Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
HFS-840 303 090 A 5342 GT16 HFS-840 303 090 A 5342 GT16 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C93DF604A0D6&compId=HFS-840-0137.pdf?ci_sign=1f527c7551f4c1adeb0538413636e5cc1095fcb2 Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.9mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.5mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 5342 GT16 M HFS-840 303 090 A 5342 GT16 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5E2FE040D6&compId=HFS-840-0336.pdf?ci_sign=b16c4c86ceb2bf24fea8f14eed11ec5cd53dacc5 Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.9mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.5mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 8040 GT13 HFS-840 303 090 A 8040 GT13 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDB364900D6&compId=HFS-840-0598.pdf?ci_sign=dce21bb64b390acc41b5dca61a36a9cc35531a89 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.9mm
Blade tip shape: cone; inverted; with traverse groove
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: outer conductor maximum current: 3A
Length: 45mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1.1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 8040 GT13 4M HFS-840 303 090 A 8040 GT13 4M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D624C0D6&compId=HFS-840-0628.pdf?ci_sign=de13d75a29c43aee933eb74c7c4a098b1b109804 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.9mm
Blade tip shape: cone; inverted; with traverse groove
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 45mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1.1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 5342 RF3 HFS-840 303 150 A 5342 RF3 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5CBCC060D6&compId=HFS-840-0332.pdf?ci_sign=bcadcafcb98045faedbb5769d7d3750071a326f4 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 5.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 5342 RF3 M HFS-840 303 150 A 5342 RF3 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1B931C80D6&compId=HFS-840-0399.pdf?ci_sign=fe03bb70e5d30071eff601b8d1aa6cd66a4ef34c Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: screw-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 5.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 8042 RF3 HFS-840 303 150 A 8042 RF3 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CE980D6&compId=HFS-840-0579.pdf?ci_sign=79be54c51b8c7038955a189192bf00a5a908a5ca Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 8N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 8042 RF3 M HFS-840 303 150 A 8042 RF3 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBF1AA31A0D6&compId=HFS-840-0637.pdf?ci_sign=049377134a29b54b158f882b93178de7f0c1f416 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Contact plating: gold-plated
Tip diameter: 1.5mm
Blade tip shape: cone; head 42; inverted
Spring compression force: 8N
Mounting: screw-in
Manufacturer series: HFS-840
Test accessories features: exchangeable outer conductor KO-810142610A-FRF3-A; outer conductor maximum current: 10A
Contact material: CuBe
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Operating temperature: -40...80°C
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 F HFS-840 303 150 A 9342 F INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C8A5F60000D6&compId=HFS-840-0020.pdf?ci_sign=b8ae1f66765b7d06d711f1bd1093d24b68286f36 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Contact material: CuBe
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Spring compression force: 9.3N
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 FS1 HFS-840 303 150 A 9342 FS1 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C8756485E0D6&compId=HFS-840-0045.pdf?ci_sign=48448d14c2a8867916842bd4cdb0767cdfae14d9 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Contact material: CuBe
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 5.8mm
Length: 43.2mm
Current rating: 3A
Spring compression force: 9.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 RF3 HFS-840 303 150 A 9342 RF3 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF8680DF7D225AC0D6&compId=HFS-840-0234.pdf?ci_sign=3d1f43f6b7b494bd242c2a056d926bbf10361d76 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 9.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9942 RF3 HFS-840 303 150 A 9942 RF3 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C9899E2300D6&compId=HFS-840-0273.pdf?ci_sign=4e442651049b81dc2874e1f0155f6bdb6ac1a848 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 10N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9942 RF3 M HFS-840 303 150 A 9942 RF3 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDB3647C0D6&compId=HFS-840-0597.pdf?ci_sign=1130b1cc57cbbfb740f66291b3c2089aaeab6120 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Contact plating: gold-plated
Tip diameter: 1.5mm
Blade tip shape: cone; head 42; inverted
Spring compression force: 10N
Mounting: screw-in
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Contact material: CuBe
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Operating temperature: -40...80°C
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 1102 V2-36S HFS-840 307 100 A 1102 V2-36S INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C87E214CA0D6&compId=HFS-840-0101.pdf?ci_sign=f9ce627e6dbf6510f9e123c5a9351bf50b1b51d0 Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 11.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 9202 V2-36S HFS-840 307 100 A 9202 V2-36S INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5CBCBB60D6&compId=HFS-840-0303.pdf?ci_sign=d6e4c6a50c3b396ae5fd25e52ad01fc5e0d8f7a8 Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 9.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 9202 V236S4M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D62380D6&compId=HFS-840-0623.pdf?ci_sign=2dba092889a3aed1d806aec00ca399519154e627 Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 9.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: screw-in
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 5342 GT16-F HFS-840 308 080 A 5342 GT16-F INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C941788820D6&compId=HFS-840-0222.pdf?ci_sign=bf5c17061904cd0f829b6a668d9555c590189409 Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.8mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Length: 43mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 5342GT16-F4M HFS-840 308 080 A 5342GT16-F4M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C9899E1780D6&compId=HFS-840-0245.pdf?ci_sign=bb28a5f763a64c60d4ca8204850d79847eb518ea Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.8mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Length: 43mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 8043 X HFS-840 308 080 A 8043 X INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CE5C0D6&compId=HFS-840-0560.pdf?ci_sign=9a2af638b2d57ebd7cf823d52fc45c56aba5e402 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Mounting: push-in
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 8mm
Length: 44mm
Spring compression force: 8N
Current rating: 3A
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone; head 43
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 9342 ZE3 M HFS-840 308 080 A 9342 ZE3 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBE0FE0CC0D6&compId=HFS-840-0683.pdf?ci_sign=1fd22991c671cde4d6cf903419fbe301f43f30a2 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: screw-in
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.4mm
Spring compression force: 9.3N
Current rating: 3A
Impedance: 50Ω
Blade tip shape: cone; head 42
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 9942 ZE3 M HFS-840 308 080 A 9942 ZE3 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC080A9960D6&compId=HFS-840-0655.pdf?ci_sign=8a4489fd8cd07ff3999afb8b4384ff3cee4a8004 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.8mm
Blade tip shape: cone; head 42
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Length: 43.4mm
Spring compression force: 10N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 110 A 8042 BX HFS-840 308 110 A 8042 BX INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CD900D6&compId=HFS-840-0444.pdf?ci_sign=5b664f9d003feea36f600c6babe44af0596e6f43 Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.1mm
Blade tip shape: cone; head 42
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Length: 43mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 358 080 A 4802 V2-00S HFS-840 358 080 A 4802 V2-00S INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C875648C20D6&compId=HFS-840-0056.pdf?ci_sign=28d0a05461cb9d499b352fe1aa44c38305c44fc2 Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 0.8mm; cone; HFS-840; push-in
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 2A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Length: 44mm
Current rating: 3A
Spring compression force: 4.8N
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 303 051 A 5543 UFL-H HFS-856 303 051 A 5543 UFL-H INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D62A60D6&compId=HFS-856-0024.pdf?ci_sign=96a0af581428af44207a5248da2bd07672f589ad Category: Contact Probes
Description: Test needle; Spring compression: 1mm; 2mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 1mm
Maksimum spring compression: 2mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Blade tip shape: cone; head 43; inverted
Manufacturer series: HFS-856
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 36.2mm
Spring compression force: 5.5N
Impedance: 50Ω
Max. frequency: 12GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 305 030 A 5543MM8030 H HFS-856 305 030 A 5543MM8030 H INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDE48AA60D6&compId=HFS-856-0022.pdf?ci_sign=f243b222f0344f1568e79f00dd296d39c38c5144 Category: Contact Probes
Description: Test needle; Spring compression: 0.8mm; 2mm; 2A; CuBe; gold-plated
Contact plating: gold-plated
Blade tip shape: head 43; rounded
Test accessories features: outer conductor maximum current: 3A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.3mm
Operational spring compression: 0.8mm
Maksimum spring compression: 2mm
Length: 36.2mm
Current rating: 2A
Spring compression force: 5.5N
Impedance: 50Ω
Contact material: CuBe
Max. frequency: 6GHz
Manufacturer series: HFS-856
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 305 040 A 6343 MS156-H HFS-856 305 040 A 6343 MS156-H INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CCA2BE3CA0D6&compId=HFS-856-0027.pdf?ci_sign=dcd51d44d402418af6f882476162fdf672f65f77 Category: Contact Probes
Description: Test needle; Spring compression: 0.8mm; 2mm; 2A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 0.8mm
Maksimum spring compression: 2mm
Current rating: 2A
Contact material: CuBe
Contact plating: gold-plated
Blade tip shape: head 43; rounded
Manufacturer series: HFS-856
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 36.5mm
Spring compression force: 6.3N
Impedance: 50Ω
Max. frequency: 6GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HKF-617 06308 080 A 10002 HKF-617 06308 080 A 10002 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CCA2BE3DE0D6&compId=HKF-617-0007.pdf?ci_sign=6912e3cd4eac3980cb90a394676f5b3dc1b1d231 Category: Contact Probes
Description: Test needle; 40A; bronze; gold-plated; HKF-617; push-in; 57.9mm
Current rating: 40A
Manufacturer series: HKF-617
Contact plating: gold-plated
Contact material: bronze
Operating temperature: -100...150°C
Mounting: push-in
Type of test accessories: test needle
Max. contact resistance:: 10mΩ
Length: 57.9mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HMS-100 305 090 A HMS-100 305 090 A INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA0A0CAF57C86A0D3&compId=INGUN_HMS-100-0001_EN.pdf?ci_sign=cc7bf3452f6892f01d27fb75bb4b0ec83afdcfd9 Category: Contact Probes
Description: Test needle; Operational spring compression: 4.3mm; Ø: 0.9mm
Contact material: CuBe
Manufacturer series: HMS-100
Blade tip shape: round
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 4.3mm
Maksimum spring compression: 6.35mm
Length: 33.4mm
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
8+9.11 EUR
10+8.75 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
HMS-100 305 090 A HMS-100 305 090 A INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA0A0CAF57C86A0D3&compId=INGUN_HMS-100-0001_EN.pdf?ci_sign=cc7bf3452f6892f01d27fb75bb4b0ec83afdcfd9 Category: Contact Probes
Description: Test needle; Operational spring compression: 4.3mm; Ø: 0.9mm
Contact material: CuBe
Manufacturer series: HMS-100
Blade tip shape: round
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 4.3mm
Maksimum spring compression: 6.35mm
Length: 33.4mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 10 Stücke:
Lieferzeit 7-14 Tag (e)
8+9.11 EUR
10+8.75 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 214 130 A 2209 HSS-118 214 130 A 2209 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EDD75E7640D6&compId=HSS-118-0364.pdf?ci_sign=2107a234d457a1335006240dec49af7754059ae2 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; steel; Ø: 1.3mm
Operating temperature: -100...200°C
Manufacturer series: HSS-118
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact material: steel
Mounting: push-in
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 1.3mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Length: 39.3mm
Max. contact resistance:: 10mΩ
Current rating: 20A
Spring compression force: 2.25N
Blade tip shape: corona; sharp
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 0806 HSS-118 302 100 A 0806 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E6AAAE1540D6&compId=HSS-118-0173.pdf?ci_sign=927cbc167e0b157fbb3e05eaf42da88c0f5fdd04 Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1mm; 0.8N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 5A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: flat
Tip diameter: 1mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 36.3mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 1503 HSS-118 302 100 A 1503 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB0547F1A0D6&compId=HSS-118-0300.pdf?ci_sign=87e76825699638a0940d843a9ecfa1bc202675df Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2203 HSS-118 302 100 A 2203 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EBFA0C9A40D6&compId=HSS-118-0331.pdf?ci_sign=880b7da38f33d8440b374c5ded1dc8621fe0caeb Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2204 HSS-118 302 100 A 2204 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC73F24EC0D6&compId=HSS-118-0332.pdf?ci_sign=b01d890bd2160fb38ff369ed6cec3528c0107c16 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2208 HSS-118 302 100 A 2208 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4D986A3A0D6&compId=HSS-118-0565.pdf?ci_sign=bf6e61cca36a0f4b50f53d5ae8c9ff3e04515207 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2210 HSS-118 302 100 A 2210 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4923CCC00D6&compId=HSS-118-0537.pdf?ci_sign=7755a15defee966bb6a0ffb8798b6ba833619ca2 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 40.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 1503 HSS-118 303 200 A 1503 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB35903B20D6&compId=HSS-118-0318.pdf?ci_sign=bb6ef911b71b4d52cefc543fa784063ab62975ba Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 1.5N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 1510 HSS-118 303 200 A 1510 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E7818962A0D6&compId=HSS-118-0200.pdf?ci_sign=4e26044655dbbef84c378745fee7568d9b912bce Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 1.5N
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Mounting: push-in
Operating temperature: -100...200°C
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Length: 40.3mm
Spring compression force: 1.5N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Blade tip shape: cone; inverted
Contact material: CuBe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2202 HSS-118 303 200 A 2202 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E3B06DA200D6&compId=HSS-118-0110.pdf?ci_sign=922a99929239410d2b8bff4dc843f9cb97f09493 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Contact material: CuBe
Blade tip shape: cone; inverted
Mounting: push-in
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Max. contact resistance:: 10mΩ
Length: 32.3mm
Spring compression force: 2.25N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Manufacturer series: HSS-118
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2207 HSS-118 303 200 A 2207 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E8B7CDFB80D6&compId=HSS-118-0238.pdf?ci_sign=bb19daba2075c718b2e5c3b429acacf348272f09 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Blade tip shape: cone; inverted
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Contact material: CuBe
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Max. contact resistance:: 10mΩ
Length: 37.3mm
Spring compression force: 2.25N
Current rating: 20A
Operating temperature: -100...200°C
Manufacturer series: HSS-118
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2210 HSS-118 303 200 A 2210 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EA5249E020D6&compId=HSS-118-0286.pdf?ci_sign=d06a6e20a615cbf9e70c7d39531cfea28c425999 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 40.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 3007 HSS-118 303 200 A 3007 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC02A706E0D6&compId=HSS-118-0326.pdf?ci_sign=992208319b79325afad4dfd641b4b6aa023f58a7 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 3N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 37.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 3008 HSS-118 303 200 A 3008 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB6229E8C0D6&compId=HSS-118-0323.pdf?ci_sign=cc81c92dadd7c0b739f494432a5bc3cb3ff60225 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 3N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 065 A 0802 M HSS-118 305 065 A 0802 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4962AD500D6&compId=HSS-118-0558.pdf?ci_sign=5d0da2fee3e2900943f3f3a5895a5b92a9fe58f5 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 5A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 5A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.65mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 065 A 1502 HSS-118 305 065 A 1502 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F10D2AF6E0D6&compId=HSS-118-0457.pdf?ci_sign=15d08db41710021527c71bfe31422216af7add5b Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 0.65mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: round
Tip diameter: 0.65mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 080 A 1502 HSS-118 305 080 A 1502 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB54BBE920D6&compId=HSS-118-0309.pdf?ci_sign=01e9b37e678d8a36da519feed95e2bbbdbc1488f Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1502 M HSS-118 305 100 A 1502 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E1CAD28360D6&compId=HSS-118-0066.pdf?ci_sign=0e4e95de15a7bca2ec2de21cca84ba0dff34ac60 Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: round
Tip diameter: 1mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1503 HSS-118 305 100 A 1503 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB0547F480D6&compId=HSS-118-0303.pdf?ci_sign=e10603776b64228d0912d63aa993069529fb522e Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1506 HSS-118 305 100 A 1506 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E203056300D6&compId=HSS-118-0067.pdf?ci_sign=ec0ddd5a5ad60bc9abad8c6c1bf8603f64978f21 Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Manufacturer series: HSS-118
Current rating: 20A
Spring compression force: 1.5N
Contact material: CuBe
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Blade tip shape: round
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Max. contact resistance:: 10mΩ
Length: 36.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 2202 M HSS-118 305 100 A 2202 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E1C4A437C0D6&compId=HSS-118-0061.pdf?ci_sign=94449bcc101ef050b64630b16fc6f30dfd092b44 Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Manufacturer series: HSS-118
Current rating: 20A
Spring compression force: 2.25N
Contact material: CuBe
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: screw-in
Blade tip shape: round
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Max. contact resistance:: 10mΩ
Length: 35.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 2204 HSS-118 305 100 A 2204 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E968080C60D6&compId=HSS-118-0274.pdf?ci_sign=d1de30dbc921d28a35834a53d3e9b1a1de650311 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Mounting: push-in
Operating temperature: -100...200°C
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Length: 34.3mm
Max. contact resistance:: 10mΩ
Spring compression force: 2.25N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Manufacturer series: HSS-118
Contact material: CuBe
Blade tip shape: round
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 3008 HSS-118 305 100 A 3008 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECBAC20D60D6&compId=HSS-118-0341.pdf?ci_sign=57927724becd9342864693d1f9c39979c3769acd Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 200 S 1502 HSS-118 305 200 S 1502 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EE40005B60D6&compId=HSS-118-0381.pdf?ci_sign=9b6d93c78bc0be73485b643d3b00d77635382824 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; flat
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: silver plated
Tip diameter: 2mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 200 S 2202 HSS-118 305 200 S 2202 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EEC6330440D6&compId=HSS-118-0392.pdf?ci_sign=8e872c54d3abfc5907e308104bc134cb4ffdd825 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; flat
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: silver plated
Tip diameter: 2mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 0804 HSS-118 306 130 A 0804 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECED36EE80D6&compId=HSS-118-0336.pdf?ci_sign=8065a2393789f29fcf20d00cc3e3c19fe408510a Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 5A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 5A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 1504 HSS-118 306 130 A 1504 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECED36EFC0D6&compId=HSS-118-0337.pdf?ci_sign=07fa8b453127e11ac044c61a6289d8a5f058d555 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 2203 HSS-118 306 130 A 2203 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC164D1400D6&compId=HSS-118-0329.pdf?ci_sign=261b47edb09396b7b903531d395aaa9afcd5b613 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 2204 HSS-118 306 130 A 2204 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC2CFBA3E0D6&compId=HSS-118-0330.pdf?ci_sign=5c985882e70c105f625d409fc3ce9aef2ec04ba5 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 3002 M HSS-118 306 130 A 3002 M INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E98973FBC0D6&compId=HSS-118-0265.pdf?ci_sign=57931ae414348b3d299d35aba2c3f0ab5bcd1462 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 160 A 1503 HSS-118 306 160 A 1503 INGUN pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB6358ACA0D6&compId=HSS-118-0315.pdf?ci_sign=abda5317db6ee1beacc0c776d5bc0bb7bab6e6f5 Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.6mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.6mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 5342 GT16 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C93DF604A0D6&compId=HFS-840-0137.pdf?ci_sign=1f527c7551f4c1adeb0538413636e5cc1095fcb2
HFS-840 303 090 A 5342 GT16
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.9mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.5mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 5342 GT16 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5E2FE040D6&compId=HFS-840-0336.pdf?ci_sign=b16c4c86ceb2bf24fea8f14eed11ec5cd53dacc5
HFS-840 303 090 A 5342 GT16 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.9mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.5mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 8040 GT13 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDB364900D6&compId=HFS-840-0598.pdf?ci_sign=dce21bb64b390acc41b5dca61a36a9cc35531a89
HFS-840 303 090 A 8040 GT13
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.9mm
Blade tip shape: cone; inverted; with traverse groove
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: outer conductor maximum current: 3A
Length: 45mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1.1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 090 A 8040 GT13 4M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D624C0D6&compId=HFS-840-0628.pdf?ci_sign=de13d75a29c43aee933eb74c7c4a098b1b109804
HFS-840 303 090 A 8040 GT13 4M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.9mm
Blade tip shape: cone; inverted; with traverse groove
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 45mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1.1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 5342 RF3 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5CBCC060D6&compId=HFS-840-0332.pdf?ci_sign=bcadcafcb98045faedbb5769d7d3750071a326f4
HFS-840 303 150 A 5342 RF3
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 5.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 5342 RF3 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1B931C80D6&compId=HFS-840-0399.pdf?ci_sign=fe03bb70e5d30071eff601b8d1aa6cd66a4ef34c
HFS-840 303 150 A 5342 RF3 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: screw-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 5.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 8042 RF3 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CE980D6&compId=HFS-840-0579.pdf?ci_sign=79be54c51b8c7038955a189192bf00a5a908a5ca
HFS-840 303 150 A 8042 RF3
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 8N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 8042 RF3 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBF1AA31A0D6&compId=HFS-840-0637.pdf?ci_sign=049377134a29b54b158f882b93178de7f0c1f416
HFS-840 303 150 A 8042 RF3 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Contact plating: gold-plated
Tip diameter: 1.5mm
Blade tip shape: cone; head 42; inverted
Spring compression force: 8N
Mounting: screw-in
Manufacturer series: HFS-840
Test accessories features: exchangeable outer conductor KO-810142610A-FRF3-A; outer conductor maximum current: 10A
Contact material: CuBe
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Operating temperature: -40...80°C
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 F pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C8A5F60000D6&compId=HFS-840-0020.pdf?ci_sign=b8ae1f66765b7d06d711f1bd1093d24b68286f36
HFS-840 303 150 A 9342 F
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Contact material: CuBe
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Spring compression force: 9.3N
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 FS1 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C8756485E0D6&compId=HFS-840-0045.pdf?ci_sign=48448d14c2a8867916842bd4cdb0767cdfae14d9
HFS-840 303 150 A 9342 FS1
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Contact material: CuBe
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 5.8mm
Length: 43.2mm
Current rating: 3A
Spring compression force: 9.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42; inverted
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9342 RF3 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF8680DF7D225AC0D6&compId=HFS-840-0234.pdf?ci_sign=3d1f43f6b7b494bd242c2a056d926bbf10361d76
HFS-840 303 150 A 9342 RF3
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 9.3N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9942 RF3 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C9899E2300D6&compId=HFS-840-0273.pdf?ci_sign=4e442651049b81dc2874e1f0155f6bdb6ac1a848
HFS-840 303 150 A 9942 RF3
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Mounting: push-in
Operating temperature: -40...80°C
Tip diameter: 1.5mm
Maksimum spring compression: 3.7mm
Flange diameter: 6.1mm
Length: 43.2mm
Spring compression force: 10N
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Operational spring compression: 2mm
Blade tip shape: cone; head 42; inverted
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 303 150 A 9942 RF3 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDB3647C0D6&compId=HFS-840-0597.pdf?ci_sign=1130b1cc57cbbfb740f66291b3c2089aaeab6120
HFS-840 303 150 A 9942 RF3 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Contact plating: gold-plated
Tip diameter: 1.5mm
Blade tip shape: cone; head 42; inverted
Spring compression force: 10N
Mounting: screw-in
Manufacturer series: HFS-840
Test accessories features: outer conductor maximum current: 10A
Contact material: CuBe
Flange diameter: 6.1mm
Length: 43.2mm
Current rating: 3A
Impedance: 50Ω
Dielectric strength: 1.1kV
Operating temperature: -40...80°C
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 1102 V2-36S pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C87E214CA0D6&compId=HFS-840-0101.pdf?ci_sign=f9ce627e6dbf6510f9e123c5a9351bf50b1b51d0
HFS-840 307 100 A 1102 V2-36S
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 11.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 9202 V2-36S pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CA5CBCBB60D6&compId=HFS-840-0303.pdf?ci_sign=d6e4c6a50c3b396ae5fd25e52ad01fc5e0d8f7a8
HFS-840 307 100 A 9202 V2-36S
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 9.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 307 100 A 9202 V236S4M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D62380D6&compId=HFS-840-0623.pdf?ci_sign=2dba092889a3aed1d806aec00ca399519154e627
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 1mm; chisel,cone; HFS-840
Test accessories features: outer conductor maximum current: 3A; self-cleaning
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 1mm
Length: 44mm
Current rating: 3A
Spring compression force: 9.2N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: chisel; cone
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: screw-in
Contact plating: gold-plated
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 5342 GT16-F pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C941788820D6&compId=HFS-840-0222.pdf?ci_sign=bf5c17061904cd0f829b6a668d9555c590189409
HFS-840 308 080 A 5342 GT16-F
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.8mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Length: 43mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 5342GT16-F4M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C9899E1780D6&compId=HFS-840-0245.pdf?ci_sign=bb28a5f763a64c60d4ca8204850d79847eb518ea
HFS-840 308 080 A 5342GT16-F4M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 2mm; 3A; Ø: 0.8mm
Current rating: 3A
Manufacturer series: HFS-840
Contact material: CuBe
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Length: 43mm
Spring compression force: 5.3N
Impedance: 50Ω
Dielectric strength: 1.1kV
Max. frequency: 4GHz
Blade tip shape: cone; head 42
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 8043 X pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CE5C0D6&compId=HFS-840-0560.pdf?ci_sign=9a2af638b2d57ebd7cf823d52fc45c56aba5e402
HFS-840 308 080 A 8043 X
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Manufacturer series: HFS-840
Mounting: push-in
Contact material: CuBe
Type of test accessories: test needle
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 8mm
Length: 44mm
Spring compression force: 8N
Current rating: 3A
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone; head 43
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 9342 ZE3 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBE0FE0CC0D6&compId=HFS-840-0683.pdf?ci_sign=1fd22991c671cde4d6cf903419fbe301f43f30a2
HFS-840 308 080 A 9342 ZE3 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Mounting: screw-in
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Flange diameter: 6mm
Length: 43.4mm
Spring compression force: 9.3N
Current rating: 3A
Impedance: 50Ω
Blade tip shape: cone; head 42
Max. frequency: 4GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 080 A 9942 ZE3 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC080A9960D6&compId=HFS-840-0655.pdf?ci_sign=8a4489fd8cd07ff3999afb8b4384ff3cee4a8004
HFS-840 308 080 A 9942 ZE3 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.8mm
Blade tip shape: cone; head 42
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Length: 43.4mm
Spring compression force: 10N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 308 110 A 8042 BX pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CB1D6CD900D6&compId=HFS-840-0444.pdf?ci_sign=5b664f9d003feea36f600c6babe44af0596e6f43
HFS-840 308 110 A 8042 BX
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 2mm; 3.7mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 2mm
Maksimum spring compression: 3.7mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.1mm
Blade tip shape: cone; head 42
Manufacturer series: HFS-840
Operating temperature: -40...80°C
Mounting: push-in
Test accessories features: outer conductor maximum current: 10A; self-cleaning
Length: 43mm
Spring compression force: 8N
Impedance: 50Ω
Max. frequency: 4GHz
Flange diameter: 6.5mm
Dielectric strength: 1kV
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-840 358 080 A 4802 V2-00S pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0C875648C20D6&compId=HFS-840-0056.pdf?ci_sign=28d0a05461cb9d499b352fe1aa44c38305c44fc2
HFS-840 358 080 A 4802 V2-00S
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; 3A; CuBe; gold-plated; Ø: 0.8mm; cone; HFS-840; push-in
Type of test accessories: test needle
Contact material: CuBe
Manufacturer series: HFS-840
Mounting: push-in
Contact plating: gold-plated
Test accessories features: outer conductor maximum current: 2A; self-cleaning
Operating temperature: -40...80°C
Tip diameter: 0.8mm
Length: 44mm
Current rating: 3A
Spring compression force: 4.8N
Impedance: 50Ω
Max. frequency: 4GHz
Blade tip shape: cone
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 303 051 A 5543 UFL-H pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CC04D62A60D6&compId=HFS-856-0024.pdf?ci_sign=96a0af581428af44207a5248da2bd07672f589ad
HFS-856 303 051 A 5543 UFL-H
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 1mm; 2mm; 3A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 1mm
Maksimum spring compression: 2mm
Current rating: 3A
Contact material: CuBe
Contact plating: gold-plated
Blade tip shape: cone; head 43; inverted
Manufacturer series: HFS-856
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 36.2mm
Spring compression force: 5.5N
Impedance: 50Ω
Max. frequency: 12GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 305 030 A 5543MM8030 H pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CBDE48AA60D6&compId=HFS-856-0022.pdf?ci_sign=f243b222f0344f1568e79f00dd296d39c38c5144
HFS-856 305 030 A 5543MM8030 H
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 0.8mm; 2mm; 2A; CuBe; gold-plated
Contact plating: gold-plated
Blade tip shape: head 43; rounded
Test accessories features: outer conductor maximum current: 3A
Mounting: screw-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.3mm
Operational spring compression: 0.8mm
Maksimum spring compression: 2mm
Length: 36.2mm
Current rating: 2A
Spring compression force: 5.5N
Impedance: 50Ω
Contact material: CuBe
Max. frequency: 6GHz
Manufacturer series: HFS-856
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HFS-856 305 040 A 6343 MS156-H pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CCA2BE3CA0D6&compId=HFS-856-0027.pdf?ci_sign=dcd51d44d402418af6f882476162fdf672f65f77
HFS-856 305 040 A 6343 MS156-H
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 0.8mm; 2mm; 2A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 0.8mm
Maksimum spring compression: 2mm
Current rating: 2A
Contact material: CuBe
Contact plating: gold-plated
Blade tip shape: head 43; rounded
Manufacturer series: HFS-856
Operating temperature: -40...80°C
Mounting: screw-in
Test accessories features: outer conductor maximum current: 3A
Length: 36.5mm
Spring compression force: 6.3N
Impedance: 50Ω
Max. frequency: 6GHz
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HKF-617 06308 080 A 10002 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF83A0CCA2BE3DE0D6&compId=HKF-617-0007.pdf?ci_sign=6912e3cd4eac3980cb90a394676f5b3dc1b1d231
HKF-617 06308 080 A 10002
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; 40A; bronze; gold-plated; HKF-617; push-in; 57.9mm
Current rating: 40A
Manufacturer series: HKF-617
Contact plating: gold-plated
Contact material: bronze
Operating temperature: -100...150°C
Mounting: push-in
Type of test accessories: test needle
Max. contact resistance:: 10mΩ
Length: 57.9mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HMS-100 305 090 A pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA0A0CAF57C86A0D3&compId=INGUN_HMS-100-0001_EN.pdf?ci_sign=cc7bf3452f6892f01d27fb75bb4b0ec83afdcfd9
HMS-100 305 090 A
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4.3mm; Ø: 0.9mm
Contact material: CuBe
Manufacturer series: HMS-100
Blade tip shape: round
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 4.3mm
Maksimum spring compression: 6.35mm
Length: 33.4mm
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
8+9.11 EUR
10+8.75 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
HMS-100 305 090 A pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA0A0CAF57C86A0D3&compId=INGUN_HMS-100-0001_EN.pdf?ci_sign=cc7bf3452f6892f01d27fb75bb4b0ec83afdcfd9
HMS-100 305 090 A
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4.3mm; Ø: 0.9mm
Contact material: CuBe
Manufacturer series: HMS-100
Blade tip shape: round
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Operating temperature: -40...80°C
Tip diameter: 0.9mm
Operational spring compression: 4.3mm
Maksimum spring compression: 6.35mm
Length: 33.4mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 10 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
8+9.11 EUR
10+8.75 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 214 130 A 2209 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EDD75E7640D6&compId=HSS-118-0364.pdf?ci_sign=2107a234d457a1335006240dec49af7754059ae2
HSS-118 214 130 A 2209
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; steel; Ø: 1.3mm
Operating temperature: -100...200°C
Manufacturer series: HSS-118
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact material: steel
Mounting: push-in
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 1.3mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Length: 39.3mm
Max. contact resistance:: 10mΩ
Current rating: 20A
Spring compression force: 2.25N
Blade tip shape: corona; sharp
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 0806 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E6AAAE1540D6&compId=HSS-118-0173.pdf?ci_sign=927cbc167e0b157fbb3e05eaf42da88c0f5fdd04
HSS-118 302 100 A 0806
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 5A; Ø: 1mm; 0.8N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 5A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: flat
Tip diameter: 1mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 36.3mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 1503 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB0547F1A0D6&compId=HSS-118-0300.pdf?ci_sign=87e76825699638a0940d843a9ecfa1bc202675df
HSS-118 302 100 A 1503
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2203 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EBFA0C9A40D6&compId=HSS-118-0331.pdf?ci_sign=880b7da38f33d8440b374c5ded1dc8621fe0caeb
HSS-118 302 100 A 2203
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2204 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC73F24EC0D6&compId=HSS-118-0332.pdf?ci_sign=b01d890bd2160fb38ff369ed6cec3528c0107c16
HSS-118 302 100 A 2204
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2208 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4D986A3A0D6&compId=HSS-118-0565.pdf?ci_sign=bf6e61cca36a0f4b50f53d5ae8c9ff3e04515207
HSS-118 302 100 A 2208
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 302 100 A 2210 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4923CCC00D6&compId=HSS-118-0537.pdf?ci_sign=7755a15defee966bb6a0ffb8798b6ba833619ca2
HSS-118 302 100 A 2210
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 40.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 1503 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB35903B20D6&compId=HSS-118-0318.pdf?ci_sign=bb6ef911b71b4d52cefc543fa784063ab62975ba
HSS-118 303 200 A 1503
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 1.5N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 1510 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E7818962A0D6&compId=HSS-118-0200.pdf?ci_sign=4e26044655dbbef84c378745fee7568d9b912bce
HSS-118 303 200 A 1510
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 1.5N
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Mounting: push-in
Operating temperature: -100...200°C
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Length: 40.3mm
Spring compression force: 1.5N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Blade tip shape: cone; inverted
Contact material: CuBe
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2202 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E3B06DA200D6&compId=HSS-118-0110.pdf?ci_sign=922a99929239410d2b8bff4dc843f9cb97f09493
HSS-118 303 200 A 2202
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Contact material: CuBe
Blade tip shape: cone; inverted
Mounting: push-in
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Max. contact resistance:: 10mΩ
Length: 32.3mm
Spring compression force: 2.25N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Manufacturer series: HSS-118
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2207 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E8B7CDFB80D6&compId=HSS-118-0238.pdf?ci_sign=bb19daba2075c718b2e5c3b429acacf348272f09
HSS-118 303 200 A 2207
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Blade tip shape: cone; inverted
Test accessories features: magnetic
Mounting: push-in
Type of test accessories: test needle
Contact material: CuBe
Tip diameter: 2mm
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Max. contact resistance:: 10mΩ
Length: 37.3mm
Spring compression force: 2.25N
Current rating: 20A
Operating temperature: -100...200°C
Manufacturer series: HSS-118
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 2210 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EA5249E020D6&compId=HSS-118-0286.pdf?ci_sign=d06a6e20a615cbf9e70c7d39531cfea28c425999
HSS-118 303 200 A 2210
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 40.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 3007 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC02A706E0D6&compId=HSS-118-0326.pdf?ci_sign=992208319b79325afad4dfd641b4b6aa023f58a7
HSS-118 303 200 A 3007
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 3N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 37.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 303 200 A 3008 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB6229E8C0D6&compId=HSS-118-0323.pdf?ci_sign=cc81c92dadd7c0b739f494432a5bc3cb3ff60225
HSS-118 303 200 A 3008
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; 3N
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 2mm
Blade tip shape: cone; inverted
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 065 A 0802 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F4962AD500D6&compId=HSS-118-0558.pdf?ci_sign=5d0da2fee3e2900943f3f3a5895a5b92a9fe58f5
HSS-118 305 065 A 0802 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 5A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 5A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 0.65mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 065 A 1502 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7F10D2AF6E0D6&compId=HSS-118-0457.pdf?ci_sign=15d08db41710021527c71bfe31422216af7add5b
HSS-118 305 065 A 1502
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 0.65mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: round
Tip diameter: 0.65mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 080 A 1502 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB54BBE920D6&compId=HSS-118-0309.pdf?ci_sign=01e9b37e678d8a36da519feed95e2bbbdbc1488f
HSS-118 305 080 A 1502
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1502 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E1CAD28360D6&compId=HSS-118-0066.pdf?ci_sign=0e4e95de15a7bca2ec2de21cca84ba0dff34ac60
HSS-118 305 100 A 1502 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact plating: gold-plated
Max. contact resistance:: 10mΩ
Contact material: CuBe
Blade tip shape: round
Tip diameter: 1mm
Manufacturer series: HSS-118
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1503 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB0547F480D6&compId=HSS-118-0303.pdf?ci_sign=e10603776b64228d0912d63aa993069529fb522e
HSS-118 305 100 A 1503
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 1506 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E203056300D6&compId=HSS-118-0067.pdf?ci_sign=ec0ddd5a5ad60bc9abad8c6c1bf8603f64978f21
HSS-118 305 100 A 1506
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Manufacturer series: HSS-118
Current rating: 20A
Spring compression force: 1.5N
Contact material: CuBe
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: push-in
Blade tip shape: round
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Max. contact resistance:: 10mΩ
Length: 36.3mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 2202 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E1C4A437C0D6&compId=HSS-118-0061.pdf?ci_sign=94449bcc101ef050b64630b16fc6f30dfd092b44
HSS-118 305 100 A 2202 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Operational spring compression: 4mm; 20A; Ø: 1mm
Manufacturer series: HSS-118
Current rating: 20A
Spring compression force: 2.25N
Contact material: CuBe
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Contact plating: gold-plated
Test accessories features: magnetic
Mounting: screw-in
Blade tip shape: round
Type of test accessories: test needle
Operating temperature: -100...200°C
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Max. contact resistance:: 10mΩ
Length: 35.8mm
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 2204 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E968080C60D6&compId=HSS-118-0274.pdf?ci_sign=d1de30dbc921d28a35834a53d3e9b1a1de650311
HSS-118 305 100 A 2204
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Mounting: push-in
Operating temperature: -100...200°C
Contact plating: gold-plated
Test accessories features: magnetic
Type of test accessories: test needle
Tip diameter: 1mm
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Length: 34.3mm
Max. contact resistance:: 10mΩ
Spring compression force: 2.25N
Current rating: 20A
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Manufacturer series: HSS-118
Contact material: CuBe
Blade tip shape: round
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 100 A 3008 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECBAC20D60D6&compId=HSS-118-0341.pdf?ci_sign=57927724becd9342864693d1f9c39979c3769acd
HSS-118 305 100 A 3008
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 8mm; 20A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 8mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1mm
Blade tip shape: round
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 38.3mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 200 S 1502 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EE40005B60D6&compId=HSS-118-0381.pdf?ci_sign=9b6d93c78bc0be73485b643d3b00d77635382824
HSS-118 305 200 S 1502
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; flat
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: silver plated
Tip diameter: 2mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 305 200 S 2202 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EEC6330440D6&compId=HSS-118-0392.pdf?ci_sign=8e872c54d3abfc5907e308104bc134cb4ffdd825
HSS-118 305 200 S 2202
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 2mm; flat
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: silver plated
Tip diameter: 2mm
Blade tip shape: flat
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 0804 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECED36EE80D6&compId=HSS-118-0336.pdf?ci_sign=8065a2393789f29fcf20d00cc3e3c19fe408510a
HSS-118 306 130 A 0804
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 5A; CuBe; gold-plated
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 5A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 0.8N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 1504 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7ECED36EFC0D6&compId=HSS-118-0337.pdf?ci_sign=07fa8b453127e11ac044c61a6289d8a5f058d555
HSS-118 306 130 A 1504
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 2203 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC164D1400D6&compId=HSS-118-0329.pdf?ci_sign=261b47edb09396b7b903531d395aaa9afcd5b613
HSS-118 306 130 A 2203
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 2204 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EC2CFBA3E0D6&compId=HSS-118-0330.pdf?ci_sign=5c985882e70c105f625d409fc3ce9aef2ec04ba5
HSS-118 306 130 A 2204
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 34.3mm
Spring compression force: 2.25N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 130 A 3002 M pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7E98973FBC0D6&compId=HSS-118-0265.pdf?ci_sign=57931ae414348b3d299d35aba2c3f0ab5bcd1462
HSS-118 306 130 A 3002 M
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.3mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.3mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: screw-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 35.8mm
Spring compression force: 3N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
HSS-118 306 160 A 1503 pVersion=0046&contRep=ZT&docId=005056AB281E1EDEA6B7EB6358ACA0D6&compId=HSS-118-0315.pdf?ci_sign=abda5317db6ee1beacc0c776d5bc0bb7bab6e6f5
HSS-118 306 160 A 1503
Hersteller: INGUN
Category: Contact Probes
Description: Test needle; Spring compression: 4mm; 5.3mm; 20A; CuBe; Ø: 1.6mm
Type of test accessories: test needle
Operational spring compression: 4mm
Maksimum spring compression: 5.3mm
Current rating: 20A
Contact material: CuBe
Contact plating: gold-plated
Tip diameter: 1.6mm
Blade tip shape: serrated
Manufacturer series: HSS-118
Max. contact resistance:: 10mΩ
Operating temperature: -100...200°C
Mounting: push-in
Test accessories features: magnetic
Related items: DS-11202; DS-11203; DS-11205; KS-11230E2; SW-ZW-GKS-112
Length: 32.3mm
Spring compression force: 1.5N
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 3 6 9 12 15 18 21 22 23 24 25 26 27 28 29 30 31  [ Nächste Seite >> ]
