AEF0810470M050R KYOCERA AVX
Hersteller: KYOCERA AVX
Category: SMD electrolytic capacitors
Description: Capacitor: electrolytic; SMD; 47uF; 50VDC; Ø8x10.5mm; ±20%; AEF
Type of capacitor: electrolytic
Mounting: SMD
Capacitance: 47µF
Operating voltage: 50V DC
Body dimensions: Ø8x10.5mm
Tolerance: ±20%
Operating temperature: -55...105°C
Manufacturer series: AEF
Operating current: 0.52A
Height: 10.5mm
Diameter: 8mm
ESR value: 570mΩ
Roll diameter max.: 380mm
| Anzahl | Preis |
|---|---|
| 70+ | 1.03 EUR |
| 124+ | 0.58 EUR |
| 178+ | 0.4 EUR |
| 208+ | 0.34 EUR |
| 550+ | 0.3 EUR |
| 1100+ | 0.28 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details AEF0810470M050R KYOCERA AVX
Description: CAP ALUM 50V POLAR, Ripple Current @ High Frequency: 520 mA @ 100 kHz, Ripple Current @ Low Frequency: 260 mA @ 120 Hz, Voltage - Rated: 50 V, Capacitance: 47 µF, Height - Seated (Max): 0.433" (11.00mm), Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm), Lifetime @ Temp.: 6000 Hrs @ 105°C, ESR (Equivalent Series Resistance): 570mOhm @ 100kHz, Applications: Automotive, Operating Temperature: -55°C ~ 105°C, Mounting Type: Surface Mount, Polarization: Polar, Size / Dimension: 0.315" Dia (8.00mm), Package / Case: Radial, Can - SMD, Tolerance: ±20%, Packaging: Tape & Reel (TR).
Weitere Produktangebote AEF0810470M050R
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
|---|---|---|---|---|---|
 |
AEF0810470M050R | KYOCERA AVX |
Description: CAP ALUM 50V POLAR Ripple Current @ High Frequency: 520 mA @ 100 kHz Ripple Current @ Low Frequency: 260 mA @ 120 Hz Voltage - Rated: 50 V Capacitance: 47 µF Height - Seated (Max): 0.433" (11.00mm) Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm) Lifetime @ Temp.: 6000 Hrs @ 105°C ESR (Equivalent Series Resistance): 570mOhm @ 100kHz Applications: Automotive Operating Temperature: -55°C ~ 105°C Mounting Type: Surface Mount Polarization: Polar Size / Dimension: 0.315" Dia (8.00mm) Package / Case: Radial, Can - SMD Tolerance: ±20% Packaging: Tape & Reel (TR) |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 550 Stücke Im Einkaufswagen Stück im Wert von UAH |
 |
AEF0810470M050R | Kyocera AVX |
Aluminium Electrolytic Capacitors - SMD 50V 47uF 6000Hrs 20% ESR=570mOhms |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 3 Stücke Im Einkaufswagen Stück im Wert von UAH |
| AEF0810470M050R |
|
Hersteller: KYOCERA AVX
Description: CAP ALUM 50V POLAR
Ripple Current @ High Frequency: 520 mA @ 100 kHz
Ripple Current @ Low Frequency: 260 mA @ 120 Hz
Voltage - Rated: 50 V
Capacitance: 47 µF
Height - Seated (Max): 0.433" (11.00mm)
Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm)
Lifetime @ Temp.: 6000 Hrs @ 105°C
ESR (Equivalent Series Resistance): 570mOhm @ 100kHz
Applications: Automotive
Operating Temperature: -55°C ~ 105°C
Mounting Type: Surface Mount
Polarization: Polar
Size / Dimension: 0.315" Dia (8.00mm)
Package / Case: Radial, Can - SMD
Tolerance: ±20%
Packaging: Tape & Reel (TR)
Description: CAP ALUM 50V POLAR
Ripple Current @ High Frequency: 520 mA @ 100 kHz
Ripple Current @ Low Frequency: 260 mA @ 120 Hz
Voltage - Rated: 50 V
Capacitance: 47 µF
Height - Seated (Max): 0.433" (11.00mm)
Surface Mount Land Size: 0.327" L x 0.327" W (8.30mm x 8.30mm)
Lifetime @ Temp.: 6000 Hrs @ 105°C
ESR (Equivalent Series Resistance): 570mOhm @ 100kHz
Applications: Automotive
Operating Temperature: -55°C ~ 105°C
Mounting Type: Surface Mount
Polarization: Polar
Size / Dimension: 0.315" Dia (8.00mm)
Package / Case: Radial, Can - SMD
Tolerance: ±20%
Packaging: Tape & Reel (TR)
Produkt ist nicht verfügbar
Mindestbestellmenge: 550 Stücke
Im Einkaufswagen
Stück im Wert von UAH
| AEF0810470M050R |
|
Hersteller: Kyocera AVX
Aluminium Electrolytic Capacitors - SMD 50V 47uF 6000Hrs 20% ESR=570mOhms
Aluminium Electrolytic Capacitors - SMD 50V 47uF 6000Hrs 20% ESR=570mOhms
Produkt ist nicht verfügbar
Mindestbestellmenge: 3 Stücke
Im Einkaufswagen
Stück im Wert von UAH
