22234 HELUKABEL

Category: Power Cords, Description: Wire; 2YSLCYK-J,TOPFLEX-EMV-UV; 4G1.5mm2; round; stranded; Cu; PE, Core marking: colours + ground wire, Kind of core: Cu, Cable application: frequency converters wiring; motors power 0,6/1 kV; outdoor, Type of wire: mains, CPR standard: no classification, Wire insulation material: PE, Wire cross-section shape: round, Core structure: stranded, Resistance to: UV rays, Earth core: yellow-green, Operating temperature: -40...70°C, Core section: 1.5mm2, Cable external diameter: 10.1mm, Number of cores: 4, Cable structure: 4G1.5mm2, Flexibility class: 5, Max. current load: 18A, Max motor power: 0.09kW; 0.1kW; 0.1/0.2kW; 0.12kW; 0.18kW; 0.2kW; 0.2/0.4kW; 0.25kW; 0.37kW; 0.4kW; 0.4/0.55kW; 0.4/0.75kW; 0.55kW; 0.75kW; 0.75/1.1kW; 0.75/1.5kW; 1.1kW; 1.5kW, Rated voltage: 0.6kV; 1kV, Kind of wire: 2YSLCYK-J; TOPFLEX-EMV-UV, Shield structure: Al foil; braid made of copper wires; shielded twofold, Insulation colour: black, Anzahl je Verpackung: 1 Stücke.
