C4ATHBW5100A3LJ KEMET
Hersteller: KEMET
Category: THT Film Capacitors
Description: Capacitor: polypropylene; 10uF; 600VDC; 350VAC; Ioper.max: 29A
Capacitor application: filtering
Manufacturer series: C4AT
Type of capacitor: polypropylene
Mounting: THT
Operating temperature: -40...85°C
Capacitance: 10µF
ESR value: 1.8mΩ
Terminal pitch: 37.5x20.3mm
Body dimensions: 42x45x30mm
Operating voltage: 350V AC; 600V DC
Tolerance: ±5%
Max. operating current: 29A
Pulse resistance: 70V/μs
Max. forward impulse current: 702A
Climate class: 40/085/56
Produktrezensionen
Produktbewertung abgeben
Technische Details C4ATHBW5100A3LJ KEMET
Description: CAP FILM 10UF 5% 600VDC RADIAL, Tolerance: ±5%, Packaging: Bulk, Package / Case: Radial - 4 Leads, Mounting Type: Through Hole, Operating Temperature: -40°C ~ 85°C, Applications: DC Link, DC Filtering; High Frequency, Switching, Lead Spacing: 1.476" (37.50mm), Termination: PC Pins, Dielectric Material: Polypropylene (PP), Metallized, Voltage Rating - AC: 350V, Voltage Rating - DC: 600V, Height - Seated (Max): 1.772" (45.00mm), Capacitance: 10 µF, ESR (Equivalent Series Resistance): 1.8 MOhms, Size / Dimension: 1.654" L x 1.181" W (42.00mm x 30.00mm).
Weitere Produktangebote C4ATHBW5100A3LJ nach Preis ab 13.84 EUR bis 22.56 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
C4ATHBW5100A3LJ | KEMET |
Description: CAP FILM 10UF 5% 600VDC RADIAL Tolerance: ±5% Packaging: Bulk Package / Case: Radial - 4 Leads Mounting Type: Through Hole Operating Temperature: -40°C ~ 85°C Applications: DC Link, DC Filtering; High Frequency, Switching Lead Spacing: 1.476" (37.50mm) Termination: PC Pins Dielectric Material: Polypropylene (PP), Metallized Voltage Rating - AC: 350V Voltage Rating - DC: 600V Height - Seated (Max): 1.772" (45.00mm) Capacitance: 10 µF ESR (Equivalent Series Resistance): 1.8 MOhms Size / Dimension: 1.654" L x 1.181" W (42.00mm x 30.00mm) |
auf Bestellung 36 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
 |
C4ATHBW5100A3LJ | KEMET |
Film Capacitors 600V 10 uF 85C 5% 4 Pin LS=37.5 mm AEC-Q200 |
auf Bestellung 83 Stücke: Lieferzeit 10-14 Tag (e) |
|
| C4ATHBW5100A3LJ |
|
Hersteller: KEMET
Description: CAP FILM 10UF 5% 600VDC RADIAL
Tolerance: ±5%
Packaging: Bulk
Package / Case: Radial - 4 Leads
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: DC Link, DC Filtering; High Frequency, Switching
Lead Spacing: 1.476" (37.50mm)
Termination: PC Pins
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - AC: 350V
Voltage Rating - DC: 600V
Height - Seated (Max): 1.772" (45.00mm)
Capacitance: 10 µF
ESR (Equivalent Series Resistance): 1.8 MOhms
Size / Dimension: 1.654" L x 1.181" W (42.00mm x 30.00mm)
Description: CAP FILM 10UF 5% 600VDC RADIAL
Tolerance: ±5%
Packaging: Bulk
Package / Case: Radial - 4 Leads
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: DC Link, DC Filtering; High Frequency, Switching
Lead Spacing: 1.476" (37.50mm)
Termination: PC Pins
Dielectric Material: Polypropylene (PP), Metallized
Voltage Rating - AC: 350V
Voltage Rating - DC: 600V
Height - Seated (Max): 1.772" (45.00mm)
Capacitance: 10 µF
ESR (Equivalent Series Resistance): 1.8 MOhms
Size / Dimension: 1.654" L x 1.181" W (42.00mm x 30.00mm)
auf Bestellung 36 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 22.35 EUR |
| 36+ | 15.52 EUR |
| C4ATHBW5100A3LJ |
|
Hersteller: KEMET
Film Capacitors 600V 10 uF 85C 5% 4 Pin LS=37.5 mm AEC-Q200
Film Capacitors 600V 10 uF 85C 5% 4 Pin LS=37.5 mm AEC-Q200
auf Bestellung 83 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 22.56 EUR |
| 10+ | 18.28 EUR |
| 36+ | 15.21 EUR |
| 108+ | 14.35 EUR |
| 504+ | 13.84 EUR |
