1825057-6 TE Connectivity
Hersteller: TE Connectivity
Category: Dip-Switches
Description: Switch: DIP-SWITCH; Poles number: 7; OFF-ON; 0.1A/24VDC; Pos: 2; THT
Contact plating: gold-plated
Terminal pitch: 2.54mm
Mounting: THT
Contact material: copper alloy
Manufacturer series: ADE
Flammability rating: UL94V-0
Poles number: 7
Type of switch: DIP-SWITCH
DC contacts rating @R: 0.1A / 24V DC
Body colour: black
Operating temperature: -30...85°C
Contacts configuration: SPST
Stable positions number: 2
Leads: for soldering
Switching method: OFF-ON
Min. insulation resistance: 1GΩ
Max. contact resistance:: 50mΩ
Electrical life: 1000 cycles
Illumination: none
Number of positions: 2
Produktrezensionen
Produktbewertung abgeben
Technische Details 1825057-6 TE Connectivity
Category: Dip-Switches, Description: Switch: DIP-SWITCH; Poles number: 7; OFF-ON; 0.1A/24VDC; Pos: 2; THT, Contact plating: gold-plated, Terminal pitch: 2.54mm, Mounting: THT, Contact material: copper alloy, Manufacturer series: ADE, Flammability rating: UL94V-0, Poles number: 7, Type of switch: DIP-SWITCH, DC contacts rating @R: 0.1A / 24V DC, Body colour: black, Operating temperature: -30...85°C, Contacts configuration: SPST, Stable positions number: 2, Leads: for soldering, Switching method: OFF-ON, Min. insulation resistance: 1GΩ, Max. contact resistance:: 50mΩ, Electrical life: 1000 cycles, Illumination: none, Number of positions: 2.
Weitere Produktangebote 1825057-6 nach Preis ab 1.92 EUR bis 3.72 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1825057-6 | TE Connectivity |
DIP Switches/SIP Switches SWITCH DIP SWITCH |
auf Bestellung 2298 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||||||
 |
1825057-6 | TE Connectivity ALCOSWITCH Switches |
Description: SWITCH DIP SLIDE SPST 100MA 24V Packaging: Tube Contact Finish: Gold Voltage Rating: 24VDC Current Rating (Amps): 100mA Mounting Type: Through Hole Pitch: 0.100" (2.54mm), Full Circuit: SPST Operating Temperature: -30°C ~ 85°C Termination Style: PC Pin Actuator Type: Slide (Standard) Height Above Board: 0.228" (5.80mm) Actuator Level: Raised Washable: Yes Contact Material: Copper Alloy Part Status: Active Number of Positions: 7 |
auf Bestellung 5774 Stücke: Lieferzeit 10-14 Tag (e) |
|
| 1825057-6 |
|
Hersteller: TE Connectivity
DIP Switches/SIP Switches SWITCH DIP SWITCH
DIP Switches/SIP Switches SWITCH DIP SWITCH
auf Bestellung 2298 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 3.39 EUR |
| 10+ | 3.01 EUR |
| 20+ | 2.53 EUR |
| 100+ | 2.34 EUR |
| 260+ | 2.14 EUR |
| 500+ | 2.03 EUR |
| 1000+ | 1.92 EUR |
| 1825057-6 |
|
Hersteller: TE Connectivity ALCOSWITCH Switches
Description: SWITCH DIP SLIDE SPST 100MA 24V
Packaging: Tube
Contact Finish: Gold
Voltage Rating: 24VDC
Current Rating (Amps): 100mA
Mounting Type: Through Hole
Pitch: 0.100" (2.54mm), Full
Circuit: SPST
Operating Temperature: -30°C ~ 85°C
Termination Style: PC Pin
Actuator Type: Slide (Standard)
Height Above Board: 0.228" (5.80mm)
Actuator Level: Raised
Washable: Yes
Contact Material: Copper Alloy
Part Status: Active
Number of Positions: 7
Description: SWITCH DIP SLIDE SPST 100MA 24V
Packaging: Tube
Contact Finish: Gold
Voltage Rating: 24VDC
Current Rating (Amps): 100mA
Mounting Type: Through Hole
Pitch: 0.100" (2.54mm), Full
Circuit: SPST
Operating Temperature: -30°C ~ 85°C
Termination Style: PC Pin
Actuator Type: Slide (Standard)
Height Above Board: 0.228" (5.80mm)
Actuator Level: Raised
Washable: Yes
Contact Material: Copper Alloy
Part Status: Active
Number of Positions: 7
auf Bestellung 5774 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 6+ | 3.72 EUR |
| 20+ | 2.96 EUR |
| 40+ | 2.8 EUR |
| 100+ | 2.59 EUR |
| 260+ | 2.39 EUR |
| 500+ | 2.27 EUR |
| 1000+ | 2.15 EUR |
| 2500+ | 2.02 EUR |
| 5000+ | 1.93 EUR |
