D4N-1B31 Omron Automation and Safety
Hersteller: Omron Automation and Safety
Description: SWITCH SNAP ACT DPST-NC 3A 240V
Packaging: Bulk
Current Rating (Amps): 3A (AC), 270mA (DC)
Mounting Type: Chassis Mount
Circuit: DPST-NC
Switch Function: On-Mom
Operating Temperature: -30°C ~ 70°C
Termination Style: Screw Terminal
Actuator Type: Round (Pin Plunger)
Operating Force: 663gf
Ingress Protection: IP67 - Dust Tight, Waterproof
Mechanical Life: 15,000,000 Cycles
Electrical Life: 300,000 Cycles
Release Force: 153gf
Pretravel: 0.080" (2.0mm)
Differential Travel: 0.040" (1.0mm)
Overtravel: 0.158" (4.0mm)
Operating Position: 0.715" (18.2mm)
Voltage Rating - AC: 240 V
Voltage Rating - DC: 250 V
Produktrezensionen
Produktbewertung abgeben
Technische Details D4N-1B31 Omron Automation and Safety
Description: SWITCH SNAP ACT DPST-NC 3A 240V, Packaging: Bulk, Current Rating (Amps): 3A (AC), 270mA (DC), Mounting Type: Chassis Mount, Circuit: DPST-NC, Switch Function: On-Mom, Operating Temperature: -30°C ~ 70°C, Termination Style: Screw Terminal, Actuator Type: Round (Pin Plunger), Operating Force: 663gf, Ingress Protection: IP67 - Dust Tight, Waterproof, Mechanical Life: 15,000,000 Cycles, Electrical Life: 300,000 Cycles, Release Force: 153gf, Pretravel: 0.080" (2.0mm), Differential Travel: 0.040" (1.0mm), Overtravel: 0.158" (4.0mm), Operating Position: 0.715" (18.2mm), Voltage Rating - AC: 240 V, Voltage Rating - DC: 250 V.
Weitere Produktangebote D4N-1B31
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
 |
D4N-1B31 | OMRON |
Category: Limit Switches Description: Limit switch; plunger; 10A; max.240VAC; max.250VDC; PG13,5; IP67 Number of mounting holes: 2 Body material: plastic Switched voltage: max. 240V AC; max. 250V DC Connection: PG13,5 Mounting holes pitch: 20...22mm Kind of actuator: plunger IP rating: IP67 Type of sensor: limit switch Contact current max.: 10A DC contacts rating @R: 0.55A / 125V DC AC contacts rating @R: 3A / 240V AC Operating temperature: -30...70°C |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH |
| D4N-1B31 |
|
Hersteller: OMRON
Category: Limit Switches
Description: Limit switch; plunger; 10A; max.240VAC; max.250VDC; PG13,5; IP67
Number of mounting holes: 2
Body material: plastic
Switched voltage: max. 240V AC; max. 250V DC
Connection: PG13,5
Mounting holes pitch: 20...22mm
Kind of actuator: plunger
IP rating: IP67
Type of sensor: limit switch
Contact current max.: 10A
DC contacts rating @R: 0.55A / 125V DC
AC contacts rating @R: 3A / 240V AC
Operating temperature: -30...70°C
Category: Limit Switches
Description: Limit switch; plunger; 10A; max.240VAC; max.250VDC; PG13,5; IP67
Number of mounting holes: 2
Body material: plastic
Switched voltage: max. 240V AC; max. 250V DC
Connection: PG13,5
Mounting holes pitch: 20...22mm
Kind of actuator: plunger
IP rating: IP67
Type of sensor: limit switch
Contact current max.: 10A
DC contacts rating @R: 0.55A / 125V DC
AC contacts rating @R: 3A / 240V AC
Operating temperature: -30...70°C
