2842131-5 TE Connectivity AMP Connectors
Hersteller: TE Connectivity AMP Connectors
Description: 10P,2MM,BRK HDR,DRVT,2.8,0.38AU,
Overall Contact Length: 0.327" (8.30mm)
Shrouding: Unshrouded
Insulation Height: 0.059" (1.50mm)
Contact Length - Post: 0.110" (2.79mm)
Contact Shape: Square
Part Status: Active
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 15.0µin (0.38µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.079" (2.00mm)
Insulation Color: Black
Contact Material: Copper Alloy
Contact Length - Mating: 0.157" (4.00mm)
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Male Pin
Operating Temperature: -40°C ~ 125°C
Style: Board to Board
Number of Rows: 2
Number of Positions: 10
Mounting Type: Through Hole
Current Rating (Amps): 2A
Voltage Rating: 125VAC/DC
Connector Type: Header, Breakaway
Row Spacing - Mating: 0.079" (2.00mm)
Insulation Material: Thermoplastic
Features: Pick and Place
Packaging: Tube
Material Flammability Rating: UL94 V-0
| Anzahl | Preis |
|---|---|
| 6+ | 3.15 EUR |
| 58+ | 2.27 EUR |
| 116+ | 2.15 EUR |
| 522+ | 1.9 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 2842131-5 TE Connectivity AMP Connectors
Description: 10P,2MM,BRK HDR,DRVT,2.8,0.38AU,, Overall Contact Length: 0.327" (8.30mm), Shrouding: Unshrouded, Insulation Height: 0.059" (1.50mm), Contact Length - Post: 0.110" (2.79mm), Contact Shape: Square, Part Status: Active, Contact Finish - Post: Tin, Contact Finish Thickness - Mating: 15.0µin (0.38µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.079" (2.00mm), Insulation Color: Black, Contact Material: Copper Alloy, Contact Length - Mating: 0.157" (4.00mm), Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Male Pin, Operating Temperature: -40°C ~ 125°C, Style: Board to Board, Number of Rows: 2, Number of Positions: 10, Mounting Type: Through Hole, Current Rating (Amps): 2A, Voltage Rating: 125VAC/DC, Connector Type: Header, Breakaway, Row Spacing - Mating: 0.079" (2.00mm), Insulation Material: Thermoplastic, Features: Pick and Place, Packaging: Tube, Material Flammability Rating: UL94 V-0.
Weitere Produktangebote 2842131-5 nach Preis ab 1.52 EUR bis 1.79 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2842131-5 | Hersteller : TE Connectivity |
Category: Raster signal connectors 2,00mm Description: Connector: pin strips; pin header; male; PIN: 10; AMPMODU; Inom: 2A Contact plating: gold-plated Kind of connector: male Mechanical mounting: on PCBs Body material: PA9T Connector variant: pick and place Connector: pin header Type of connector: pin strips Electrical mounting: soldering; THT Spatial orientation: straight Flammability rating: UL94V-0 Operating temperature: -40...125°C Contacts pitch: 2mm Maximum current: 2A Current rating: 2A Number of pins: 10 Manufacturer series: AMPMODU Body colour: black Contact material: brass |
auf Bestellung 4176 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||
| 2842131-5 | Hersteller : TE CONNECTIVITY / PARTNER STOCK |
Description: TE CONNECTIVITY / PARTNER STOCK - 2842131-5 - PIN HEADERS tariffCode: 85366990 productTraceability: No rohsCompliant: YES euEccn: NLR isCanonical: Y hazardous: false rohsPhthalatesCompliant: YES usEccn: EAR99 SVHC: No SVHC (21-Jan-2025) |
auf Bestellung 3770 Stücke: Lieferzeit 14-21 Tag (e) |
