Produkte > ALPHA WIRE > 6409 SL005

6409 SL005 Alpha Wire


6409 Hersteller: Alpha Wire
Description: MULTI-PAIR 24COND 24AWG 100'
Features: Drain Wire
Packaging: Spool
Length: 100.0' (30.5m)
Wire Gauge: 24 AWG
Jacket (Insulation) Material: Poly-Vinyl Chloride (PVC)
Conductor Strand: 7/32
Operating Temperature: -20°C ~ 80°C
Number of Conductors: 24 (12 Pair Twisted)
Cable Type: Multi-Pair
Jacket (Insulation) Diameter: 0.478" (12.14mm)
Ratings: UL Style 2919
Jacket (Insulation) Thickness: 0.0350" (0.889mm)
Shield Type: Foil, Braid
Conductor Material: Copper, Tinned
Jacket Color: Slate
Part Status: Active
Voltage: 300 V
auf Bestellung 2 Stücke:

Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+2403.83 EUR
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details 6409 SL005 Alpha Wire

Category: Multicore Cables - Shielded, Description: Wire; Alpha Essential C&C; 12x2x24AWG; PVC; dark grey; 300V; 30.5m, Shield structure: Al-PET foil; shielded twofold; tinned copper braid, Kind of wire: Alpha Essential C&C, Insulation colour: dark grey, Core marking: colours with colour repetition, Conform to the norm: CSA CM FT1; UL 2919; UL CM; VW-1, Type of wire: control cable, Kind of core: Cu; tinned, CPR standard: no classification, Earth core: none, Wire insulation material: PVC, Core structure: stranded, Ground: tinned copper strand 24AWG, Cable features: twisted pair conductors, Operating temperature: -20...80°C, Cable external diameter: 12.14mm, Number of cores: 24, Cable structure: 12x2x24AWG, Minimal wire bend radius: 10xØ, No. of pairs: 12, Core diameter: 24AWG, Rated voltage: 300V, Package contents: 30.5m, Package contents - ft: 100ft, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote 6409 SL005

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
6409 SL005 6409 SL005 Hersteller : ALPHA WIRE pVersion=0046&contRep=ZT&docId=005056AB281E1EDFA5BCDB25A1D840D6&compId=6409.pdf?ci_sign=3569790f3db3970c4f9fc4c5123f7cc85abd2c5b Category: Multicore Cables - Shielded
Description: Wire; Alpha Essential C&C; 12x2x24AWG; PVC; dark grey; 300V; 30.5m
Shield structure: Al-PET foil; shielded twofold; tinned copper braid
Kind of wire: Alpha Essential C&C
Insulation colour: dark grey
Core marking: colours with colour repetition
Conform to the norm: CSA CM FT1; UL 2919; UL CM; VW-1
Type of wire: control cable
Kind of core: Cu; tinned
CPR standard: no classification
Earth core: none
Wire insulation material: PVC
Core structure: stranded
Ground: tinned copper strand 24AWG
Cable features: twisted pair conductors
Operating temperature: -20...80°C
Cable external diameter: 12.14mm
Number of cores: 24
Cable structure: 12x2x24AWG
Minimal wire bend radius: 10xØ
No. of pairs: 12
Core diameter: 24AWG
Rated voltage: 300V
Package contents: 30.5m
Package contents - ft: 100ft
Anzahl je Verpackung: 1 Stücke
