Produkte > GW INSTEK > Alle Produkte des Herstellers GW INSTEK (1189) > Seite 5 nach 20

Wählen Sie Seite:    << Vorherige Seite ]  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20  Nächste Seite >> ]
Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
ohne MwSt
GDS-2072A GDS-2072A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Kind of display used: LCD 8"
Number of channels: 2
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Trigger: alternative; falling-edge; impulse width; rising-edge
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Rise time: ≤5ns
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Plug variant: EU
Dimensions: 380x220x145mm
Related items: DS2-8LA
Software: included
Alias: 01DS2072A0GT
Input coupling: AC, DC, GND
Input impedance: 1MΩ/16pF
Measurement memory: 24
Trigger coupling: AC; DC; highpass; lowpass
Band: 70MHz
Time base: 1n...100s/div
Max. input voltage: 300V
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Kind of oscilloscope: DSO
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Vertical resolution: 8bit
Type of oscilloscope: digital
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
1+1755.44 EUR
GDS-2072E GDS-2072E GW INSTEK 2344135.pdf Description: GW INSTEK - GDS-2072E - Digitales Oszilloskop, GDS-2000E, 2 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2072E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2072E GDS-2072E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS272E00GT
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
1+929.5 EUR
GDS-2074A GDS-2074A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2074E GDS-2074E GW INSTEK 2344135.pdf Description: GW INSTEK - GDS-2074E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2074E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-210 GDS-210 GW INSTEK 1875485.pdf Description: GW INSTEK - GDS-210 - Oszilloskop, GDS200, 2 Kanäle, 100 MHz, 1 GSPS, 1Mpts, 3.5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 1Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS200
Bandbreite: 100
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2102A GDS-2102A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2102E GDS-2102E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Produkt ist nicht verfügbar
GDS-2104A GDS-2104A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2104E GDS-2104E GW INSTEK 2344135.pdf Description: GW INSTEK - GDS-2104E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 100 MHz, 1 GSPS, 10Mpts, 3.5 ns
Lieferumfang des Kits: DSO GDS-2104E, 1 passiver 150MHz-Tastkopf GTP-150A-4 (10:1/1:1), Netzkabel, Kurzanleitung, CD
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 100
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2104E GDS-2104E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Produkt ist nicht verfügbar
GDS-220 GDS-220 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS220000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-2202A GDS-2202A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2202E GDS-2202E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS222E00GT
Produkt ist nicht verfügbar
GDS-2204A
+2
GDS-2204A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
1+2143.8 EUR
GDS-2204E GDS-2204E GW INSTEK 2344135.pdf Description: GW INSTEK - GDS-2204E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 200 MHz, 1 GSPS, 10Mpts, 1.75 ns
Lieferumfang des Kits: DSO GDS-2204E, vier passive Tastköpfe GTP-200B-4 (200MHz, 10:1/1:1 umschaltbar), je 1 pro Kanal, Netzkabel, Kurzanleitung & Handbuch auf CD.
Berechnete Anstiegszeit: 1.75
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 200
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
auf Bestellung 3 Stücke:
Lieferzeit 14-21 Tag (e)
GDS-2204E GDS-2204E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 4
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS224E00GT
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
1+2100.67 EUR
GDS-2302A GDS-2302A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2304A GDS-2304A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-307 GDS-307 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS307000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-310 GDS-310 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤3.5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS310000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 100MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-310 GDS-310 GW INSTEK 2344131.pdf Description: GW INSTEK - GDS-310 - Oszilloskop, GDS300, 2 Kanäle, 100 MHz, 1 GSPS, 5Mpts, 3.5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 5Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS300
Bandbreite: 100
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-320 GDS-320 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS320000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-320 GDS-320 GW INSTEK 2344131.pdf Description: GW INSTEK - GDS-320 - Oszilloskop, GDS300, 2 Kanäle, 200 MHz, 1 GSPS, 5Mpts, 1.75 ns
Lieferumfang des Kits: 1 Tastkopf für 200MHz (GTP-200A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 1.75
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 5Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS300
Bandbreite: 200
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-3352A GW INSTEK PDF_BH_GDS-3XX2A_E_2CH.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3354A GW INSTEK Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS334A00GT
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Produkt ist nicht verfügbar
GDS-3502
+2
GDS-3502 GW INSTEK GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3504 GW INSTEK GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Produkt ist nicht verfügbar
GDS-3652A GDS-3652A GW INSTEK PDF_BH_GDS-3XX2A_E_2CH.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3654A GW INSTEK Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS364A00GT
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-1054B GDS-1054B GW INSTEK DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 50MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 50MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-1000B
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS154B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
1+696.68 EUR
GDS-1074B GDS-1074B GW INSTEK DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 70MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-1000B
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS174B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+907.26 EUR
GDS-1102B (CE) 2CH GDS-1102B (CE) 2CH GW INSTEK DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS112B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+596.74 EUR
GDS-1104B GDS-1104B GW INSTEK DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 100MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS114B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+1028.03 EUR
GDS-1202B GDS-1202B GW INSTEK GDS-1000B.pdf GDS-1000B-MANUAL.pdf GDS-1000B_DE.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1 Stücke:
Lieferzeit 7-14 Tag (e)
1+700.84 EUR
GDS-207 GDS-207 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS207000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2072E GDS-2072E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS272E00GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+929.5 EUR
GDS-2074A GDS-2074A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-207-BATTTERY GW INSTEK Category: Portable Oscilloscopes, Scopemeters
Description: Test acces: battery; GDS-207
Related items: GDS-207
Type of test accessories: battery
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2102A GDS-2102A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2102E GDS-2102E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2104A GDS-2104A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2104E GDS-2104E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-220 GDS-220 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS220000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2202A GDS-2202A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2202E GDS-2202E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS222E00GT
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2204A
+2
GDS-2204A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+2143.8 EUR
GDS-2204E GDS-2204E GW INSTEK datasheet_DS_GDS-2000E_E.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 4
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS224E00GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
1+2100.67 EUR
GDS-2302A GDS-2302A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2304A GDS-2304A GW INSTEK 2267005.pdf Description: GW INSTEK - GDS-2304A - Digitales Oszilloskop, GDS-2000A Series, 4 Kanäle, 300 MHz, 2 GSPS, 2Mpts, 1.17 ns
tariffCode: 90302000
Abtastrate: 2GSPS
productTraceability: No
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
Berechnete Anstiegszeit: 1.17ns
usEccn: 3A992.g
Bandbreite: 300MHz
Produktpalette: GDS-2000A Series
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
GDS-2304A GDS-2304A GW INSTEK GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-307 GDS-307 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS307000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-310 GDS-310 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤3.5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS310000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 100MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-320 GDS-320 GW INSTEK DS_GDS-300200_E.pdf Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS320000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3352A GW INSTEK PDF_BH_GDS-3XX2A_E_2CH.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3354A GW INSTEK Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS334A00GT
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3502
+2
GDS-3502 GW INSTEK GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3504 GW INSTEK GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3652A GDS-3652A GW INSTEK PDF_BH_GDS-3XX2A_E_2CH.pdf Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3654A GW INSTEK Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS364A00GT
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2072A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2072A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Kind of display used: LCD 8"
Number of channels: 2
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Trigger: alternative; falling-edge; impulse width; rising-edge
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Rise time: ≤5ns
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Plug variant: EU
Dimensions: 380x220x145mm
Related items: DS2-8LA
Software: included
Alias: 01DS2072A0GT
Input coupling: AC, DC, GND
Input impedance: 1MΩ/16pF
Measurement memory: 24
Trigger coupling: AC; DC; highpass; lowpass
Band: 70MHz
Time base: 1n...100s/div
Max. input voltage: 300V
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Kind of oscilloscope: DSO
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Vertical resolution: 8bit
Type of oscilloscope: digital
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis ohne MwSt
1+1755.44 EUR
GDS-2072E 2344135.pdf
GDS-2072E
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2072E - Digitales Oszilloskop, GDS-2000E, 2 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2072E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2072E datasheet_DS_GDS-2000E_E.pdf
GDS-2072E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS272E00GT
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis ohne MwSt
1+929.5 EUR
GDS-2074A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2074A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2074E 2344135.pdf
GDS-2074E
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2074E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2074E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-210 1875485.pdf
GDS-210
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-210 - Oszilloskop, GDS200, 2 Kanäle, 100 MHz, 1 GSPS, 1Mpts, 3.5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 1Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS200
Bandbreite: 100
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2102A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2102A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2102E datasheet_DS_GDS-2000E_E.pdf
GDS-2102E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Produkt ist nicht verfügbar
GDS-2104A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2104A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2104E 2344135.pdf
GDS-2104E
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2104E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 100 MHz, 1 GSPS, 10Mpts, 3.5 ns
Lieferumfang des Kits: DSO GDS-2104E, 1 passiver 150MHz-Tastkopf GTP-150A-4 (10:1/1:1), Netzkabel, Kurzanleitung, CD
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 100
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-2104E datasheet_DS_GDS-2000E_E.pdf
GDS-2104E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Produkt ist nicht verfügbar
GDS-220 DS_GDS-300200_E.pdf
GDS-220
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS220000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-2202A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2202A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2202E datasheet_DS_GDS-2000E_E.pdf
GDS-2202E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS222E00GT
Produkt ist nicht verfügbar
GDS-2204A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis ohne MwSt
1+2143.8 EUR
GDS-2204E 2344135.pdf
GDS-2204E
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2204E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 200 MHz, 1 GSPS, 10Mpts, 1.75 ns
Lieferumfang des Kits: DSO GDS-2204E, vier passive Tastköpfe GTP-200B-4 (200MHz, 10:1/1:1 umschaltbar), je 1 pro Kanal, Netzkabel, Kurzanleitung & Handbuch auf CD.
Berechnete Anstiegszeit: 1.75
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 200
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)
auf Bestellung 3 Stücke:
Lieferzeit 14-21 Tag (e)
GDS-2204E datasheet_DS_GDS-2000E_E.pdf
GDS-2204E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 4
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS224E00GT
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis ohne MwSt
1+2100.67 EUR
GDS-2302A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2302A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-2304A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2304A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Produkt ist nicht verfügbar
GDS-307 DS_GDS-300200_E.pdf
GDS-307
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS307000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-310 DS_GDS-300200_E.pdf
GDS-310
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤3.5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS310000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 100MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-310 2344131.pdf
GDS-310
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-310 - Oszilloskop, GDS300, 2 Kanäle, 100 MHz, 1 GSPS, 5Mpts, 3.5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 5Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS300
Bandbreite: 100
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-320 DS_GDS-300200_E.pdf
GDS-320
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS320000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Produkt ist nicht verfügbar
GDS-320 2344131.pdf
GDS-320
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-320 - Oszilloskop, GDS300, 2 Kanäle, 200 MHz, 1 GSPS, 5Mpts, 1.75 ns
Lieferumfang des Kits: 1 Tastkopf für 200MHz (GTP-200A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 1.75
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 5Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS300
Bandbreite: 200
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
GDS-3352A PDF_BH_GDS-3XX2A_E_2CH.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3354A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS334A00GT
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Produkt ist nicht verfügbar
GDS-3502 GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3504 GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Produkt ist nicht verfügbar
GDS-3652A PDF_BH_GDS-3XX2A_E_2CH.pdf
GDS-3652A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-3654A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS364A00GT
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Produkt ist nicht verfügbar
GDS-1054B DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf
GDS-1054B
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 50MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 50MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-1000B
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS154B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+696.68 EUR
GDS-1074B DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf
GDS-1074B
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 70MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-1000B
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS174B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+907.26 EUR
GDS-1102B (CE) 2CH DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf
GDS-1102B (CE) 2CH
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS112B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+596.74 EUR
GDS-1104B DS_GDS-1000B_E.pdf GDS-1000B_DE.pdf
GDS-1104B
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 100MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS114B10GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+1028.03 EUR
GDS-1202B GDS-1000B.pdf GDS-1000B-MANUAL.pdf GDS-1000B_DE.pdf
GDS-1202B
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: colour; LCD 7"
Trigger modes: automatic; normal; single
Time base: 5n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: USB
Manufacturer series: GDS-1000B
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+700.84 EUR
GDS-207 DS_GDS-300200_E.pdf
GDS-207
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS207000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2072E datasheet_DS_GDS-2000E_E.pdf
GDS-2072E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 70MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 70MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS272E00GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+929.5 EUR
GDS-2074A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2074A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 70MHz
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-207-BATTTERY
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Test acces: battery; GDS-207
Related items: GDS-207
Type of test accessories: battery
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2102A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2102A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2102E datasheet_DS_GDS-2000E_E.pdf
GDS-2102E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2104A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2104A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 100MHz
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2104E datasheet_DS_GDS-2000E_E.pdf
GDS-2104E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Band: 100MHz
Manufacturer series: GDS-2000E
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Kind of oscilloscope: DSO
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Interface: LAN; USB
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Sampling: 1Gsps
Type of oscilloscope: digital
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-220 DS_GDS-300200_E.pdf
GDS-220
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 1Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS220000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2202A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2202A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2202E datasheet_DS_GDS-2000E_E.pdf
GDS-2202E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS222E00GT
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2204A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 200MHz
Rise time: ≤1.7ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+2143.8 EUR
GDS-2204E datasheet_DS_GDS-2000E_E.pdf
GDS-2204E
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 4
Band: 200MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤1.75ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Plug variant: EU
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Alias: 01DS224E00GT
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis ohne MwSt
1+2100.67 EUR
GDS-2302A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2302A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-2304A 2267005.pdf
GDS-2304A
Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2304A - Digitales Oszilloskop, GDS-2000A Series, 4 Kanäle, 300 MHz, 2 GSPS, 2Mpts, 1.17 ns
tariffCode: 90302000
Abtastrate: 2GSPS
productTraceability: No
rohsCompliant: Y-EX
euEccn: NLR
Netzsteckertyp: -
hazardous: false
rohsPhthalatesCompliant: YES
Berechnete Anstiegszeit: 1.17ns
usEccn: 3A992.g
Bandbreite: 300MHz
Produktpalette: GDS-2000A Series
auf Bestellung 2 Stücke:
Lieferzeit 14-21 Tag (e)
GDS-2304A GDS-2000A.pdf GDS-2000A+User+Manual+2013+1003.pdf
GDS-2304A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Interface: Ethernet (option); IEEE-488 (option); RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Software: included
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: alternative; falling-edge; impulse width; rising-edge
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Kind of oscilloscope: DSO
Band: 300MHz
Rise time: ≤1.17ns
Input sensitivity: 1mV/div...10V/div
Time base: 1n...100s/div
Memory record length: 2Mpts
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Related items: DS2-8LA
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-307 DS_GDS-300200_E.pdf
GDS-307
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS307000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 70MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-310 DS_GDS-300200_E.pdf
GDS-310
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤3.5ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS310000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 100MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-320 DS_GDS-300200_E.pdf
GDS-320
Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD; Ch: 2; 1Gsps (in real time)
Measuring instrument features: HOLD function; MIN/MAX function
Resistance measuring accuracy: ±(0,3% + 3 digits) (500Ω, 5kΩ, 50kΩ, 500kΩ); ±(0,5% + 5 digits) (5MΩ)
Input sensitivity: 2mV/div
Memory record length: 5Mpts/ch
Type of oscilloscope: handheld oscilloscope
Screen size: 7"
Touchpad: yes
Kind of display used: LCD
Rise time: ≤1.75ns
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
Sampling: 1Gsps (in real time)
Display resolution: 480x800
Input impedance: 1MΩ
Dimensions: 240x136x60mm
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
AC current measuring accuracy: ±(1,5% + 15 digits) (50mA, 500mA) [50Hz-1kHz]; ±(3% + 15 digits) (10A) [50Hz-1kHz]
Alias: 01DS320000GT
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Band: 200MHz
Time base: 5n...100s/div
Number of channels: 2
AC voltage measuring accuracy: ±(1,5% + 15 digits) (50Hz...1kHz)
Max. input voltage: 300V
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
Plug variant: EU
AC current measuring range: 50mA; 0.5A; 10A
Supply voltage: 100...240V AC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3352A PDF_BH_GDS-3XX2A_E_2CH.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3354A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 350MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS334A00GT
Band: 350MHz
Rise time: 1ns
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3502 GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 2
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3504 GDS-3000-DTE.pdf GDS-3000+User+Manual+2013+0930.pdf
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 500MHz; 25kpts/ch; LCD 8"; GDS-3000
Interface: Ethernet; RS232; USB
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 4Gsps (in real time); 100Gsps (in equivalent time)
Type of oscilloscope: digital
Trigger: falling-edge; impulse width; rising-edge; video signal
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Plug variant: EU
Band: 500MHz
Rise time: ≤0.7ns
Input sensitivity: 2mV/div...5V/div
Time base: 1n...100s/div
Memory record length: 25kpts/ch
Kind of display used: LCD 8"
Supply voltage: 100...240V AC
Number of channels: 4
Measurement memory: 24
Input impedance: 1MΩ/15pF
Dimensions: 400x200x130mm
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3652A PDF_BH_GDS-3XX2A_E_2CH.pdf
GDS-3652A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 2
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
GDS-3654A
Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 650MHz; 5Gsps; 200Mpts/ch; GDS-3000A
Interface: Ethernet; RS232; USB; VGA
Kind of output connector: D-Sub female socket; D-Sub male socket; RJ45 socket; USB A socket; USB B socket
Manufacturer series: GDS-3000A
Standard equipment: mains cable; oscilloscope probe with 10:1 divider
Measuring instrument features: mathematical functions: addition, subtraction, division, multiplication and FFT; split screen function
Sampling: 5Gsps
Type of oscilloscope: digital
Trigger: alternate; bus; impulse width; timeout; video signal; with delay
Input coupling: AC, DC, GND
Vertical resolution: 8bit
Trigger modes: automatic; normal; single
Trigger coupling: AC; DC; highpass; lowpass
Max. input voltage: 300V
Alias: 01DS364A00GT
Band: 650MHz
Rise time: 535ps
Input sensitivity: 1mV/div...10V/div
Time base: 1...1000s/div
Memory record length: 200Mpts/ch
Kind of display used: colour; LCD TFT 10,2"
Supply voltage: 100...240V AC
Number of channels: 4
Display resolution: 800x480
Input impedance: 1MΩ/22pF
Dimensions: 420x253x113.8mm
Related items: DS3A-16LA; DS3A-GPIB; DS3A-PWR; GCP-1030; GTL-232; GTL-246; GTL-248; GTP-351R; GTP-501R
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Wählen Sie Seite:    << Vorherige Seite ]  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20  Nächste Seite >> ]
