2-1393224-7 TE Connectivity
Hersteller: TE Connectivity
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 8A
Mounting: THT
Operating temperature: -40...70°C
Contact material: AgNi
Coil resistance: 627Ω
Contacts configuration: SPST-NC
Type of relay: electromagnetic
Relay variant: miniature
Relay series: RYII
Rated coil voltage: 12V DC
Coil voltage min.: 8.4V DC
Coil power consumption: 230mW
Operate time: 9ms
Release time: 5ms
Switched voltage: max. 250V AC
Contact current max.: 8A
Coil current: 19.1mA
Mechanical durability: 30000000 cycles
Terminal pitch: 5mm
Body dimensions: 28.5x12.3x10.1mm
Height: 12.3mm
Anzahl je Verpackung: 1 Stücke
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 8A
Mounting: THT
Operating temperature: -40...70°C
Contact material: AgNi
Coil resistance: 627Ω
Contacts configuration: SPST-NC
Type of relay: electromagnetic
Relay variant: miniature
Relay series: RYII
Rated coil voltage: 12V DC
Coil voltage min.: 8.4V DC
Coil power consumption: 230mW
Operate time: 9ms
Release time: 5ms
Switched voltage: max. 250V AC
Contact current max.: 8A
Coil current: 19.1mA
Mechanical durability: 30000000 cycles
Terminal pitch: 5mm
Body dimensions: 28.5x12.3x10.1mm
Height: 12.3mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 48 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
13+ | 5.85 EUR |
21+ | 3.52 EUR |
22+ | 3.32 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 2-1393224-7 TE Connectivity
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 8A, Mounting: THT, Operating temperature: -40...70°C, Contact material: AgNi, Coil resistance: 627Ω, Contacts configuration: SPST-NC, Type of relay: electromagnetic, Relay variant: miniature, Relay series: RYII, Rated coil voltage: 12V DC, Coil voltage min.: 8.4V DC, Coil power consumption: 230mW, Operate time: 9ms, Release time: 5ms, Switched voltage: max. 250V AC, Contact current max.: 8A, Coil current: 19.1mA, Mechanical durability: 30000000 cycles, Terminal pitch: 5mm, Body dimensions: 28.5x12.3x10.1mm, Height: 12.3mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote 2-1393224-7 nach Preis ab 3.32 EUR bis 5.85 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
2-1393224-7 | Hersteller : TE Connectivity |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NC; Ucoil: 12VDC; Icontacts max: 8A Mounting: THT Operating temperature: -40...70°C Contact material: AgNi Coil resistance: 627Ω Contacts configuration: SPST-NC Type of relay: electromagnetic Relay variant: miniature Relay series: RYII Rated coil voltage: 12V DC Coil voltage min.: 8.4V DC Coil power consumption: 230mW Operate time: 9ms Release time: 5ms Switched voltage: max. 250V AC Contact current max.: 8A Coil current: 19.1mA Mechanical durability: 30000000 cycles Terminal pitch: 5mm Body dimensions: 28.5x12.3x10.1mm Height: 12.3mm |
auf Bestellung 48 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||
2-1393224-7 | Hersteller : SCHRACK - TE CONNECTIVITY |
Description: SCHRACK - TE CONNECTIVITY - 2-1393224-7 - Leistungsrelais, SPST-NC, 12 VDC, 8 A, RY, Durchsteckmontage, Monostabil tariffCode: 85364190 rohsCompliant: YES Zulassungen & Normen: UL Relaisanschlüsse: Lötanschlüsse hazardous: false rohsPhthalatesCompliant: YES Spulentyp: Monostabil Kontaktmaterial: Silber-Nickel Kontaktstrom: 8A usEccn: EAR99 Spulenwiderstand: 627ohm euEccn: NLR Kontaktspannung V DC: - Relaismontage: Durchsteckmontage Produktpalette: RY productTraceability: Yes-Date/Lot Code Spulenspannung: 12VDC Kontaktkonfiguration: SPST-NC Kontaktspannung V AC: 250V SVHC: Diphenyl(2,4,6-trimethylbenzoyl)phosphine oxide (14-Jun-2023) |
auf Bestellung 449 Stücke: Lieferzeit 14-21 Tag (e) |
||||||||||
2-1393224-7 | Hersteller : TE Connectivity | Power Relay 12VDC 8A SPST-NC(28.5mm 10.1mm 12.3mm) THT |
Produkt ist nicht verfügbar |
||||||||||
2-1393224-7 | Hersteller : TE Connectivity Potter & Brumfield Relays |
Description: RELAY GEN PURPOSE SPST 8A 12V Packaging: Tube Mounting Type: Through Hole Coil Voltage: 12VDC Operating Temperature: -40°C ~ 70°C Termination Style: PC Pin Relay Type: General Purpose Coil Type: Non Latching Contact Material: Silver Nickel (AgNi) Contact Form: SPST-NC (1 Form B) Contact Rating (Current): 8 A Switching Voltage: 400VAC Must Release Voltage: 1.2 VDC Must Operate Voltage: 8.4 VDC Operate Time: 9 ms Release Time: 5 ms Coil Insulation: Class F |
Produkt ist nicht verfügbar |
