AM1SR-2412SJZ AIMTEC
Hersteller: AIMTEC
Category: DC/DC Converters
Description: Converter: DC/DC; 0.75W; Uin: 22.8÷25.2VDC; Uout: 12VDC; Iout: 62mA
Type of converter: DC/DC
Power: 0.75W
Input voltage: 22.8...25.2V DC
Output voltage: 12V DC
Output current: 62mA
Case: SIP4
Mounting: THT
Body dimensions: 11.6x6x10.16mm
Efficiency: 73%
Operating temperature: -40...85°C
Switching frequency: 260kHz
Protection: short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Manufacturer series: AM1SR-JZ
Produktrezensionen
Produktbewertung abgeben
Technische Details AM1SR-2412SJZ AIMTEC
Description: 0.5W DC/DC Converter, Standard Number: 62368-1, Voltage - Isolation: 1.5 kV, Number of Outputs: 1, Power (Watts): 744 mW, Part Status: Active, Voltage - Output 1: 12V, Voltage - Input (Min): 22.8V, Current - Output (Max): 62mA, Efficiency: 73%, Voltage - Input (Max): 25.2V, Applications: ITE (Commercial), Operating Temperature: -40°C ~ 85°C (With Derating), Type: Isolated Module, Mounting Type: Through Hole, Size / Dimension: 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm), Package / Case: 4-SIP Module, Packaging: Tube.
Weitere Produktangebote AM1SR-2412SJZ nach Preis ab 6.23 EUR bis 6.23 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
||
|---|---|---|---|---|---|---|---|
 |
AM1SR-2412SJZ | aimtec |
Description: 0.5W DC/DC Converter Standard Number: 62368-1 Voltage - Isolation: 1.5 kV Number of Outputs: 1 Power (Watts): 744 mW Part Status: Active Voltage - Output 1: 12V Voltage - Input (Min): 22.8V Current - Output (Max): 62mA Efficiency: 73% Voltage - Input (Max): 25.2V Applications: ITE (Commercial) Operating Temperature: -40°C ~ 85°C (With Derating) Type: Isolated Module Mounting Type: Through Hole Size / Dimension: 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm) Package / Case: 4-SIP Module Packaging: Tube |
auf Bestellung 4 Stücke: Lieferzeit 10-14 Tag (e) |
|
| AM1SR-2412SJZ |
|
Hersteller: aimtec
Description: 0.5W DC/DC Converter
Standard Number: 62368-1
Voltage - Isolation: 1.5 kV
Number of Outputs: 1
Power (Watts): 744 mW
Part Status: Active
Voltage - Output 1: 12V
Voltage - Input (Min): 22.8V
Current - Output (Max): 62mA
Efficiency: 73%
Voltage - Input (Max): 25.2V
Applications: ITE (Commercial)
Operating Temperature: -40°C ~ 85°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
Package / Case: 4-SIP Module
Packaging: Tube
Description: 0.5W DC/DC Converter
Standard Number: 62368-1
Voltage - Isolation: 1.5 kV
Number of Outputs: 1
Power (Watts): 744 mW
Part Status: Active
Voltage - Output 1: 12V
Voltage - Input (Min): 22.8V
Current - Output (Max): 62mA
Efficiency: 73%
Voltage - Input (Max): 25.2V
Applications: ITE (Commercial)
Operating Temperature: -40°C ~ 85°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.46" L x 0.24" W x 0.40" H (11.6mm x 6.0mm x 10.2mm)
Package / Case: 4-SIP Module
Packaging: Tube
auf Bestellung 4 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 3+ | 6.23 EUR |
