Produkte > OMRON ELECTRONIC COMPONENTS > Alle Produkte des Herstellers OMRON ELECTRONIC COMPONENTS (4718) > Seite 52 nach 79
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|   | G5Q-1A-EL2-HA DC12 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 16.7mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
| G5Q-1A-EL2-HA DC24 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 8.3mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A-EU 12VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Manufacturer series: G5Q-EU Type of relay: electromagnetic Mounting: PCB Relay variant: miniature Contacts configuration: SPST-NO Enclosure description: standard seal Operating temperature: -40...85°C Terminal pitch: 2.54mm Release time: 5ms Operate time: 10ms Body dimensions: 20.3x10.3x15.8mm Coil current: 16.7mA Contact resistance: 100mΩ Coil power consumption: 200mW DC contacts rating @R: 5A / 30V DC AC contacts rating @R: 10A / 250V AC Contact current max.: 10A Rated coil voltage: 12V DC Switched voltage: max. 30V DC; max. 277V AC Coil resistance: 720Ω | auf Bestellung 878 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
|   | G5Q-1A-EU 24VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Switched voltage: max. 30V DC; max. 277V AC Manufacturer series: G5Q-EU Relay variant: miniature Mounting: PCB Body dimensions: 20.3x10.3x15.8mm Operating temperature: -40...85°C Contacts configuration: SPST-NO Enclosure description: standard seal Terminal pitch: 2.54mm Release time: 5ms Operate time: 10ms Coil current: 8.3mA AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Contact resistance: 100mΩ Coil power consumption: 200mW Contact current max.: 10A Rated coil voltage: 24V DC Coil resistance: 2.88kΩ | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
| G5Q-1A-EU DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...85°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: standard seal | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-EU DC24 (TY) | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A-EU DC24 (TY) - Leistungsrelais, SPST-NO, 24 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil Relaisanschlüsse: PC-Pin Spulentyp: Monostabil Kontaktmaterial: Silberlegierung, cadmiumfrei Kontaktstrom: 10 Spulenwiderstand: 2.88 Kontaktspannung V DC: - Relaismontage: Durchsteckmontage Produktpalette: G5Q Series Spulenspannung: 24 Kontaktkonfiguration: SPST-NO Kontaktspannung V AC: 250 SVHC: No SVHC (10-Jun-2022) | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-EU-HA DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...85°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-EU-HA-VH DC24(TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...85°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: standard seal Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A-HA DC12 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | auf Bestellung 465 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
| G5Q-1A-HA DC24 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A-HA DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | auf Bestellung 302 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
| G5Q-1A-HA DC5 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Enclosure description: standard seal Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA DC5 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Application: Home Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC12 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Application: Home Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC24 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC5 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-PW DC5 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Application: Home Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-VH DC24 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-VH DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-VH DC5 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Application: Home Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-HA-VH DC5 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Application: Home Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A-HR-HA-VH DC12 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; G5Q; 20x10x15.5mm Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Manufacturer series: G5Q Body dimensions: 20x10x15.5mm Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A-HR-HA-VH DC24 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; G5Q; Home Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A Manufacturer series: G5Q Body dimensions: 20x10x15.5mm Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A-HR-HA-VH DC3 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 3VDC; G5Q; 20x10x15.5mm Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 3V DC Manufacturer series: G5Q Body dimensions: 20x10x15.5mm Application: Home Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A-HR-HA-VH DC5 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; G5Q; 20x10x15.5mm Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Manufacturer series: G5Q Body dimensions: 20x10x15.5mm Operating temperature: -40...105°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
| G5Q-1A-PW DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: standard seal | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-PW DC12 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: standard seal | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-PW DC24 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-PW DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-PW DC5 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Enclosure description: standard seal | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-PW DC5 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Operating temperature: -40...105°C Contact resistance: 100mΩ Contact material: silver alloy Coil current: 40mA Leads: for soldering Enclosure description: standard seal | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A-VH DC24 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 125V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 8.3mA Leads: for soldering Enclosure description: standard seal Operating temperature: -40...105°C | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A4 12DC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 16.7mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | auf Bestellung 54 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
|   | G5Q-1A4 5DC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 40mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | auf Bestellung 54 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
|   | G5Q-1A4 DC12 (TY) | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A4 DC12 (TY) - Leistungsrelais, SPST-NO, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil Relaisanschlüsse: PC-Pin Spulentyp: Monostabil Kontaktmaterial: Silberlegierung, cadmiumfrei Kontaktstrom: 10 Spulenwiderstand: 720 Kontaktspannung V DC: - Relaismontage: Durchsteckmontage Produktpalette: G5Q Series Spulenspannung: 12 Kontaktkonfiguration: SPST-NO Kontaktspannung V AC: 125 SVHC: No SVHC (10-Jun-2022) | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4 DC24 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 8.3mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
| G5Q-1A4-EL2-HA DC12 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 16.7mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-1A4-EL2-HA DC24 (TY) | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 1A / 250V AC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 1.44kΩ Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Coil current: 16.7mA Leads: for soldering Enclosure description: hermetic seal Operating temperature: -40...85°C Application: Home | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EL3-HA DC12 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 12V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 720Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 16.7mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EL3-HA DC24 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 8.3mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EL3-HA DC5 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 125Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 40mA Operating temperature: -40...85°C Terminal pitch: 7.62mm | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EU 12VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Contacts configuration: SPST-NO Type of relay: electromagnetic Mounting: PCB Enclosure description: hermetic seal Relay variant: miniature Operating temperature: -40...85°C Terminal pitch: 2.54mm Body dimensions: 20.3x10.3x15.8mm Release time: 5ms Operate time: 10ms Coil current: 16.7mA Contact resistance: 100mΩ Coil power consumption: 200mW DC contacts rating @R: 5A / 30V DC AC contacts rating @R: 10A / 250V AC Contact current max.: 10A Rated coil voltage: 12V DC Switched voltage: max. 30V DC; max. 277V AC Coil resistance: 720Ω Manufacturer series: G5Q-EU | auf Bestellung 224 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
|   | G5Q-1A4-EU 24VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Operate time: 10ms Body dimensions: 20.3x10.3x15.8mm Release time: 5ms Contact resistance: 100mΩ Coil current: 8.3mA Enclosure description: hermetic seal Operating temperature: -40...85°C Terminal pitch: 2.54mm Coil power consumption: 200mW | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EU 5VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A Type of relay: electromagnetic Switched voltage: max. 30V DC; max. 277V AC Manufacturer series: G5Q-EU Relay variant: miniature Mounting: PCB Body dimensions: 20.3x10.3x15.8mm Operating temperature: -40...85°C Enclosure description: hermetic seal Contacts configuration: SPST-NO Terminal pitch: 2.54mm Release time: 5ms Operate time: 10ms Coil current: 40mA Contact resistance: 100mΩ Coil power consumption: 200mW Rated coil voltage: 5V DC DC contacts rating @R: 5A / 30V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC Coil resistance: 125Ω | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-1A4-EU DC6 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 10A; 10A/250VAC; PCB Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 6V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Operate time: 10ms Body dimensions: 20x10x15.5mm Release time: 5ms Mechanical durability: 10000000 cycles Contact resistance: 100mΩ Contact material: silver alloy Leads: for soldering Enclosure description: hermetic seal Operating temperature: -40...85°C | auf Bestellung 311 Stücke:Lieferzeit 14-21 Tag (e) |
 | ||||||||||||
| G5Q-1A4-EU-HA DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Manufacturer series: G5Q-EU Type of relay: electromagnetic Mounting: PCB Leads: for soldering Enclosure description: hermetic seal Application: Home Relay variant: miniature Contact material: silver alloy Contacts configuration: SPST-NO Operating temperature: -40...85°C Release time: 5ms Coil current: 16.7mA Operate time: 10ms Body dimensions: 20x10x15.5mm Contact resistance: 100mΩ DC contacts rating @R: 5A / 30V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC Rated coil voltage: 12V DC Switched voltage: max. 30V DC; max. 277V AC Coil resistance: 720Ω Mechanical durability: 10000000 cycles | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
| G5Q-1A4-EU-HA DC12 (TY) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A Manufacturer series: G5Q-EU Type of relay: electromagnetic Mounting: PCB Leads: for soldering Enclosure description: hermetic seal Application: Home Relay variant: miniature Contact material: silver alloy Contacts configuration: SPST-NO Operating temperature: -40...85°C Release time: 5ms Coil current: 16.7mA Operate time: 10ms Body dimensions: 20x10x15.5mm Contact resistance: 100mΩ DC contacts rating @R: 5A / 30V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC Rated coil voltage: 12V DC Switched voltage: max. 30V DC; max. 277V AC Coil resistance: 720Ω Mechanical durability: 10000000 cycles | Produkt ist nicht verfügbar | Im Einkaufswagen Stück im Wert von UAH | |||||||||||||
|   | G5Q-14 5DC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; G5Q Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 3A / 250V AC DC contacts rating @R: 3A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 63Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 80mA Operating temperature: -40...85°C Terminal pitch: 2.54mm Anzahl je Verpackung: 1 Stücke | auf Bestellung 479 Stücke:Lieferzeit 7-14 Tag (e) |
 | ||||||||||||
|   | G5Q-14 DC12 | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-14  DC12 - Leistungsrelais, SPDT, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil tariffCode: 85364190 rohsCompliant: YES Relaisanschlüsse: PC-Pin hazardous: false rohsPhthalatesCompliant: YES Spulentyp: Monostabil Kontaktmaterial: Silberlegierung Kontaktstrom: 10A usEccn: EAR99 Spulenwiderstand: 360ohm euEccn: NLR Kontaktspannung V DC: - Relaismontage: Durchsteckmontage Produktpalette: G5Q Series productTraceability: No Spulenspannung: 12VDC Kontaktkonfiguration: SPDT Kontaktspannung V AC: 125V SVHC: To Be Advised | auf Bestellung 661 Stücke:Lieferzeit 14-21 Tag (e) | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-14 DC12 | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 3A / 250V AC DC contacts rating @R: 3A / 30V DC Manufacturer series: G5Q Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 360Ω Body dimensions: 20.3x10.3x15.8mm Contact resistance: 100mΩ Coil current: 33.3mA Operating temperature: -40...85°C Terminal pitch: 2.54mm Anzahl je Verpackung: 1 Stücke | auf Bestellung 421 Stücke:Lieferzeit 7-14 Tag (e) |
 | ||||||||||||
|   | G5Q-14-EU 12VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 12V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 360Ω Operate time: 10ms Body dimensions: 20.3x10.3x15.8mm Release time: 5ms Contact resistance: 100mΩ Coil current: 33.3mA Enclosure description: hermetic seal Operating temperature: -40...85°C Terminal pitch: 2.54mm Coil power consumption: 400mW Anzahl je Verpackung: 1 Stücke | auf Bestellung 591 Stücke:Lieferzeit 7-14 Tag (e) |
 | ||||||||||||
|   | G5Q-14-EU 24VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10A Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 1.44kΩ Operate time: 10ms Body dimensions: 20.3x10.3x15.8mm Release time: 5ms Contact resistance: 100mΩ Coil current: 16.7mA Enclosure description: hermetic seal Operating temperature: -40...85°C Terminal pitch: 2.54mm Coil power consumption: 400mW Anzahl je Verpackung: 1 Stücke | auf Bestellung 1108 Stücke:Lieferzeit 7-14 Tag (e) |
 | ||||||||||||
|   | G5Q-14-EU 5VDC | OMRON Electronic Components |  Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; PCB Type of relay: electromagnetic Contacts configuration: SPDT Rated coil voltage: 5V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 5A / 30V DC Manufacturer series: G5Q-EU Switched voltage: max. 30V DC; max. 277V AC Relay variant: miniature Mounting: PCB Coil resistance: 63Ω Operate time: 10ms Body dimensions: 20.3x10.3x15.8mm Release time: 5ms Coil power consumption: 400mW Contact resistance: 100mΩ Terminal pitch: 2.54mm Coil current: 80mA Enclosure description: hermetic seal Operating temperature: -40...85°C Anzahl je Verpackung: 1 Stücke | auf Bestellung 380 Stücke:Lieferzeit 7-14 Tag (e) |
 | ||||||||||||
|   | G5Q-14-EU DC12 | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC12 - POWER RELAY, SPDT, 10A, 250VAC, TH tariffCode: 85364190 productTraceability: Yes-Date/Lot Code rohsCompliant: YES euEccn: NLR hazardous: false rohsPhthalatesCompliant: YES directShipCharge: 25 usEccn: EAR99 | auf Bestellung 240 Stücke:Lieferzeit 14-21 Tag (e) | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-14EU DC12 | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-14EU  DC12 - Universelles Leistungsrelais, Baureihe G5Q, monostabil, SPDT, 12V DC, 10A tariffCode: 85364190 rohsCompliant: YES Zulassungen & Normen: CSA, IEC, UL, VDE Relaisanschlüsse: Lötanschlüsse hazardous: false rohsPhthalatesCompliant: YES Spulentyp: Monostabil Kontaktmaterial: Silberlegierung Kontaktstrom: 10A usEccn: EAR99 Spulenwiderstand: 360ohm euEccn: NLR Kontaktspannung V DC: 30V Relaismontage: Durchsteckmontage Produktpalette: G5Q Series productTraceability: No Spulenspannung: 12VDC Kontaktkonfiguration: SPDT Kontaktspannung V AC: 250V | auf Bestellung 1270 Stücke:Lieferzeit 14-21 Tag (e) | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-14-EU DC5 | OMRON ELECTRONIC COMPONENTS |  Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC5 - POWER RELAY, SPDT, 5VDC, 10A, THT tariffCode: 85364190 productTraceability: Yes-Date/Lot Code rohsCompliant: YES euEccn: NLR hazardous: false rohsPhthalatesCompliant: YES directShipCharge: 25 usEccn: EAR99 | auf Bestellung 516 Stücke:Lieferzeit 14-21 Tag (e) | Im Einkaufswagen Stück im Wert von UAH | ||||||||||||
|   | G5Q-14-EU-HA DC12 (SP) | OMRON Electronic Components | Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A Manufacturer series: G5Q-EU Type of relay: electromagnetic Mounting: PCB Leads: for soldering Enclosure description: hermetic seal Application: Home Relay variant: miniature Contact material: silver alloy Contacts configuration: SPDT Operating temperature: -40...85°C Release time: 5ms Coil current: 33.3mA Operate time: 10ms Body dimensions: 20x10x15.5mm Contact resistance: 100mΩ DC contacts rating @R: 5A / 30V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC Rated coil voltage: 12V DC Switched voltage: max. 30V DC; max. 277V AC Coil resistance: 360Ω Mechanical durability: 10000000 cycles Anzahl je Verpackung: 1 Stücke | auf Bestellung 348 Stücke:Lieferzeit 7-14 Tag (e) |
 |
| G5Q-1A-EL2-HA DC12 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EL2-HA DC24 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EU 12VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
Contacts configuration: SPST-NO
Enclosure description: standard seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Coil current: 16.7mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
DC contacts rating @R: 5A / 30V DC
AC contacts rating @R: 10A / 250V AC
Contact current max.: 10A
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Relay variant: miniature
Contacts configuration: SPST-NO
Enclosure description: standard seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Coil current: 16.7mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
DC contacts rating @R: 5A / 30V DC
AC contacts rating @R: 10A / 250V AC
Contact current max.: 10A
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
auf Bestellung 878 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 37+ | 1.97 EUR |
| 40+ | 1.79 EUR |
| 55+ | 1.3 EUR |
| 59+ | 1.23 EUR |
| G5Q-1A-EU 24VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Switched voltage: max. 30V DC; max. 277V AC
Manufacturer series: G5Q-EU
Relay variant: miniature
Mounting: PCB
Body dimensions: 20.3x10.3x15.8mm
Operating temperature: -40...85°C
Contacts configuration: SPST-NO
Enclosure description: standard seal
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Coil current: 8.3mA
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Contact resistance: 100mΩ
Coil power consumption: 200mW
Contact current max.: 10A
Rated coil voltage: 24V DC
Coil resistance: 2.88kΩ
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Switched voltage: max. 30V DC; max. 277V AC
Manufacturer series: G5Q-EU
Relay variant: miniature
Mounting: PCB
Body dimensions: 20.3x10.3x15.8mm
Operating temperature: -40...85°C
Contacts configuration: SPST-NO
Enclosure description: standard seal
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Coil current: 8.3mA
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Contact resistance: 100mΩ
Coil power consumption: 200mW
Contact current max.: 10A
Rated coil voltage: 24V DC
Coil resistance: 2.88kΩ
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EU DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...85°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EU DC24 (TY) |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A-EU DC24 (TY) - Leistungsrelais, SPST-NO, 24 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
Relaisanschlüsse: PC-Pin
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung, cadmiumfrei
Kontaktstrom: 10
Spulenwiderstand: 2.88
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
Spulenspannung: 24
Kontaktkonfiguration: SPST-NO
Kontaktspannung V AC: 250
SVHC: No SVHC (10-Jun-2022)
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A-EU DC24 (TY) - Leistungsrelais, SPST-NO, 24 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
Relaisanschlüsse: PC-Pin
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung, cadmiumfrei
Kontaktstrom: 10
Spulenwiderstand: 2.88
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
Spulenspannung: 24
Kontaktkonfiguration: SPST-NO
Kontaktspannung V AC: 250
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EU-HA DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...85°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...85°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-EU-HA-VH DC24(TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...85°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...85°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA DC12 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
auf Bestellung 465 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 35+ | 2.07 EUR |
| 36+ | 1.99 EUR |
| 53+ | 1.37 EUR |
| 55+ | 1.3 EUR |
| G5Q-1A-HA DC24 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
auf Bestellung 302 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 32+ | 2.26 EUR |
| 34+ | 2.16 EUR |
| 100+ | 1.96 EUR |
| G5Q-1A-HA DC5 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA DC5 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC12 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC24 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC5 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-PW DC5 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-VH DC24 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-VH DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-VH DC5 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HA-VH DC5 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Application: Home
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HR-HA-VH DC12 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HR-HA-VH DC24 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; G5Q; Home
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; G5Q; Home
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HR-HA-VH DC3 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 3VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 3V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Application: Home
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 3VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 3V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Application: Home
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-HR-HA-VH DC5 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; G5Q; 20x10x15.5mm
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Manufacturer series: G5Q
Body dimensions: 20x10x15.5mm
Operating temperature: -40...105°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC12 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: standard seal
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC24 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC5 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-PW DC5 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Operating temperature: -40...105°C
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 40mA
Leads: for soldering
Enclosure description: standard seal
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A-VH DC24 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 125V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 8.3mA
Leads: for soldering
Enclosure description: standard seal
Operating temperature: -40...105°C
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4 12DC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
auf Bestellung 54 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 36+ | 2.03 EUR |
| 40+ | 1.82 EUR |
| 47+ | 1.53 EUR |
| 50+ | 1.44 EUR |
| G5Q-1A4 5DC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 40mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 40mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
auf Bestellung 54 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 35+ | 2.09 EUR |
| 39+ | 1.84 EUR |
| 48+ | 1.52 EUR |
| 50+ | 1.43 EUR |
| G5Q-1A4 DC12 (TY) |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A4 DC12 (TY) - Leistungsrelais, SPST-NO, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
Relaisanschlüsse: PC-Pin
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung, cadmiumfrei
Kontaktstrom: 10
Spulenwiderstand: 720
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
Spulenspannung: 12
Kontaktkonfiguration: SPST-NO
Kontaktspannung V AC: 125
SVHC: No SVHC (10-Jun-2022)
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-1A4 DC12 (TY) - Leistungsrelais, SPST-NO, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
Relaisanschlüsse: PC-Pin
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung, cadmiumfrei
Kontaktstrom: 10
Spulenwiderstand: 720
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
Spulenspannung: 12
Kontaktkonfiguration: SPST-NO
Kontaktspannung V AC: 125
SVHC: No SVHC (10-Jun-2022)
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4 DC24 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EL2-HA DC12 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EL2-HA DC24 (TY) |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 1A / 250V AC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Application: Home
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 1A / 250V AC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Coil current: 16.7mA
Leads: for soldering
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Application: Home
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EL3-HA DC12 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 12V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 720Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 16.7mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EL3-HA DC24 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 8.3mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EL3-HA DC5 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 40mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 5A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 5V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 125Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 40mA
Operating temperature: -40...85°C
Terminal pitch: 7.62mm
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EU 12VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Contacts configuration: SPST-NO
Type of relay: electromagnetic
Mounting: PCB
Enclosure description: hermetic seal
Relay variant: miniature
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Operate time: 10ms
Coil current: 16.7mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
DC contacts rating @R: 5A / 30V DC
AC contacts rating @R: 10A / 250V AC
Contact current max.: 10A
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Manufacturer series: G5Q-EU
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Contacts configuration: SPST-NO
Type of relay: electromagnetic
Mounting: PCB
Enclosure description: hermetic seal
Relay variant: miniature
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Operate time: 10ms
Coil current: 16.7mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
DC contacts rating @R: 5A / 30V DC
AC contacts rating @R: 10A / 250V AC
Contact current max.: 10A
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Manufacturer series: G5Q-EU
auf Bestellung 224 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 37+ | 1.97 EUR |
| 40+ | 1.79 EUR |
| 55+ | 1.3 EUR |
| 59+ | 1.23 EUR |
| G5Q-1A4-EU 24VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 8.3mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 200mW
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 8.3mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 200mW
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EU 5VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Switched voltage: max. 30V DC; max. 277V AC
Manufacturer series: G5Q-EU
Relay variant: miniature
Mounting: PCB
Body dimensions: 20.3x10.3x15.8mm
Operating temperature: -40...85°C
Enclosure description: hermetic seal
Contacts configuration: SPST-NO
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Coil current: 40mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
Rated coil voltage: 5V DC
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Coil resistance: 125Ω
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 5VDC; Icontacts max: 10A
Type of relay: electromagnetic
Switched voltage: max. 30V DC; max. 277V AC
Manufacturer series: G5Q-EU
Relay variant: miniature
Mounting: PCB
Body dimensions: 20.3x10.3x15.8mm
Operating temperature: -40...85°C
Enclosure description: hermetic seal
Contacts configuration: SPST-NO
Terminal pitch: 2.54mm
Release time: 5ms
Operate time: 10ms
Coil current: 40mA
Contact resistance: 100mΩ
Coil power consumption: 200mW
Rated coil voltage: 5V DC
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Coil resistance: 125Ω
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EU DC6 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 10A; 10A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 6V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Leads: for soldering
Enclosure description: hermetic seal
Operating temperature: -40...85°C
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 10A; 10A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 6V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Release time: 5ms
Mechanical durability: 10000000 cycles
Contact resistance: 100mΩ
Contact material: silver alloy
Leads: for soldering
Enclosure description: hermetic seal
Operating temperature: -40...85°C
auf Bestellung 311 Stücke:
Lieferzeit 14-21 Tag (e)| Anzahl | Preis |
|---|---|
| 34+ | 2.12 EUR |
| 36+ | 2.02 EUR |
| 52+ | 1.39 EUR |
| 55+ | 1.32 EUR |
| G5Q-1A4-EU-HA DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPST-NO
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 16.7mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Mechanical durability: 10000000 cycles
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPST-NO
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 16.7mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Mechanical durability: 10000000 cycles
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-1A4-EU-HA DC12 (TY) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPST-NO
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 16.7mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Mechanical durability: 10000000 cycles
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPST-NO
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 16.7mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 720Ω
Mechanical durability: 10000000 cycles
Produkt ist nicht verfügbar
    Im Einkaufswagen
     Stück im Wert von     UAH
| G5Q-14 5DC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; G5Q
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 63Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 80mA
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; G5Q
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 63Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 80mA
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 479 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 41+ | 1.76 EUR |
| 47+ | 1.54 EUR |
| 56+ | 1.29 EUR |
| 57+ | 1.27 EUR |
| 59+ | 1.22 EUR |
| G5Q-14 DC12 |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-14 DC12 - Leistungsrelais, SPDT, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
tariffCode: 85364190
rohsCompliant: YES
Relaisanschlüsse: PC-Pin
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung
Kontaktstrom: 10A
usEccn: EAR99
Spulenwiderstand: 360ohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
productTraceability: No
Spulenspannung: 12VDC
Kontaktkonfiguration: SPDT
Kontaktspannung V AC: 125V
SVHC: To Be Advised
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-14 DC12 - Leistungsrelais, SPDT, 12 VDC, 10 A, G5Q Series, Durchsteckmontage, Monostabil
tariffCode: 85364190
rohsCompliant: YES
Relaisanschlüsse: PC-Pin
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung
Kontaktstrom: 10A
usEccn: EAR99
Spulenwiderstand: 360ohm
euEccn: NLR
Kontaktspannung V DC: -
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
productTraceability: No
Spulenspannung: 12VDC
Kontaktkonfiguration: SPDT
Kontaktspannung V AC: 125V
SVHC: To Be Advised
auf Bestellung 661 Stücke:
Lieferzeit 14-21 Tag (e)Im Einkaufswagen Stück im Wert von UAH
| G5Q-14 DC12 |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 33.3mA
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Manufacturer series: G5Q
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Body dimensions: 20.3x10.3x15.8mm
Contact resistance: 100mΩ
Coil current: 33.3mA
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 421 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 33+ | 2.22 EUR |
| 38+ | 1.89 EUR |
| 46+ | 1.59 EUR |
| 48+ | 1.5 EUR |
| G5Q-14-EU 12VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 33.3mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 400mW
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 12V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 360Ω
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 33.3mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 400mW
Anzahl je Verpackung: 1 Stücke
auf Bestellung 591 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 32+ | 2.3 EUR |
| 34+ | 2.13 EUR |
| 43+ | 1.67 EUR |
| 46+ | 1.59 EUR |
| 500+ | 1.52 EUR |
| G5Q-14-EU 24VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 16.7mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 400mW
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10A
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 24V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 1.44kΩ
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Contact resistance: 100mΩ
Coil current: 16.7mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Terminal pitch: 2.54mm
Coil power consumption: 400mW
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1108 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 33+ | 2.23 EUR |
| 36+ | 2.03 EUR |
| 49+ | 1.47 EUR |
| 52+ | 1.39 EUR |
| 500+ | 1.37 EUR |
| G5Q-14-EU 5VDC |  |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; PCB
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 63Ω
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Coil power consumption: 400mW
Contact resistance: 100mΩ
Terminal pitch: 2.54mm
Coil current: 80mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 5VDC; Icontacts max: 10A; PCB
Type of relay: electromagnetic
Contacts configuration: SPDT
Rated coil voltage: 5V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 5A / 30V DC
Manufacturer series: G5Q-EU
Switched voltage: max. 30V DC; max. 277V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 63Ω
Operate time: 10ms
Body dimensions: 20.3x10.3x15.8mm
Release time: 5ms
Coil power consumption: 400mW
Contact resistance: 100mΩ
Terminal pitch: 2.54mm
Coil current: 80mA
Enclosure description: hermetic seal
Operating temperature: -40...85°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 380 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 37+ | 1.94 EUR |
| 41+ | 1.76 EUR |
| 56+ | 1.29 EUR |
| 57+ | 1.27 EUR |
| 59+ | 1.22 EUR |
| 520+ | 1.2 EUR |
| G5Q-14-EU DC12 |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC12 - POWER RELAY, SPDT, 10A, 250VAC, TH
tariffCode: 85364190
productTraceability: Yes-Date/Lot Code
rohsCompliant: YES
euEccn: NLR
hazardous: false
rohsPhthalatesCompliant: YES
directShipCharge: 25
usEccn: EAR99
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC12 - POWER RELAY, SPDT, 10A, 250VAC, TH
tariffCode: 85364190
productTraceability: Yes-Date/Lot Code
rohsCompliant: YES
euEccn: NLR
hazardous: false
rohsPhthalatesCompliant: YES
directShipCharge: 25
usEccn: EAR99
auf Bestellung 240 Stücke:
Lieferzeit 14-21 Tag (e)Im Einkaufswagen Stück im Wert von UAH
| G5Q-14EU DC12 |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-14EU DC12 - Universelles Leistungsrelais, Baureihe G5Q, monostabil, SPDT, 12V DC, 10A
tariffCode: 85364190
rohsCompliant: YES
Zulassungen & Normen: CSA, IEC, UL, VDE
Relaisanschlüsse: Lötanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung
Kontaktstrom: 10A
usEccn: EAR99
Spulenwiderstand: 360ohm
euEccn: NLR
Kontaktspannung V DC: 30V
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
productTraceability: No
Spulenspannung: 12VDC
Kontaktkonfiguration: SPDT
Kontaktspannung V AC: 250V
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-14EU DC12 - Universelles Leistungsrelais, Baureihe G5Q, monostabil, SPDT, 12V DC, 10A
tariffCode: 85364190
rohsCompliant: YES
Zulassungen & Normen: CSA, IEC, UL, VDE
Relaisanschlüsse: Lötanschlüsse
hazardous: false
rohsPhthalatesCompliant: YES
Spulentyp: Monostabil
Kontaktmaterial: Silberlegierung
Kontaktstrom: 10A
usEccn: EAR99
Spulenwiderstand: 360ohm
euEccn: NLR
Kontaktspannung V DC: 30V
Relaismontage: Durchsteckmontage
Produktpalette: G5Q Series
productTraceability: No
Spulenspannung: 12VDC
Kontaktkonfiguration: SPDT
Kontaktspannung V AC: 250V
auf Bestellung 1270 Stücke:
Lieferzeit 14-21 Tag (e)Im Einkaufswagen Stück im Wert von UAH
| G5Q-14-EU DC5 |  |
Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC5 - POWER RELAY, SPDT, 5VDC, 10A, THT
tariffCode: 85364190
productTraceability: Yes-Date/Lot Code
rohsCompliant: YES
euEccn: NLR
hazardous: false
rohsPhthalatesCompliant: YES
directShipCharge: 25
usEccn: EAR99
    Description: OMRON ELECTRONIC COMPONENTS - G5Q-14-EU DC5 - POWER RELAY, SPDT, 5VDC, 10A, THT
tariffCode: 85364190
productTraceability: Yes-Date/Lot Code
rohsCompliant: YES
euEccn: NLR
hazardous: false
rohsPhthalatesCompliant: YES
directShipCharge: 25
usEccn: EAR99
auf Bestellung 516 Stücke:
Lieferzeit 14-21 Tag (e)Im Einkaufswagen Stück im Wert von UAH
| G5Q-14-EU-HA DC12 (SP) |
Hersteller: OMRON Electronic Components
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPDT
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 33.3mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 360Ω
Mechanical durability: 10000000 cycles
Anzahl je Verpackung: 1 Stücke
    Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; Icontacts max: 10A
Manufacturer series: G5Q-EU
Type of relay: electromagnetic
Mounting: PCB
Leads: for soldering
Enclosure description: hermetic seal
Application: Home
Relay variant: miniature
Contact material: silver alloy
Contacts configuration: SPDT
Operating temperature: -40...85°C
Release time: 5ms
Coil current: 33.3mA
Operate time: 10ms
Body dimensions: 20x10x15.5mm
Contact resistance: 100mΩ
DC contacts rating @R: 5A / 30V DC
Contact current max.: 10A
AC contacts rating @R: 10A / 250V AC
Rated coil voltage: 12V DC
Switched voltage: max. 30V DC; max. 277V AC
Coil resistance: 360Ω
Mechanical durability: 10000000 cycles
Anzahl je Verpackung: 1 Stücke
auf Bestellung 348 Stücke:
Lieferzeit 7-14 Tag (e)| Anzahl | Preis |
|---|---|
| 34+ | 2.13 EUR |
| 35+ | 2.04 EUR |
| 51+ | 1.42 EUR |
| 54+ | 1.34 EUR |
