505575-0971 Molex

Description: CONN HEADER SMD 9POS 2MM, Packaging: Tape & Reel (TR), Features: Solder Retention, Connector Type: Header, Voltage Rating: 250VAC/DC, Current Rating (Amps): Varies by Wire Gauge, Mounting Type: Surface Mount, Number of Positions: 9, Number of Rows: 1, Style: Board to Cable/Wire, Operating Temperature: -40°C ~ 105°C, Contact Type: Male Pin, Fastening Type: Locking Ramp, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Brass, Insulation Color: Black, Pitch - Mating: 0.079" (2.00mm), Contact Finish - Mating: Tin, Contact Finish Thickness - Mating: 39.4µin (1.00µm), Contact Finish - Post: Tin, Contact Shape: Square, Insulation Height: 0.339" (8.61mm), Shrouding: Shrouded - 4 Wall, Insulation Material: Polyamide (PA), Nylon.
