BXRE-40G20F0-C-83 BRIDGELUX
Hersteller: BRIDGELUX
Category: White power LEDs - COB
Description: Power LED; COB; 17.1W; 4000K; 3275lm; 120°; Front: flat; CRImin: 90
Operating voltage: 34.3V DC
Luminosity: 3275lm
Min. colour rendering index: 90
Light source efficiency: 191lm/W
Viewing angle: 120°
Binning: 3SDCM
Colour temperature: 4000K
LED version: COB
Front: flat
Type of diode: power LED
Manufacturer series: V13
Storage temperature: -40...95°C
Dimensions: 19x19x1.65mm
LED current: 500mA
Power: 17.1W
| Anzahl | Privatkunde |
|---|---|
| 11+ | 7.87 EUR |
| 13+ | 6.93 EUR |
| 25+ | 6.4 EUR |
| 50+ | 5.87 EUR |
| 100+ | 5.81 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details BXRE-40G20F0-C-83 BRIDGELUX
Description: LED COB V13 F90 ARRAY SQ 4000K, Features: Dimming, Packaging: Tube, Color: White, Neutral, Size / Dimension: 19.00mm L x 19.00mm W, Type: Chip On Board (COB), Configuration: Square, Voltage - Forward (Vf) (Typ): 33.4V, Height: 1.65mm, Current - Test: 500mA, Viewing Angle: 120°, Lens Type: Flat, Current - Max: 1.26A, Lumens/Watt @ Current - Test: 191 lm/W, CCT (K): 4000K, CRI (Color Rendering Index): 90, Light Emitting Surface (LES): 14.80mm Dia, Temperature - Test: 25°C, Luminous Flux @ Current/Temperature: 3275lm (Typ), Part Status: Active.
Weitere Produktangebote BXRE-40G20F0-C-83 nach Preis ab 8.57 EUR bis 15.79 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BXRE-40G20F0-C-83 | Bridgelux |
Description: LED COB V13 F90 ARRAY SQ 4000K Features: Dimming Packaging: Tube Color: White, Neutral Size / Dimension: 19.00mm L x 19.00mm W Type: Chip On Board (COB) Configuration: Square Voltage - Forward (Vf) (Typ): 33.4V Height: 1.65mm Current - Test: 500mA Viewing Angle: 120° Lens Type: Flat Current - Max: 1.26A Lumens/Watt @ Current - Test: 191 lm/W CCT (K): 4000K CRI (Color Rendering Index): 90 Light Emitting Surface (LES): 14.80mm Dia Temperature - Test: 25°C Luminous Flux @ Current/Temperature: 3275lm (Typ) Part Status: Active |
auf Bestellung 1449 Stücke: Lieferzeit 10-14 Tag (e) |
|
| BXRE-40G20F0-C-83 |
|
Hersteller: Bridgelux
Description: LED COB V13 F90 ARRAY SQ 4000K
Features: Dimming
Packaging: Tube
Color: White, Neutral
Size / Dimension: 19.00mm L x 19.00mm W
Type: Chip On Board (COB)
Configuration: Square
Voltage - Forward (Vf) (Typ): 33.4V
Height: 1.65mm
Current - Test: 500mA
Viewing Angle: 120°
Lens Type: Flat
Current - Max: 1.26A
Lumens/Watt @ Current - Test: 191 lm/W
CCT (K): 4000K
CRI (Color Rendering Index): 90
Light Emitting Surface (LES): 14.80mm Dia
Temperature - Test: 25°C
Luminous Flux @ Current/Temperature: 3275lm (Typ)
Part Status: Active
Description: LED COB V13 F90 ARRAY SQ 4000K
Features: Dimming
Packaging: Tube
Color: White, Neutral
Size / Dimension: 19.00mm L x 19.00mm W
Type: Chip On Board (COB)
Configuration: Square
Voltage - Forward (Vf) (Typ): 33.4V
Height: 1.65mm
Current - Test: 500mA
Viewing Angle: 120°
Lens Type: Flat
Current - Max: 1.26A
Lumens/Watt @ Current - Test: 191 lm/W
CCT (K): 4000K
CRI (Color Rendering Index): 90
Light Emitting Surface (LES): 14.80mm Dia
Temperature - Test: 25°C
Luminous Flux @ Current/Temperature: 3275lm (Typ)
Part Status: Active
auf Bestellung 1449 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 2+ | 15.79 EUR |
| 10+ | 12.04 EUR |
| 100+ | 9.84 EUR |
| 500+ | 8.89 EUR |
| 1000+ | 8.57 EUR |
