5034802400 Molex

Description: CONN FFC FPC 24POS 0.5MM R/A, Features: Solder Retention, Packaging: Tape & Reel (TR), Contact Finish: Gold, Voltage Rating: 50V, Mounting Type: Surface Mount, Right Angle, Number of Positions: 24, Pitch: 0.020" (0.50mm), Operating Temperature: -40°C ~ 85°C, Termination: Solder, Height Above Board: 0.039" (1.00mm), Locking Feature: Flip Lock, Backlock, Material Flammability Rating: UL94 V-0, UL94 HB, Actuator Material: Polyamide (PA), Nylon, Glass Filled, Contact Material: Phosphor Bronze, FFC, FCB Thickness: 0.30mm, Housing Material: Liquid Crystal Polymer (LCP), Glass Filled, Cable End Type: Straight, Tabbed, Flat Flex Type: FFC, FPC, Connector/Contact Type: Contacts, Top and Bottom, Part Status: Active.
