1391647 Phoenix Contact
Hersteller: Phoenix Contact
Description: TERM BLOCK PLUG 5POS 15.24MM
Features: Mating Flange
Packaging: Bulk
Color: Green
Mounting Type: Free Hanging (In-Line)
Number of Positions: 5
Pitch: 0.600" (15.24mm)
Type: Plug, Female Sockets
Operating Temperature: -40°C ~ 105°C
Termination Style: Screw - Clamping Yoke (Tension Sleeve)
Current - IEC: 41A
Number of Levels: 1
Wire Gauge or Range - AWG: 8-24 AWG
Wire Gauge or Range - mm²: 0.2-10mm²
Positions Per Level: 5
Plug Wire Entry: 180°
Contact Mating Finish: Tin
Current - UL: 41 A
Voltage - IEC: 1 kV
Voltage - UL: 600 V
Produktrezensionen
Produktbewertung abgeben
Technische Details 1391647 Phoenix Contact
Description: TERM BLOCK PLUG 5POS 15.24MM, Features: Mating Flange, Packaging: Bulk, Color: Green, Mounting Type: Free Hanging (In-Line), Number of Positions: 5, Pitch: 0.600" (15.24mm), Type: Plug, Female Sockets, Operating Temperature: -40°C ~ 105°C, Termination Style: Screw - Clamping Yoke (Tension Sleeve), Current - IEC: 41A, Number of Levels: 1, Wire Gauge or Range - AWG: 8-24 AWG, Wire Gauge or Range - mm²: 0.2-10mm², Positions Per Level: 5, Plug Wire Entry: 180°, Contact Mating Finish: Tin, Current - UL: 41 A, Voltage - IEC: 1 kV, Voltage - UL: 600 V.
Weitere Produktangebote 1391647
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
|---|---|---|---|---|---|
 |
1391647 | Hersteller : Phoenix Contact |
Pluggable Terminal Blocks PC 5/ 5-STF1-15 24 |
Produkt ist nicht verfügbar |
|
 |
1391647 | Hersteller : PHOENIX CONTACT |
Category: Pluggable terminal blocks Description: Connector: pluggable terminal block; plug; COMBICON L; 32A; 1kV Electrical mounting: screw terminal Connector: plug Type of connector: pluggable terminal block Locking system: threaded joint Contact plating: tinned Flammability rating: UL94V-0 Contacts pitch: 15.24mm Height: 19.7mm Length: 35.25mm Width: 83.8mm Number of pins: 5 Current rating: 32A Rated voltage: 1kV Manufacturer series: COMBICON L Body colour: green Body material: PA |
Produkt ist nicht verfügbar |
