2170934 LAPP
Hersteller: LAPP
Description: ETHERLINE CAT.7 FLEX 4X2X26/7
Packaging: Spool
Length: 3280.0' (999.7m)
Wire Gauge: 26 AWG
Jacket (Insulation) Material: Polyurethane (PU)
Operating Temperature: -40°C ~ 80°C
Number of Conductors: 8 (4 Pair Twisted)
Cable Type: Multi-Pair, Cat7
Jacket (Insulation) Diameter: 0.250" (6.35mm)
Conductor Insulation: Polyethylene (PE)
Shield Type: Foil, Braid
Conductor Material: Copper, Bare
Jacket Color: Green
Voltage: 125 V
| Anzahl | Preis |
|---|---|
| 3280+ | 4.64 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 2170934 LAPP
Category: Industrial Ethernet Cables, Description: Wire; S/FTP; ETHERLINE® Cat.7; 4x2x26AWG; Cat 7; stranded; Cu; PUR, Type of wire: data transmission, Kind of cable: S/FTP, Ethernet category: Cat 7, Cable structure: 4x2x26AWG, Kind of core: Cu, Core structure: stranded, Number of cores: 8, No. of pairs: 4, Shield structure: braid made of copper wires; pairs shielded with Al-PET foil; shielded twofold, Wire insulation material: PUR, Insulation colour: green, Cable features: twisted pair conductors, Cable external diameter: 6.4mm, Cable application: EtherCAT; EtherNet/IP; industrial applications; industrial Ethernet, Operating temperature: -50...80°C, Information: The UL Label and Mark on full factory packaging only, Kind of material: halogen free; no flame propagation, Conform to the norm: FT2; IEC 60332-1-2; UL 758; UL 21576, Manufacturer series: ETHERLINE® Cat.7, Core diameter: 26AWG, Rated voltage: 0.125kV, CPR standard: no classification, Resistance to: flame; mechanical stesses; mineral oils; most of oils; UV rays.
Weitere Produktangebote 2170934 nach Preis ab 3.9 EUR bis 9.68 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
2170934 | Hersteller : LAPP |
Category: Industrial Ethernet Cables Description: Wire; S/FTP; ETHERLINE® Cat.7; 4x2x26AWG; Cat 7; stranded; Cu; PUR Type of wire: data transmission Kind of cable: S/FTP Ethernet category: Cat 7 Cable structure: 4x2x26AWG Kind of core: Cu Core structure: stranded Number of cores: 8 No. of pairs: 4 Shield structure: braid made of copper wires; pairs shielded with Al-PET foil; shielded twofold Wire insulation material: PUR Insulation colour: green Cable features: twisted pair conductors Cable external diameter: 6.4mm Cable application: EtherCAT; EtherNet/IP; industrial applications; industrial Ethernet Operating temperature: -50...80°C Information: The UL Label and Mark on full factory packaging only Kind of material: halogen free; no flame propagation Conform to the norm: FT2; IEC 60332-1-2; UL 758; UL 21576 Manufacturer series: ETHERLINE® Cat.7 Core diameter: 26AWG Rated voltage: 0.125kV CPR standard: no classification Resistance to: flame; mechanical stesses; mineral oils; most of oils; UV rays |
auf Bestellung 533 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||
|
|
2170934 | Hersteller : LAPP |
Description: ETHERLINE CAT.7 FLEX 4X2X26/7 Packaging: Digi-Spool®, Continuous Spool Length: 3280.0' (999.7m) Wire Gauge: 26 AWG Jacket (Insulation) Material: Polyurethane (PU) Operating Temperature: -40°C ~ 80°C Number of Conductors: 8 (4 Pair Twisted) Cable Type: Multi-Pair, Cat7 Jacket (Insulation) Diameter: 0.250" (6.35mm) Conductor Insulation: Polyethylene (PE) Shield Type: Foil, Braid Conductor Material: Copper, Bare Jacket Color: Green Voltage: 125 V |
auf Bestellung 2446 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
2170934 | Hersteller : LAPP |
Description: LAPP - 2170934 - Netzwerkkabel, Geschirmt, Cat7, 26 AWG, 0.14 mm², 328.084 ft, 100 m tariffCode: 85444290 Länge auf Rolle (metrisch): 100m Leitermaterial: Blankes Kupfer Anzahl der Adernpaare: 4 rohsCompliant: YES hazardous: false rohsPhthalatesCompliant: YES Drahtdurchmesser: 26AWG isCanonical: Y Mantelmaterial: TPU usEccn: EAR99 Länge auf Rolle (imperial): 328.084ft Mantelfarbe: Grün Leiterquerschnitt CSA: 0.14mm² euEccn: NLR Max. Anzahl d. Einzeldrähte x Einzeldrahtgröße: 7 x 26AWG Außendurchmesser: 6.4mm Produktpalette: ETHERLINE Series LAN-Kategorie: Cat7 productTraceability: No Nennspannung: 125V Kabelabschirmung: Geschirmt SVHC: No SVHC (25-Jun-2025) |
auf Bestellung 5 Stücke: Lieferzeit 14-21 Tag (e) |
|||||||||||||||
 |
2170934 | Hersteller : LAPP |
Ethernet Cables / Networking Cables ETHERLINE Cat.7 FLEX 4x2x26/7 |
Produkt ist nicht verfügbar |
