5-2213772-9 TE Connectivity
Hersteller: TE Connectivity
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; DPST; 3A/250VAC; IP67; OFF-(ON)
Operating temperature: -20...55°C
Contacts configuration: DPST
Mounting: on panel
IP rating: IP67
Illumination: LED; ring
Switching method: OFF-(ON)
Button shape: round
Actuator colour: silver
Body colour: silver
Contact plating: silver plated
Flammability rating: UL94V-0
Type of switch: vandal resistant
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø22mm
Max. contact resistance:: 50mΩ
Stable positions number: 1
Number of positions: 2
AC contacts rating @R: 3A / 250V AC
Operating Force: 3.5N
Illumination voltage: 24V DC
Electrical life: 50000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 1GΩ
Manufacturer series: AV
Backlight colour: blue
Leads: connectors
Contact material: copper
Anzahl je Verpackung: 1 Stücke
Category: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; DPST; 3A/250VAC; IP67; OFF-(ON)
Operating temperature: -20...55°C
Contacts configuration: DPST
Mounting: on panel
IP rating: IP67
Illumination: LED; ring
Switching method: OFF-(ON)
Button shape: round
Actuator colour: silver
Body colour: silver
Contact plating: silver plated
Flammability rating: UL94V-0
Type of switch: vandal resistant
Leads dimensions: 2.8x0.5mm
Key stroke: 3.2mm
Mounting hole diameter: Ø22mm
Max. contact resistance:: 50mΩ
Stable positions number: 1
Number of positions: 2
AC contacts rating @R: 3A / 250V AC
Operating Force: 3.5N
Illumination voltage: 24V DC
Electrical life: 50000 cycles
Mechanical durability: 1000000 cycles
Min. insulation resistance: 1GΩ
Manufacturer series: AV
Backlight colour: blue
Leads: connectors
Contact material: copper
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 71.5 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 5-2213772-9 TE Connectivity
Category: Push Button Switches, Description: Switch: vandal resistant; Pos: 2; DPST; 3A/250VAC; IP67; OFF-(ON), Operating temperature: -20...55°C, Contacts configuration: DPST, Mounting: on panel, IP rating: IP67, Illumination: LED; ring, Switching method: OFF-(ON), Button shape: round, Actuator colour: silver, Body colour: silver, Contact plating: silver plated, Flammability rating: UL94V-0, Type of switch: vandal resistant, Leads dimensions: 2.8x0.5mm, Key stroke: 3.2mm, Mounting hole diameter: Ø22mm, Max. contact resistance:: 50mΩ, Stable positions number: 1, Number of positions: 2, AC contacts rating @R: 3A / 250V AC, Operating Force: 3.5N, Illumination voltage: 24V DC, Electrical life: 50000 cycles, Mechanical durability: 1000000 cycles, Min. insulation resistance: 1GΩ, Manufacturer series: AV, Backlight colour: blue, Leads: connectors, Contact material: copper, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote 5-2213772-9 nach Preis ab 27.51 EUR bis 71.5 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||
|---|---|---|---|---|---|---|---|---|---|
|
|
5-2213772-9 | Hersteller : TE Connectivity |
Category: Push Button Switches Description: Switch: vandal resistant; Pos: 2; DPST; 3A/250VAC; IP67; OFF-(ON) Operating temperature: -20...55°C Contacts configuration: DPST Mounting: on panel IP rating: IP67 Illumination: LED; ring Switching method: OFF-(ON) Button shape: round Actuator colour: silver Body colour: silver Contact plating: silver plated Flammability rating: UL94V-0 Type of switch: vandal resistant Leads dimensions: 2.8x0.5mm Key stroke: 3.2mm Mounting hole diameter: Ø22mm Max. contact resistance:: 50mΩ Stable positions number: 1 Number of positions: 2 AC contacts rating @R: 3A / 250V AC Operating Force: 3.5N Illumination voltage: 24V DC Electrical life: 50000 cycles Mechanical durability: 1000000 cycles Min. insulation resistance: 1GΩ Manufacturer series: AV Backlight colour: blue Leads: connectors Contact material: copper |
auf Bestellung 1 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||
 |
5-2213772-9 | Hersteller : TE CONNECTIVITY / PARTNER STOCK |
 Description: TE CONNECTIVITY / PARTNER STOCK - 5-2213772-9 - STANDARDtariffCode: 85365080 productTraceability: No rohsCompliant: Y-EX euEccn: NLR hazardous: false rohsPhthalatesCompliant: YES usEccn: EAR99 SVHC: Lead (27-Jun-2024) |
auf Bestellung 9 Stücke: Lieferzeit 14-21 Tag (e) |
|||||
| 5-2213772-9 | Hersteller : TE Connectivity | Flush Pushbutton Switch |
auf Bestellung 11 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||
| 5-2213772-9 | Hersteller : TE Connectivity |
Flush Pushbutton Switch |
Produkt ist nicht verfügbar |
||||||
 |
5-2213772-9 | Hersteller : TE Connectivity / Alcoswitch |
Pushbutton Switches AV22 DPM 3A MOVE RING LED BLUE 24V |
Produkt ist nicht verfügbar |
