BXRE-30G65F0-C-83 BRIDGELUX
Hersteller: BRIDGELUX
Category: White power LEDs - COB
Description: Power LED; COB; 62.4W; 3000K; 11542lm; 120°; Front: flat; CRImin: 90
Power: 62.4W
Manufacturer series: V22
Type of diode: power LED
Storage temperature: -40...95°C
Dimensions: 28x28x1.65mm
LED current: 1.2A
Operating voltage: 52V DC
Min. colour rendering index: 90
Viewing angle: 120°
Light source efficiency: 185lm/W
Colour temperature: 3000K
Luminosity: 11542lm
Binning: 3SDCM
LED version: COB
Front: flat
| Anzahl | Privatkunde |
|---|---|
| 4+ | 24.03 EUR |
| 5+ | 21.29 EUR |
| 15+ | 19.99 EUR |
| 30+ | 18.91 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details BXRE-30G65F0-C-83 BRIDGELUX
Description: LED COB V22 F90 ARRAY SQ 3000K, Part Status: Active, Luminous Flux @ Current/Temperature: 21233lm, Temperature - Test: 85°C, Light Emitting Surface (LES): 23.30mm Dia, CRI (Color Rendering Index): 90, CCT (K): 3000K, Lumens/Watt @ Current - Test: 138 lm/W, Current - Max: 2.7A, Lens Type: Flat, Viewing Angle: 120°, Height: 1.65mm, Voltage - Forward (Vf) (Typ): 57V, Configuration: Square, Type: Chip On Board (COB), Size / Dimension: 28.00mm L x 28.00mm W, Color: White, Warm, Features: Dimming, Packaging: Tube.
Weitere Produktangebote BXRE-30G65F0-C-83 nach Preis ab 25.57 EUR bis 37.87 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BXRE-30G65F0-C-83 | Bridgelux |
Description: LED COB V22 F90 ARRAY SQ 3000K Part Status: Active Luminous Flux @ Current/Temperature: 21233lm Temperature - Test: 85°C Light Emitting Surface (LES): 23.30mm Dia CRI (Color Rendering Index): 90 CCT (K): 3000K Lumens/Watt @ Current - Test: 138 lm/W Current - Max: 2.7A Lens Type: Flat Viewing Angle: 120° Height: 1.65mm Voltage - Forward (Vf) (Typ): 57V Configuration: Square Type: Chip On Board (COB) Size / Dimension: 28.00mm L x 28.00mm W Color: White, Warm Features: Dimming Packaging: Tube |
auf Bestellung 123 Stücke: Lieferzeit 10-14 Tag (e) |
|
| BXRE-30G65F0-C-83 |
|
Hersteller: Bridgelux
Description: LED COB V22 F90 ARRAY SQ 3000K
Part Status: Active
Luminous Flux @ Current/Temperature: 21233lm
Temperature - Test: 85°C
Light Emitting Surface (LES): 23.30mm Dia
CRI (Color Rendering Index): 90
CCT (K): 3000K
Lumens/Watt @ Current - Test: 138 lm/W
Current - Max: 2.7A
Lens Type: Flat
Viewing Angle: 120°
Height: 1.65mm
Voltage - Forward (Vf) (Typ): 57V
Configuration: Square
Type: Chip On Board (COB)
Size / Dimension: 28.00mm L x 28.00mm W
Color: White, Warm
Features: Dimming
Packaging: Tube
Description: LED COB V22 F90 ARRAY SQ 3000K
Part Status: Active
Luminous Flux @ Current/Temperature: 21233lm
Temperature - Test: 85°C
Light Emitting Surface (LES): 23.30mm Dia
CRI (Color Rendering Index): 90
CCT (K): 3000K
Lumens/Watt @ Current - Test: 138 lm/W
Current - Max: 2.7A
Lens Type: Flat
Viewing Angle: 120°
Height: 1.65mm
Voltage - Forward (Vf) (Typ): 57V
Configuration: Square
Type: Chip On Board (COB)
Size / Dimension: 28.00mm L x 28.00mm W
Color: White, Warm
Features: Dimming
Packaging: Tube
auf Bestellung 123 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 37.87 EUR |
| 10+ | 30.08 EUR |
| 100+ | 25.57 EUR |
