C4AQLBU5150A11K KEMET
Hersteller: KEMET
Description: CAP FILM 15UF 10% 500VDC RADIAL
Tolerance: ±10%
Packaging: Bulk
Package / Case: Radial
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 105°C
Applications: Automotive; DC Link, DC Filtering
Lead Spacing: 1.083" (27.50mm)
Termination: PC Pins
Ratings: AEC-Q200
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - DC: 500V
Height - Seated (Max): 1.150" (29.20mm)
Capacitance: 15 µF
ESR (Equivalent Series Resistance): 6 mOhms
Size / Dimension: 1.240" L x 0.748" W (31.50mm x 19.00mm)
| Anzahl | Privatkunde |
|---|---|
| 3+ | 9.12 EUR |
| 10+ | 6.6 EUR |
| 72+ | 5.43 EUR |
| 144+ | 5.14 EUR |
Artikel auf Bestellung
Nicht an unserem Lager — wir beziehen ihn nach Ihrer Bestellung vom Lieferantenlager.
Lieferzeit:
10-14 Tag (e)
Mindestmenge:
3 Stücke
Produktrezensionen
Produktbewertung abgeben
Technische Details C4AQLBU5150A11K KEMET
Category: THT Film Capacitors, Description: Capacitor: polypropylene; DC-Link; 15uF; Uoper: 500VDC; Ifsm: 147A, Type of capacitor: polypropylene, Capacitance: 15µF, Operating voltage: 500V DC, Mounting: THT, Tolerance: ±10%, Operating temperature: -40...105°C, Manufacturer series: C4AQ, Terminal pitch: 27.5mm, ESR value: 6mΩ, Body dimensions: 31.5x29x19mm, Max. operating current: 8.5A, Pulse resistance: 10V/μs, Max. forward impulse current: 147A, Max. operating voltage: 500V DC, Climate class: 55/105/56; IEC 60068-1, Conform to the norm: AEC-Q200, Capacitor application: filtering, Kind of capacitor: DC-Link.
Weitere Produktangebote C4AQLBU5150A11K
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
 |
C4AQLBU5150A11K | KEMET |
Category: THT Film Capacitors Description: Capacitor: polypropylene; DC-Link; 15uF; Uoper: 500VDC; Ifsm: 147A Type of capacitor: polypropylene Capacitance: 15µF Operating voltage: 500V DC Mounting: THT Tolerance: ±10% Operating temperature: -40...105°C Manufacturer series: C4AQ Terminal pitch: 27.5mm ESR value: 6mΩ Body dimensions: 31.5x29x19mm Max. operating current: 8.5A Pulse resistance: 10V/μs Max. forward impulse current: 147A Max. operating voltage: 500V DC Climate class: 55/105/56; IEC 60068-1 Conform to the norm: AEC-Q200 Capacitor application: filtering Kind of capacitor: DC-Link |
auf Bestellung 72 Stücke: Lieferzeit 14-21 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH |
| C4AQLBU5150A11K |
|
Hersteller: KEMET
Category: THT Film Capacitors
Description: Capacitor: polypropylene; DC-Link; 15uF; Uoper: 500VDC; Ifsm: 147A
Type of capacitor: polypropylene
Capacitance: 15µF
Operating voltage: 500V DC
Mounting: THT
Tolerance: ±10%
Operating temperature: -40...105°C
Manufacturer series: C4AQ
Terminal pitch: 27.5mm
ESR value: 6mΩ
Body dimensions: 31.5x29x19mm
Max. operating current: 8.5A
Pulse resistance: 10V/μs
Max. forward impulse current: 147A
Max. operating voltage: 500V DC
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
Capacitor application: filtering
Kind of capacitor: DC-Link
Category: THT Film Capacitors
Description: Capacitor: polypropylene; DC-Link; 15uF; Uoper: 500VDC; Ifsm: 147A
Type of capacitor: polypropylene
Capacitance: 15µF
Operating voltage: 500V DC
Mounting: THT
Tolerance: ±10%
Operating temperature: -40...105°C
Manufacturer series: C4AQ
Terminal pitch: 27.5mm
ESR value: 6mΩ
Body dimensions: 31.5x29x19mm
Max. operating current: 8.5A
Pulse resistance: 10V/μs
Max. forward impulse current: 147A
Max. operating voltage: 500V DC
Climate class: 55/105/56; IEC 60068-1
Conform to the norm: AEC-Q200
Capacitor application: filtering
Kind of capacitor: DC-Link
auf Bestellung 72 Stücke:
Lieferzeit 14-21 Tag (e)
