10127819-0441GPLF Amphenol Communications Solutions-FCI
Hersteller: Amphenol Communications Solutions-FCI
Conn Wire to Board HDR 4 POS 4.2mm Solder RA Side Entry Thru-Hole Tray
| Anzahl | Privatkunde |
|---|---|
| 68+ | 2.65 EUR |
| 250+ | 2.56 EUR |
| 500+ | 2.45 EUR |
| 960+ | 2.32 EUR |
Artikel auf Bestellung
Nicht an unserem Lager — wir beziehen ihn nach Ihrer Bestellung vom Lieferantenlager.
Lieferzeit:
14-21 Tag (e)
Mindestmenge:
68 Stücke
Produktrezensionen
Produktbewertung abgeben
Technische Details 10127819-0441GPLF Amphenol Communications Solutions-FCI
Description: 10127819-0441GPLF-MTK 4.2 DR 04P, Features: Board Lock, Glow Wire Compliant, Packaging: Tray, Connector Type: Header, Voltage Rating: 600VAC/DC, Current Rating (Amps): Varies by Wire Gauge, Mounting Type: Through Hole, Right Angle, Number of Positions: 4, Number of Rows: 2, Style: Board to Cable/Wire, Operating Temperature: -40°C ~ 105°C, Contact Type: Male Pin, Fastening Type: Locking Ramp, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Brass, Insulation Color: Natural, Pitch - Mating: 0.165" (4.20mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 30.0µin (0.76µm), Contact Shape: Square, Contact Length - Post: 0.138" (3.50mm), Insulation Height: 0.386" (9.80mm), Shrouding: Shrouded - 4 Wall, Insulation Material: Polyamide (PA66), Nylon 6/6, Row Spacing - Mating: 0.165" (4.20mm).
Weitere Produktangebote 10127819-0441GPLF
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
| 10127819-0441GPLF | AMPHENOL |
Category: Raster signal connectors 4,20mm Description: Connector: wire-board; male; PIN: 4; 9A; angled; soldering; 4.2mm Type of connector: wire-board Contact plating: gold-plated Spatial orientation: angled Contact material: brass Flammability rating: UL94V-0 Connector variant: Glow-Wire Contacts pitch: 4.2mm Number of pins: 4 Current rating: 9A Operating temperature: -40...105°C Electrical mounting: soldering Max. voltage: 600V AC Kind of connector: male Row pitch: 4.191mm |
auf Bestellung 960 Stücke: Lieferzeit 14-21 Tag (e) |
Mindestbestellmenge: 48 Stücke Im Einkaufswagen Stück im Wert von UAH |
| 10127819-0441GPLF |
|
Hersteller: AMPHENOL
Category: Raster signal connectors 4,20mm
Description: Connector: wire-board; male; PIN: 4; 9A; angled; soldering; 4.2mm
Type of connector: wire-board
Contact plating: gold-plated
Spatial orientation: angled
Contact material: brass
Flammability rating: UL94V-0
Connector variant: Glow-Wire
Contacts pitch: 4.2mm
Number of pins: 4
Current rating: 9A
Operating temperature: -40...105°C
Electrical mounting: soldering
Max. voltage: 600V AC
Kind of connector: male
Row pitch: 4.191mm
Category: Raster signal connectors 4,20mm
Description: Connector: wire-board; male; PIN: 4; 9A; angled; soldering; 4.2mm
Type of connector: wire-board
Contact plating: gold-plated
Spatial orientation: angled
Contact material: brass
Flammability rating: UL94V-0
Connector variant: Glow-Wire
Contacts pitch: 4.2mm
Number of pins: 4
Current rating: 9A
Operating temperature: -40...105°C
Electrical mounting: soldering
Max. voltage: 600V AC
Kind of connector: male
Row pitch: 4.191mm
auf Bestellung 960 Stücke:
Lieferzeit 14-21 Tag (e)
