2MM-HB-S25-VT-02-H-TB TE CONNECTIVITY
Hersteller: TE CONNECTIVITY
Description: TE CONNECTIVITY - 2MM-HB-S25-VT-02-H-TB - Stiftleiste, Board-to-Board, 2 mm, 1 Reihe(n), 25 Kontakt(e), Durchsteckmontage, gerade
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
usEccn: EAR99
Steckverbinderkragen: Ohne Kragen
Anzahl der Kontakte: 25Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board
Steckverbinder: Stiftleiste
Produktpalette: 2MM-HB Series
productTraceability: No
Kontaktanschluss: Durchsteckmontage, gerade
Anzahl der Reihen: 1Reihe(n)
Rastermaß: 2mm
SVHC: No SVHC (21-Jan-2025)
| Anzahl | Privatkunde |
|---|---|
| 30+ | 8.57 EUR |
| 35+ | 6.75 EUR |
| 100+ | 5.3 EUR |
| 250+ | 4.87 EUR |
| 500+ | 4.34 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 2MM-HB-S25-VT-02-H-TB TE CONNECTIVITY
Description: 25P, AMPMODU 2 MM, BREAKAWAY HEA, Features: Pick and Place, Packaging: Tube, Connector Type: Header, Breakaway, Current Rating (Amps): 2A, Mounting Type: Through Hole, Number of Positions: 25, Number of Rows: 1, Style: Board to Board, Operating Temperature: -40°C ~ 105°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.079" (2.00mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 30.0µin (0.76µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Square, Contact Length - Post: 0.110" (2.80mm), Insulation Height: 0.059" (1.50mm), Shrouding: Unshrouded, Overall Contact Length: 0.327" (8.30mm), Insulation Material: Thermoplastic, Contact Length - Mating: 0.157" (4.00mm).
Weitere Produktangebote 2MM-HB-S25-VT-02-H-TB nach Preis ab 7.25 EUR bis 13.45 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
2MM-HB-S25-VT-02-H-TB | TE Connectivity |
Headers & Wire Housings 25P,2MM,BRK HDR,SRVT,2.8,0.76AU,TB |
auf Bestellung 1313 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
2MM-HB-S25-VT-02-H-TB | TE Connectivity AMP Connectors |
Description: 25P, AMPMODU 2 MM, BREAKAWAY HEA Features: Pick and Place Packaging: Tube Connector Type: Header, Breakaway Current Rating (Amps): 2A Mounting Type: Through Hole Number of Positions: 25 Number of Rows: 1 Style: Board to Board Operating Temperature: -40°C ~ 105°C Contact Type: Male Pin Fastening Type: Push-Pull Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Contact Material: Phosphor Bronze Insulation Color: Black Pitch - Mating: 0.079" (2.00mm) Contact Finish - Mating: Gold Contact Finish Thickness - Mating: 30.0µin (0.76µm) Contact Finish - Post: Tin Part Status: Active Contact Shape: Square Contact Length - Post: 0.110" (2.80mm) Insulation Height: 0.059" (1.50mm) Shrouding: Unshrouded Overall Contact Length: 0.327" (8.30mm) Insulation Material: Thermoplastic Contact Length - Mating: 0.157" (4.00mm) |
auf Bestellung 995 Stücke: Lieferzeit 10-14 Tag (e) |
|
| 2MM-HB-S25-VT-02-H-TB |
|
Hersteller: TE Connectivity
Headers & Wire Housings 25P,2MM,BRK HDR,SRVT,2.8,0.76AU,TB
Headers & Wire Housings 25P,2MM,BRK HDR,SRVT,2.8,0.76AU,TB
auf Bestellung 1313 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 10.64 EUR |
| 10+ | 9.65 EUR |
| 20+ | 9.17 EUR |
| 50+ | 8.95 EUR |
| 100+ | 8.33 EUR |
| 200+ | 7.46 EUR |
| 500+ | 7.25 EUR |
| 2MM-HB-S25-VT-02-H-TB |
|
Hersteller: TE Connectivity AMP Connectors
Description: 25P, AMPMODU 2 MM, BREAKAWAY HEA
Features: Pick and Place
Packaging: Tube
Connector Type: Header, Breakaway
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 25
Number of Rows: 1
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.110" (2.80mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.327" (8.30mm)
Insulation Material: Thermoplastic
Contact Length - Mating: 0.157" (4.00mm)
Description: 25P, AMPMODU 2 MM, BREAKAWAY HEA
Features: Pick and Place
Packaging: Tube
Connector Type: Header, Breakaway
Current Rating (Amps): 2A
Mounting Type: Through Hole
Number of Positions: 25
Number of Rows: 1
Style: Board to Board
Operating Temperature: -40°C ~ 105°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.079" (2.00mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.110" (2.80mm)
Insulation Height: 0.059" (1.50mm)
Shrouding: Unshrouded
Overall Contact Length: 0.327" (8.30mm)
Insulation Material: Thermoplastic
Contact Length - Mating: 0.157" (4.00mm)
auf Bestellung 995 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 2+ | 13.45 EUR |
| 10+ | 11.41 EUR |
| 100+ | 9.7 EUR |
| 500+ | 8.66 EUR |
