A40303MNZQ C&K
Hersteller: C&K
Description: SWITCH ROTARY 3POS 2.5A 125V
Packaging: Bulk
Contact Finish: Silver
Current Rating (Amps): 2.5A (AC), 350mA (DC)
Mounting Type: Panel Mount
Number of Positions: 3
Termination Style: Solder Lug
Actuator Length: 9.53mm
Actuator Type: Flatted (6.35mm Dia)
Angle of Throw: 30°
Number of Decks: 1
Number of Poles per Deck: 4
Circuit per Deck: 4P3T
Contact Material: Silver (Ag)
Contact Timing: Non-Shorting (BBM)
Index Stops: Fixed
Depth Behind Panel: 20.83mm
Voltage Rating - AC: 125 V
Voltage Rating - DC: 125 V
Produktrezensionen
Produktbewertung abgeben
Technische Details A40303MNZQ C&K
Description: SWITCH ROTARY 3POS 2.5A 125V, Packaging: Bulk, Contact Finish: Silver, Current Rating (Amps): 2.5A (AC), 350mA (DC), Mounting Type: Panel Mount, Number of Positions: 3, Termination Style: Solder Lug, Actuator Length: 9.53mm, Actuator Type: Flatted (6.35mm Dia), Angle of Throw: 30°, Number of Decks: 1, Number of Poles per Deck: 4, Circuit per Deck: 4P3T, Contact Material: Silver (Ag), Contact Timing: Non-Shorting (BBM), Index Stops: Fixed, Depth Behind Panel: 20.83mm, Voltage Rating - AC: 125 V, Voltage Rating - DC: 125 V.
Weitere Produktangebote A40303MNZQ
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
 |
A40303MNZQ | C&K |
Rotary Switches A40303MNZQ |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 72 Stücke Im Einkaufswagen Stück im Wert von UAH |
 |
A403-03-M-N-Z-Q | C&K |
Category: Rotary Switches Description: Switch: rotary; Pos: 3; 2.5A/125VAC; 0.35A/125VDC; Poles number: 4 Leads: for soldering Type of switch: rotary Operating temperature: -30...85°C Body dimensions: Ø26.2mm Max. contact resistance:: 20mΩ Button height: 29.35mm AC contacts rating @R: 2.5A / 125V AC DC contacts rating @R: 0.35A / 125V DC Stable positions number: 3 Number of positions: 3 Poles number: 4 Electrical life: 15000 cycles Min. insulation resistance: 10GΩ Manufacturer series: A |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 72 Stücke Im Einkaufswagen Stück im Wert von UAH |
| A40303MNZQ |
|
Hersteller: C&K
Rotary Switches A40303MNZQ
Rotary Switches A40303MNZQ
Produkt ist nicht verfügbar
Mindestbestellmenge: 72 Stücke
Im Einkaufswagen
Stück im Wert von UAH
| A403-03-M-N-Z-Q |
|
Hersteller: C&K
Category: Rotary Switches
Description: Switch: rotary; Pos: 3; 2.5A/125VAC; 0.35A/125VDC; Poles number: 4
Leads: for soldering
Type of switch: rotary
Operating temperature: -30...85°C
Body dimensions: Ø26.2mm
Max. contact resistance:: 20mΩ
Button height: 29.35mm
AC contacts rating @R: 2.5A / 125V AC
DC contacts rating @R: 0.35A / 125V DC
Stable positions number: 3
Number of positions: 3
Poles number: 4
Electrical life: 15000 cycles
Min. insulation resistance: 10GΩ
Manufacturer series: A
Category: Rotary Switches
Description: Switch: rotary; Pos: 3; 2.5A/125VAC; 0.35A/125VDC; Poles number: 4
Leads: for soldering
Type of switch: rotary
Operating temperature: -30...85°C
Body dimensions: Ø26.2mm
Max. contact resistance:: 20mΩ
Button height: 29.35mm
AC contacts rating @R: 2.5A / 125V AC
DC contacts rating @R: 0.35A / 125V DC
Stable positions number: 3
Number of positions: 3
Poles number: 4
Electrical life: 15000 cycles
Min. insulation resistance: 10GΩ
Manufacturer series: A
