801651 HELU
Hersteller: HELU
Category: Industrial Ethernet Cables
Description: Wire; hybrid; HELUKAT® PROFInet B; 4x1.5mm2; 2x2x22AWG; Cat 5e
Operating temperature: -40...70°C
Kind of material: halogen free; no flame propagation
Wire insulation material: FRNC
Insulation colour: green
Kind of cable: hybrid
CPR standard: no classification
Core structure: stranded
Core section: 1.5mm2
Cable external diameter: 10.3mm
No. of pairs: 2
Cable structure: 2x2x22AWG; 4x1.5mm2
Number of cores: 8
Core diameter: 22AWG
Manufacturer series: HELUKAT® PROFInet B
Shield structure: Al foil; braid made of copper wires; shielded twofold
Cable application: industrial Ethernet; PROFINET
Ethernet category: Cat 5e
Kind of core: Cu
Type of wire: data transmission
| Anzahl | Preis |
|---|---|
| 7+ | 11.38 EUR |
| 10+ | 10.35 EUR |
| 25+ | 9.31 EUR |
| 50+ | 8.28 EUR |
| 100+ | 7.25 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details 801651 HELU
Category: Industrial Ethernet Cables, Description: Wire; hybrid; HELUKAT® PROFInet B; 4x1.5mm2; 2x2x22AWG; Cat 5e, Operating temperature: -40...70°C, Kind of material: halogen free; no flame propagation, Wire insulation material: FRNC, Insulation colour: green, Kind of cable: hybrid, CPR standard: no classification, Core structure: stranded, Core section: 1.5mm2, Cable external diameter: 10.3mm, No. of pairs: 2, Cable structure: 2x2x22AWG; 4x1.5mm2, Number of cores: 8, Core diameter: 22AWG, Manufacturer series: HELUKAT® PROFInet B, Shield structure: Al foil; braid made of copper wires; shielded twofold, Cable application: industrial Ethernet; PROFINET, Ethernet category: Cat 5e, Kind of core: Cu, Type of wire: data transmission.
