77313-818-08LF

77313-818-08LF AMPHENOL COMMUNICATIONS SOLUTIONS


77313-818-XXLF.pdf Hersteller: AMPHENOL COMMUNICATIONS SOLUTIONS
Category: Pin headers
Description: Connector: pin strips; pin header; male; PIN: 8; BERGSTIK; straight
Manufacturer series: BERGSTIK
Height: 11.43mm
Number of pins: 8
Connector pinout layout: 2x4
Contacts pitch: 2.54mm
Kind of package: bulk
Electrical mounting: THT
Plating thickness: 0.38µm
Spatial orientation: straight
Family: FCI
Type of connector: pin strips
Connector: pin header
Kind of connector: male
Contact plating: gold-plated
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2792 Stücke:

Lieferzeit 7-14 Tag (e)
Anzahl Preis
129+0.56 EUR
154+0.47 EUR
218+0.33 EUR
231+0.31 EUR
1000+0.3 EUR
Mindestbestellmenge: 129
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details 77313-818-08LF AMPHENOL COMMUNICATIONS SOLUTIONS

Description: CONN HEADER VERT 8POS 2.54MM, Packaging: Bulk, Connector Type: Header, Breakaway, Current Rating (Amps): 3A per Contact, Mounting Type: Through Hole, Number of Positions: 8, Number of Rows: 2, Style: Board to Board or Cable, Operating Temperature: -65°C ~ 130°C, Contact Type: Male Pin, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Contact Material: Phosphor Bronze, Insulation Color: Black, Pitch - Mating: 0.100" (2.54mm), Contact Finish - Mating: Gold or Gold, GXT™, Contact Finish Thickness - Mating: 15.0µin (0.38µm), Contact Finish - Post: Tin, Part Status: Active, Contact Shape: Square, Contact Length - Post: 0.120" (3.05mm), Insulation Height: 0.100" (2.54mm), Shrouding: Unshrouded, Overall Contact Length: 0.450" (11.43mm), Insulation Material: Thermoplastic, Row Spacing - Mating: 0.100" (2.54mm), Contact Length - Mating: 0.230" (5.84mm).

Weitere Produktangebote 77313-818-08LF nach Preis ab 0.3 EUR bis 1.07 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
77313-818-08LF 77313-818-08LF Hersteller : AMPHENOL COMMUNICATIONS SOLUTIONS 77313-818-XXLF.pdf Category: Pin headers
Description: Connector: pin strips; pin header; male; PIN: 8; BERGSTIK; straight
Manufacturer series: BERGSTIK
Height: 11.43mm
Number of pins: 8
Connector pinout layout: 2x4
Contacts pitch: 2.54mm
Kind of package: bulk
Electrical mounting: THT
Plating thickness: 0.38µm
Spatial orientation: straight
Family: FCI
Type of connector: pin strips
Connector: pin header
Kind of connector: male
Contact plating: gold-plated
auf Bestellung 2792 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
129+0.56 EUR
154+0.47 EUR
218+0.33 EUR
231+0.31 EUR
1000+0.3 EUR
Mindestbestellmenge: 129
Im Einkaufswagen  Stück im Wert von  UAH
77313-818-08LF 77313-818-08LF Hersteller : Amphenol FCI bwb_bergstik.pdf Headers & Wire Housings 8P STR DR TMT HDR .38 AU .45IN LENGTH
auf Bestellung 404 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
3+0.97 EUR
10+0.78 EUR
100+0.65 EUR
500+0.52 EUR
1000+0.47 EUR
5000+0.42 EUR
10000+0.39 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
77313-818-08LF 77313-818-08LF Hersteller : Amphenol ICC (FCI) bwb_bergstik.pdf Description: CONN HEADER VERT 8POS 2.54MM
Packaging: Bulk
Connector Type: Header, Breakaway
Current Rating (Amps): 3A per Contact
Mounting Type: Through Hole
Number of Positions: 8
Number of Rows: 2
Style: Board to Board or Cable
Operating Temperature: -65°C ~ 130°C
Contact Type: Male Pin
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Phosphor Bronze
Insulation Color: Black
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold or Gold, GXT™
Contact Finish Thickness - Mating: 15.0µin (0.38µm)
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.120" (3.05mm)
Insulation Height: 0.100" (2.54mm)
Shrouding: Unshrouded
Overall Contact Length: 0.450" (11.43mm)
Insulation Material: Thermoplastic
Row Spacing - Mating: 0.100" (2.54mm)
Contact Length - Mating: 0.230" (5.84mm)
auf Bestellung 1900 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
17+1.07 EUR
22+0.81 EUR
100+0.62 EUR
500+0.52 EUR
1000+0.45 EUR
Mindestbestellmenge: 17
Im Einkaufswagen  Stück im Wert von  UAH
77313-818-08LF 77313-818-08LF Hersteller : FCI 77313.pdf Conn Unshrouded Header HDR 8 POS 2.54mm Solder ST Top Entry Thru-Hole BergStik® Bulk
auf Bestellung 500 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
77313-818-08LF 77313-818-08LF Hersteller : AMPHENOL COMMUNICATIONS SOLUTIONS 2562207.pdf Description: AMPHENOL COMMUNICATIONS SOLUTIONS - 77313-818-08LF - Stiftleiste, Board-to-Board, 2.54 mm, 2 Reihe(n), 8 Kontakt(e), Durchsteckmontage, gerade
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Phosphorbronze
usEccn: EAR99
Steckverbinderkragen: Ohne Kragen
Anzahl der Kontakte: 8Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board
Produktpalette: FCI BergStik 77313 Series
productTraceability: No
Kontaktanschluss: Durchsteckmontage, gerade
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 2.54mm
SVHC: No SVHC (12-Jan-2017)
auf Bestellung 758 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
