS1023ABLK E-SWITCH PS1023ABLK.pdf Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST; 3A/125VDC; OFF-(ON); on panel
Mounting: on panel
Operating temperature: -20...70°C
Button shape: square
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPST
Body dimensions: 15.5x34mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 3A / 125V DC
Stable positions number: 1
Number of positions: 2
Mechanical durability: 6000 cycles
Leads: for soldering
Type of switch: push-button
auf Bestellung 887 Stücke:
Lieferzeit 14-21 Tag (e)
38+1.92 EUR
46+1.57 EUR
54+1.34 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS341 E-SWITCH ULV8.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: blue
Illumination voltage: 3V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS331 E-SWITCH ULV8.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: green
Illumination voltage: 3V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS344 E-SWITCH ULV8FPBSS344.pdf Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: blue
Illumination voltage: 12V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL59BF160Q TL59BF160Q E-SWITCH J100567.pdf TL59BF160Q.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; THT; none; 1.57N; 9.5mm
Type of switch: microswitch TACT
Contacts configuration: SPST
Number of positions: 2
Stable positions number: 1
DC contacts rating @R: 50mA / 12V DC
Mounting: THT
Illumination: none
Operating Force: 1.57N
Body dimensions: 6.2x6.2x3.6mm
Button height: 9.5mm
Switching method: OFF-(ON)
Terminal pitch: 5mm
Button shape: round
Actuator colour: black
Key stroke: 0.25mm
Leads: round pin
Max. contact resistance:: 100mΩ
Mechanical durability: 80000 cycles
auf Bestellung 1364 Stücke:
Lieferzeit 14-21 Tag (e)
193+0.37 EUR
211+0.34 EUR
228+0.31 EUR
244+0.29 EUR
264+0.27 EUR
295+0.24 EUR
500+0.22 EUR
Mindestbestellmenge: 193
Im Einkaufswagen  Stück im Wert von  UAH
TL6275AA2PQNR E-SWITCH T062750.pdf TL6275AA2PQNR.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; THT; LED; 3.43N; 7.2mm
Type of switch: microswitch TACT
Contacts configuration: SPST
Switching method: OFF-(ON)
Leads: flat pin
Mechanical durability: 100000 cycles
Operating temperature: -20...70°C
Operating Force: 3.43N
Mounting: THT
Illumination: LED
Button shape: square
Key stroke: 0.25mm
Button height: 7.2mm
Terminal pitch: 4.5mm
Body dimensions: 8x8x7.2mm
DC contacts rating @R: 50mA / 12V DC
Max. contact resistance:: 100mΩ
Stable positions number: 1
Number of positions: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
KOM4 E-SWITCH KOM4.pdf Category: Key Switches and Locks
Description: Accessories: safety cover; KO
Manufacturer series: KO
Type of switch accessories: safety cover
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1015AF160QG
+1
 		TL1015AF160QG E-SWITCH P420000.pdf TL1015AF160QG.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMT; 1.57N; 2mm
Operating temperature: -20...70°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMT
Switching method: OFF-(ON)
Button shape: round
Key stroke: 0.2mm
Button height: 2mm
Body dimensions: 3.9x2.9x1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Actuator colour: ivory
auf Bestellung 2710 Stücke:
Lieferzeit 14-21 Tag (e)
135+0.53 EUR
Mindestbestellmenge: 135
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF500AQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 4.9N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 4.9N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 100000 cycles
Actuator colour: brown
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF200AQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.96N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.96N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABAF260QG E-SWITCH TL1017v2.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 2.55N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 2.55N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABBF160QG E-SWITCH TL1017v2.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 1.57N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with ground terminal; with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF160AQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.57N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF160BQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.57N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF350BQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 3.43N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 3.43N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Actuator colour: blue
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABAF160QG E-SWITCH TL1017v2.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 1.57N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABBF260QG E-SWITCH TL1017v2.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 2.55N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with ground terminal; with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 2.55N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF200BQJ E-SWITCH TL1030.pdf Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.96N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.96N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TS20100F070S pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CB23B57DC60D3&compId=TS20100F070S.pdf?ci_sign=e6f3787b12105474c446da43165a682dcf19702c
TS20100F070S
+1
Hersteller: E-SWITCH
Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 0.1A/48VDC; without lever; SPST-NO
Mounting: THT
Leads: for soldering
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON); ON-(OFF)
Kind of package: reel; tape
Contacts configuration: SPST-NO
Switches features: without lever
Operating temperature: -25...85°C
Body dimensions: 8.6x4.8x3mm
DC contacts rating @R: 0.1A / 48V DC
Max. contact resistance:: 300mΩ
Operating Force: 0.7N
Number of positions: 2
Mechanical durability: 3000000 cycles
Electrical life: 3000000 cycles
Min. insulation resistance: 0.1GΩ
Manufacturer series: TS2
Button marking: blank
auf Bestellung 927 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
88+0.82 EUR
106+0.68 EUR
118+0.61 EUR
Mindestbestellmenge: 88
Im Einkaufswagen  Stück im Wert von  UAH
SS0750301F020P1A pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CA7F2017D40D3&compId=SS0750301F020P1A.pdf?ci_sign=580485645aa3cae3c2756e7e405fe843e0c7d67e
Hersteller: E-SWITCH
Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 1.5A/250VAC; with lever; SPDT; OFF-(ON)
Manufacturer series: SS
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPDT
Switches features: with lever
Operating temperature: -25...75°C
Key stroke: 1.6mm
Terminal pitch: 5.08mm
Body dimensions: 12.8x5.75x6.5mm
Max. contact resistance:: 100mΩ
Operating Force: 0.2N
Stable positions number: 1
AC contacts rating @R: 1.5A / 250V AC
Number of positions: 2
Electrical life: 10000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 0.1GΩ
Leads: for soldering; straight
Button marking: blank
Mounting: PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
SS0750301F040V1A pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948CA83534A220D3&compId=SS0750301F040V1A.pdf?ci_sign=3efa24931148977c67bc92b9b5f3d6fbde731b10
Hersteller: E-SWITCH
Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 1.5A/250VAC; with lever; SPDT; OFF-(ON)
Manufacturer series: SS
Type of switch: microswitch SNAP ACTION
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPDT
Switches features: with lever
Operating temperature: -25...75°C
Key stroke: 1.6mm
Terminal pitch: 5.08mm
Body dimensions: 12.8x5.75x6.5mm
Max. contact resistance:: 100mΩ
Operating Force: 0.4N
Stable positions number: 1
AC contacts rating @R: 1.5A / 250V AC
Number of positions: 2
Electrical life: 10000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 0.1GΩ
Leads: angled; for soldering
Button marking: blank
Mounting: PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP9M2QE pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E277534560C7&compId=T833053.pdf?ci_sign=f2f2156e7f30265783fc204e97719b492b6aa34a pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EB773EAA0D3&compId=800AWSP9M2QE.pdf?ci_sign=2600a9fd248859c3917b7d3f1e66638a1ad158ae
800AWSP9M2QE
+1
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 18.85mm
Body dimensions: 8.13x5.08x13.39mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 313 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
19+3.9 EUR
21+3.52 EUR
25+3.19 EUR
50+3.06 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
800SP9B6M6RE pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1B1BC74A0C7&compId=T811006.pdf?ci_sign=63e1e87be8b9d3872b6fca76a95f9054bff33637 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EF192C9A0D3&compId=800SP9B6M6RE.pdf?ci_sign=01c1b5ed5279c4e1b8cf2a615b3366567cdc8e2d
800SP9B6M6RE
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 3.53mm
Body dimensions: 8.13x5.08x14.68mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 540 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
20+3.7 EUR
22+3.3 EUR
25+3.19 EUR
50+2.76 EUR
100+2.69 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
800SP9B5M2QEH pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1203702A0C7&compId=ST811004.pdf?ci_sign=92ae0dc47ef52ac2fa72a755e198c419c60e89bc pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8EF192C720D3&compId=800SP9B5M2QEH.pdf?ci_sign=f5567cb4321e34c31b81ca96bbe9ebd503f3c996
800SP9B5M2QEH
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 18.17mm
Body dimensions: 8.13x5.08x14.23mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: silver
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 163 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
24+3.02 EUR
30+2.39 EUR
Mindestbestellmenge: 24
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP9M6QE pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E24F5A8C60C7&compId=T833005.pdf?ci_sign=19190b1407daa821dc9b1e831b6bab20aec01b40 pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8E4D4E0400D3&compId=800AWSP9M6QE.pdf?ci_sign=441d51368abffcb919b7d12e783df6d6d0b195b5
800AWSP9M6QE
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST-NO; 1A/250VAC; 3A/28VDC; OFF-(ON)
Contacts configuration: SPST-NO
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 5.46mm
Body dimensions: 8x5.08x13.4mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 1.96N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Mechanical durability: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: OFF-(ON)
Button shape: prominent; round
auf Bestellung 176 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
17+4.28 EUR
19+3.85 EUR
100+3.4 EUR
Mindestbestellmenge: 17
Im Einkaufswagen  Stück im Wert von  UAH
700SP7B20M6QE pVersion=0046&contRep=ZT&docId=005056AB90B41EDBB895E1F470A700C7&compId=T711010.pdf?ci_sign=222acd2d1be0c3a4d41a26d3e4d4241dc5fa4fce pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8E0E82CD80D3&compId=700SP7B20M6QE.pdf?ci_sign=97eee934494aaf14827b601072281f5d8cf13e88
700SP7B20M6QE
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 1A/250VAC; 3A/28VDC; ON-(ON)
Contacts configuration: SPDT
Mounting: THT
Leads: angled; for PCB
Operating temperature: -30...85°C
Type of switch: push-button
Button height: 5.12mm
Body dimensions: 12.7x6.86x17.8mm
Max. contact resistance:: 20mΩ
Stable positions number: 1
AC contacts rating @R: 1A / 250V AC
Operating Force: 2.94N
Number of positions: 2
DC contacts rating @R: 3A / 28V DC
Electrical life: 50000 cycles
Contact material: copper
Contact plating: silver plated
Illumination: none
Switching method: ON-(ON)
Button shape: prominent; round
auf Bestellung 83 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
12+6.33 EUR
13+5.58 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
RR534DZ07Z0700
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST-NO; OFF-(ON); Leads: for soldering
Type of switch: ROCKER
Contacts configuration: SPST-NO
Switching method: OFF-(ON)
Leads: for soldering
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP1T8B13M2QE pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467
Hersteller: E-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-ON; 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 2
Contacts configuration: DPDT
Switching method: ON-ON
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for PCB
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 18mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EG2322 EG2322.pdf
Hersteller: E-SWITCH
Category: Slide Switches
Description: Switch: slide; Pos: 3; ON-ON-ON; THT; Leads: for PCB,angled; EG
Manufacturer series: EG
Contact material: copper
Switching method: ON-ON-ON
Contact plating: silver plated
Type of switch: slide
Mounting: THT
Operating temperature: -20...70°C
Knob height: 7mm
Body dimensions: 20x9.3x10mm
Stable positions number: 3
Number of positions: 3
Mechanical durability: 10000 cycles
Leads: angled; for PCB
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV4F2B11343 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0ABE37466AFF720E2&compId=ULV4.pdf?ci_sign=548f1ca291a1a19e4533cc73de606d52831044b1
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Body colour: black
Actuator colour: black
Button marking: blank
Backlight colour: blue
Leads: for soldering
Contacts configuration: SPDT
Manufacturer series: ULV4
Button shape: flat; round
IP rating: IP67
Illumination: LED; ring
Type of switch: vandal resistant
Switching method: ON-(ON)
Mounting: on panel
Contact material: silver
Operating temperature: -20...55°C
Panel thickness: 1...10mm
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø19mm
Body dimensions: Ø22x27.5mm
Max. contact resistance:: 50mΩ
Stable positions number: 1
Number of positions: 2
Operating Force: 2.5N
AC contacts rating @R: 3A / 250V AC
Illumination voltage: 6V
Electrical life: 50000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8F2G11343 pVersion=0046&contRep=ZT&docId=005056AB281E1FD0ABE3A652A4E580E2&compId=ULV8.pdf?ci_sign=28264d4a171118ca67ec4fad58e938b58455256a
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; DPDT; 3A/250VAC; IP67; ON-ON; blue
Body material: aluminium anodised
Body colour: black
Actuator colour: black
Button marking: blank
Backlight colour: blue
Leads: for soldering
Contacts configuration: DPDT
Manufacturer series: ULV8
Button shape: flat; round
IP rating: IP67
Illumination: LED; ring
Type of switch: vandal resistant
Switching method: ON-ON
Mounting: on panel
Contact material: silver
Operating temperature: -20...55°C
Panel thickness: 1...10mm
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø25mm
Body dimensions: Ø28x29.4mm
Max. contact resistance:: 50mΩ
Stable positions number: 2
Number of positions: 2
Operating Force: 3.5N
AC contacts rating @R: 3A / 250V AC
Illumination voltage: 6V
Electrical life: 50000 cycles
Mechanical durability: 500000 cycles
Min. insulation resistance: 1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1QEH pVersion=0046&contRep=ZT&docId=005056AB281E1EDD948C8713D56760D3&compId=100DP2T1B1M1QEH.pdf?ci_sign=f4125670640e5cfe426d3e3cecd7a9040663800d
Hersteller: E-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x10.41mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1QE pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467
Hersteller: E-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Panel cutout diameter: 6.35mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T1B1M1RE pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467
Hersteller: E-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 0.02A/20VAC; 0.02A/20VDC
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 20mA / 20V AC
DC contacts rating @R: 20mA / 20V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: gold-plated; nickel plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 10.41mm
Panel cutout diameter: 6.35mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
100DP2T7B13M1QE pVersion=0046&contRep=ZT&docId=005056AB281E1EDEAED49BB6CD5B60D6&compId=100series.pdf?ci_sign=fff4f96362b400ea8e51971f72c0bb9982a5d467
Hersteller: E-SWITCH
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; DPDT; ON-(ON); 2A/250VAC; 5A/28VDC; 100
Type of switch: toggle
Number of positions: 2
Stable positions number: 1
Contacts configuration: DPDT
Switching method: ON-(ON)
AC contacts rating @R: 2A / 250V AC
DC contacts rating @R: 5A / 28V DC
Leads: for soldering
Manufacturer series: 100
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Body dimensions: 12.7x11.43x8.89mm
Electrical life: 40000 cycles
Contact plating: silver plated
Min. insulation resistance: 1GΩ
Contact material: copper
Mounting: on panel
Lever length: 13mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RB547A1100-136 pVersion=0046&contRep=ZT&docId=005056AB281E1EDE9FC5553657D020D6&compId=RB5.pdf?ci_sign=df439e9124ce65e273d6ad1f2e927e084ec2ca69
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; DPDT; Pos: 3; ON-OFF-(ON); 16A/125VAC; black; IP67; LED; RB5
Type of switch: ROCKER
Contacts configuration: DPDT
Number of positions: 3
Stable positions number: 2
Switching method: ON-OFF-(ON)
AC contacts rating @R: 16A / 125V AC
Key button colour: black
IP rating: IP67
Illumination: LED
Manufacturer series: RB5
Backlight colour: red/green
Illumination voltage: 125V
Max. contact resistance:: 20mΩ
Body colour: black
Leads: connectors
Leads dimensions: 6.3x0.8mm
Electrical life: 10000 cycles
Mounting hole diameter: 30.2x22mm
Body dimensions: 29x21.5x25mm
Min. insulation resistance: 0.1GΩ
Mounting: on panel
Operating temperature: 0...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M2RE 800AWSP8M2RE.pdf
800AWSP8M2RE
Hersteller: E-SWITCH
Category: Detect Switches
Description: Switch: push-button; Pos: 2; SPDT; 0.02A/20VDC; 0.02A/20VAC; 800A
Mounting: THT
DC contacts rating @R: 20mA / 20V DC
Stable positions number: 1
Number of positions: 2
Mechanical durability: 50000 cycles
Manufacturer series: 800A
Min. insulation resistance: 1GΩ
Leads: for PCB
Contact material: copper
Contact plating: gold-plated; nickel plated
Switching method: ON-(ON)
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Body dimensions: 8.13x5.08x8.89mm
Max. contact resistance:: 10mΩ
AC contacts rating @R: 20mA / 20V AC
auf Bestellung 883 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
16+4.55 EUR
25+4.23 EUR
50+4.02 EUR
100+3.78 EUR
Mindestbestellmenge: 16
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M6QE T833025.pdf 800AWSP8M6QE.pdf
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; 1A/250VAC; 3A/28VDC; ON-(ON)
Mounting: THT
DC contacts rating @R: 3A / 28V DC
Stable positions number: 1
Operating Force: 1.96N
Number of positions: 2
Mechanical durability: 50000 cycles
Leads: angled; for PCB
Contact material: copper
Contact plating: silver plated
Switching method: ON-(ON)
Button shape: prominent; round
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Button height: 5.9mm
Body dimensions: 8.13x5.08x13.4mm
Max. contact resistance:: 20mΩ
AC contacts rating @R: 1A / 250V AC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
800AWSP8M6RE 800AWSP8M6RE.pdf
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPDT; ON-(ON); Illumin: none; 1GΩ; THT
Mounting: THT
Stable positions number: 1
Operating Force: 2N
Number of positions: 2
Mechanical durability: 50000 cycles
Manufacturer series: 800A
Min. insulation resistance: 1GΩ
Leads: for soldering
Contact material: copper alloy
Contact plating: gold-plated
Illumination: none
Switching method: ON-(ON)
Button shape: round
Type of switch: push-button
Contacts configuration: SPDT
Operating temperature: -30...85°C
Body dimensions: 9.29x8.13x5.08mm
Max. contact resistance:: 20mΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS PV0.pdf 52-PV0H240SS.pdf PV0H240SS.pdf
PV0H240SS
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Mechanical durability: 1000000 cycles
auf Bestellung 107 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
8+9.95 EUR
10+9.22 EUR
25+8.02 EUR
50+7.56 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-331 PV0.pdf 52-PV0H240SS331.pdf PV0H240SS-331.pdf
PV0H240SS-331
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: green
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
auf Bestellung 113 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
6+12.31 EUR
10+11.88 EUR
25+11.3 EUR
50+10.85 EUR
100+10.42 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-231 PV0.pdf 52-PV0H240SS231.pdf PV0H240SS-231.pdf
PV0H240SS-231
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: green
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
2+35.75 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3R1 PV0.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: RGB
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-301 PV0H240SS-301.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: white
Leads: connectors; for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Manufacturer series: PV0
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Key stroke: 1.5mm
Operating temperature: -20...55°C
Contact plating: silver plated
Button marking: blank
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-311 52-PV0H240SS311.pdf PV0H240SS-311.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: red
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 1.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-201 PV0H240SS-201.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; white; 2.8VDC; PV0; on panel
Type of switch: vandal resistant
Number of positions: 2
Backlight colour: white
Max. contact resistance:: 50mΩ
Manufacturer series: PV0
Mounting: on panel
Illumination voltage: 2.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-241 52-PV0H240SS241.pdf PV0H240SS-241.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED
Backlight colour: blue
Leads: for soldering
Electrical life: 200000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent
Mounting hole diameter: Ø12mm
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Mounting: on panel
Operating temperature: -20...55°C
Button material: stainless steel
Ring shape: rounded
Illumination voltage: 2.8V DC
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-321 PV0.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: orange
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Illumination voltage: 1.8V DC
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3G1 PV0H240SS-3G1.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP65; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP65
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: green; red
Leads: connectors; for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Manufacturer series: PV0
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Key stroke: 1.5mm
Operating temperature: -20...55°C
Contact plating: silver plated
Button marking: blank
Mechanical durability: 1000000 cycles
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV0H240SS-3K1 PV0.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPST-NO
DC contacts rating @R: 2A / 36V DC
IP rating: IP67
Switching method: OFF-(ON)
Illumination: LED; ring
Backlight colour: orange/green
Leads: for soldering
Leads dimensions: 2x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 4N
Button shape: prominent; round
Mounting hole diameter: Ø12mm
Body colour: silver
Body material: stainless steel
Manufacturer series: PV0
Contact material: silver
Actuator colour: silver
Min. insulation resistance: 1GΩ
Panel thickness: 1...6mm
Mounting: on panel
Body dimensions: Ø14x19.5mm
Key stroke: 1.5mm
Operating temperature: -40...85°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PV4F23011-3K1-M01 PV4F23011-3K1-M01.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 2A/24VDC; IP65; ON-ON; 2.8mm
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 2
Contacts configuration: SPDT
DC contacts rating @R: 2A / 24V DC
IP rating: IP65
Switching method: ON-ON
Illumination: LED; ring
Backlight colour: orange/green
Leads: connectors; for soldering
Leads dimensions: 2.8mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body colour: black
Manufacturer series: PV4
Contact plating: silver plated
Actuator colour: black
Button marking: POWER
Min. insulation resistance: 1GΩ
Panel thickness: max. 11mm
Mounting: on panel
Body dimensions: Ø22x30.7mm
Button height: 1.8mm
Key stroke: 2.8mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EG4208A EG4208A.pdf
EG4208A
+1
Hersteller: E-SWITCH
Category: Slide Switches
Description: Switch: slide; Pos: 2; 4PDT; BBM (non-shorting),ON-ON; THT; EG
Operating temperature: -20...70°C
Leads: angled; for PCB
Switching method: BBM (non-shorting); ON-ON
Contact material: copper
Mounting: THT
Contact plating: silver plated
Type of switch: slide
Terminal pitch: 2mm
Row pitch: 2.5mm
Knob height: 6mm
Body dimensions: 15x6x7.5mm
Stable positions number: 2
Number of positions: 2
Mechanical durability: 10000 cycles
Contacts configuration: 4PDT
Manufacturer series: EG
auf Bestellung 608 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
47+1.53 EUR
57+1.27 EUR
Mindestbestellmenge: 47
Im Einkaufswagen  Stück im Wert von  UAH
LP4OA1PBCTG B240023.pdf LP4OA1PBCTG.pdf
LP4OA1PBCTG
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/30VDC; ON-(ON); Illumin: LED
Type of switch: push-button
Stable positions number: 1
Actuator colour: transparent
Illumination: LED
Button shape: round
Number of positions: 2
Operating temperature: -20...70°C
Leads: for PCB
Contacts configuration: DPDT
Backlight colour: green
Switching method: ON-(ON)
Mounting: THT
Button height: 19.7mm
Body dimensions: 7.5x8.7x7.3mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 0.1A / 30V DC
Operating Force: 2.45N
Mechanical durability: 50000 cycles
Body colour: black
auf Bestellung 938 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
20+3.75 EUR
21+3.47 EUR
25+3.1 EUR
50+3.03 EUR
Mindestbestellmenge: 20
Im Einkaufswagen  Stück im Wert von  UAH
LP4OA1PBCTR B240001.pdf LP4OA1PBCTR.pdf
LP4OA1PBCTR
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; DPDT; 0.1A/30VDC; ON-(ON); Illumin: LED
Type of switch: push-button
Stable positions number: 1
Actuator colour: transparent
Illumination: LED
Button shape: round
Number of positions: 2
Operating temperature: -20...70°C
Leads: for PCB
Contacts configuration: DPDT
Backlight colour: red
Switching method: ON-(ON)
Mounting: THT
Button height: 19.7mm
Body dimensions: 7.5x8.7x7.3mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 0.1A / 30V DC
Operating Force: 2.45N
Mechanical durability: 50000 cycles
Body colour: black
auf Bestellung 177 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
26+2.8 EUR
Mindestbestellmenge: 26
Im Einkaufswagen  Stück im Wert von  UAH
ULV4F23SS514 ULV4.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-ON; red
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 2
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-ON
Illumination: LED
Backlight colour: red
Illumination voltage: 12V
Leads: for soldering
Leads dimensions: 2.8x0.5mm
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 500000 cycles
Button shape: flat; round
Mounting hole diameter: Ø19mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV4
Contact material: silver
Button material: stainless steel
Actuator colour: silver
Button marking: POWER
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø22x27.5mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1000-116 RSC141D1000-116.pdf
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; transparent; LED; RSC
Manufacturer series: RSC
Body colour: black
Button marking: blank
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: LED
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Backlight colour: red
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: transparent
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1A81 RSC141D1A81.pdf
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; black-red; none; RSC
Manufacturer series: RSC
Body colour: black
Button marking: O-I
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: none
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black-red
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC141D1121 RSC141D1121.pdf
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; ON-OFF; 16A/250VAC; black; none; RSC
Manufacturer series: RSC
Body colour: black
Button marking: O-I
Leads: connectors
Contact material: copper
Contact plating: silver plated
Illumination: none
Type of switch: ROCKER
Switching method: ON-OFF
Mounting: on panel
Button shape: rectangular
Contacts configuration: SPST-NO
Flammability rating: UL94V-2
Operating temperature: -20...105°C
Button height: 7.8mm
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3x0.8mm
Terminal pitch: 6.9mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 2
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC144D1100 RSC144D1100.pdf
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST-NO; Pos: 2; OFF-(ON); 16A/250VAC; none; RSC; Body: black
Manufacturer series: RSC
Body colour: black
Leads: connectors
Illumination: none
Type of switch: ROCKER
Switching method: OFF-(ON)
Mounting: on panel
Contacts configuration: SPST-NO
Operating temperature: -20...65°C
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 1
Number of positions: 2
AC contacts rating @R: 16A / 250V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
RSC145C1100 RSC145C1100.pdf
Hersteller: E-SWITCH
Category: Rocker Switches
Description: ROCKER; SPST; Pos: 3; ON-OFF-ON; 15A/125VAC; black; RSC; Body: black
Manufacturer series: RSC
Body colour: black
Leads: connectors
Type of switch: ROCKER
Switching method: ON-OFF-ON
Mounting: on panel
Contacts configuration: SPST
Operating temperature: -20...65°C
Body dimensions: 31.5x16.7x20.5mm
Leads dimensions: 6.3mm
Max. contact resistance:: 20mΩ
Mounting hole diameter: 28.6x13.9mm
Stable positions number: 3
Number of positions: 3
AC contacts rating @R: 15A / 125V AC
Electrical life: 10000 cycles
Min. insulation resistance: 0.1GΩ
Key button colour: black
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PS1023ABLK PS1023ABLK.pdf
PS1023ABLK
Hersteller: E-SWITCH
Category: Standard Switches
Description: Switch: push-button; Pos: 2; SPST; 3A/125VDC; OFF-(ON); on panel
Mounting: on panel
Operating temperature: -20...70°C
Button shape: square
Illumination: none
Switching method: OFF-(ON)
Contacts configuration: SPST
Body dimensions: 15.5x34mm
Max. contact resistance:: 50mΩ
DC contacts rating @R: 3A / 125V DC
Stable positions number: 1
Number of positions: 2
Mechanical durability: 6000 cycles
Leads: for soldering
Type of switch: push-button
auf Bestellung 887 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
38+1.92 EUR
46+1.57 EUR
54+1.34 EUR
Mindestbestellmenge: 38
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS341 ULV8.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: blue
Illumination voltage: 3V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS331 ULV8.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: green
Illumination voltage: 3V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ULV8FPBSS344 ULV8FPBSS344.pdf
Hersteller: E-SWITCH
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPDT; 3A/250VAC; IP67; ON-(ON)
Type of switch: vandal resistant
Number of positions: 2
Stable positions number: 1
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
IP rating: IP67
Switching method: ON-(ON)
Illumination: LED; ring
Backlight colour: blue
Illumination voltage: 12V
Leads: cables
Lead length: 0.5m
Electrical life: 50000 cycles
Max. contact resistance:: 50mΩ
Operating Force: 2.5N
Mechanical durability: 1000000 cycles
Button shape: flat; round
Mounting hole diameter: Ø25mm
Body colour: silver
Body material: stainless steel
Manufacturer series: ULV8
Contact material: silver
Actuator colour: silver
Button marking: blank
Min. insulation resistance: 1GΩ
Panel thickness: 1...10mm
Mounting: on panel
Body dimensions: Ø28x29.4mm
Key stroke: 3.2mm
Operating temperature: -20...55°C
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL59BF160Q J100567.pdf TL59BF160Q.pdf
TL59BF160Q
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; THT; none; 1.57N; 9.5mm
Type of switch: microswitch TACT
Contacts configuration: SPST
Number of positions: 2
Stable positions number: 1
DC contacts rating @R: 50mA / 12V DC
Mounting: THT
Illumination: none
Operating Force: 1.57N
Body dimensions: 6.2x6.2x3.6mm
Button height: 9.5mm
Switching method: OFF-(ON)
Terminal pitch: 5mm
Button shape: round
Actuator colour: black
Key stroke: 0.25mm
Leads: round pin
Max. contact resistance:: 100mΩ
Mechanical durability: 80000 cycles
auf Bestellung 1364 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
193+0.37 EUR
211+0.34 EUR
228+0.31 EUR
244+0.29 EUR
264+0.27 EUR
295+0.24 EUR
500+0.22 EUR
Mindestbestellmenge: 193
Im Einkaufswagen  Stück im Wert von  UAH
TL6275AA2PQNR T062750.pdf TL6275AA2PQNR.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; THT; LED; 3.43N; 7.2mm
Type of switch: microswitch TACT
Contacts configuration: SPST
Switching method: OFF-(ON)
Leads: flat pin
Mechanical durability: 100000 cycles
Operating temperature: -20...70°C
Operating Force: 3.43N
Mounting: THT
Illumination: LED
Button shape: square
Key stroke: 0.25mm
Button height: 7.2mm
Terminal pitch: 4.5mm
Body dimensions: 8x8x7.2mm
DC contacts rating @R: 50mA / 12V DC
Max. contact resistance:: 100mΩ
Stable positions number: 1
Number of positions: 2
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
KOM4 KOM4.pdf
Hersteller: E-SWITCH
Category: Key Switches and Locks
Description: Accessories: safety cover; KO
Manufacturer series: KO
Type of switch accessories: safety cover
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1015AF160QG P420000.pdf TL1015AF160QG.pdf
TL1015AF160QG
+1
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMT; 1.57N; 2mm
Operating temperature: -20...70°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMT
Switching method: OFF-(ON)
Button shape: round
Key stroke: 0.2mm
Button height: 2mm
Body dimensions: 3.9x2.9x1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Actuator colour: ivory
auf Bestellung 2710 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
135+0.53 EUR
Mindestbestellmenge: 135
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF500AQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 4.9N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 4.9N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 100000 cycles
Actuator colour: brown
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF200AQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.96N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.96N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABAF260QG TL1017v2.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 2.55N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 2.55N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABBF160QG TL1017v2.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 1.57N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with ground terminal; with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF160AQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.57N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF160BQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.57N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF350BQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 3.43N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 3.43N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Actuator colour: blue
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABAF160QG TL1017v2.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 1.57N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.57N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1017ABBF260QG TL1017v2.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST-NO; Pos: 2; 0.05A/12VDC; SMD; 2.55N; 1.5mm
Operating temperature: -20...70°C
Leads: for soldering
Type of switch: microswitch TACT
Contacts configuration: SPST-NO
Mounting: SMD
Switching method: OFF-(ON)
Button shape: round
Switches features: with ground terminal; with locating pin
Button height: 1.5mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 2.55N
Stable positions number: 1
Number of positions: 2
Electrical life: 200000 cycles
Mechanical durability: 200000 cycles
Min. insulation resistance: 0.1GΩ
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TL1030AF200BQJ TL1030.pdf
Hersteller: E-SWITCH
Category: Microswitches TACT
Description: Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.96N; 1.7mm
Operating temperature: -40...85°C
Leads: for PCB
Type of switch: microswitch TACT
Contacts configuration: SPST
Mounting: SMT
Illumination: none
Switching method: OFF-(ON)
Switches features: with ground terminal
Key stroke: 0.15mm
Button height: 1.7mm
Max. contact resistance:: 100mΩ
DC contacts rating @R: 50mA / 12V DC
Operating Force: 1.96N
Stable positions number: 1
Number of positions: 2
Mechanical durability: 200000 cycles
Contact material: silver
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 36 72 108 144 180 216 252 288 324 358 359 360 361 362 363 364 365  [ Nächste Seite >> ]
