Produkte > ZF > DB2C-A1LC
DB2C-A1LC

DB2C-A1LC ZF


pVersion=0046&contRep=ZT&docId=005056AB281E1EDE95F2FC7998AD80D5&compId=DB.pdf?ci_sign=66fbfd1b4cae00e054a5627e645b5795fcf03881 Hersteller: ZF
Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 10A/250VAC; 0.1A/80VDC; with lever
Type of switch: microswitch SNAP ACTION
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 0.1A / 80V DC
Switches features: with lever
Contacts configuration: SPDT
Switching method: ON-(ON)
Number of positions: 2
Manufacturer series: DB
Stable positions number: 1
Leads: for soldering
Body dimensions: 7.3x20x6.5mm
Operating temperature: -40...85°C
Body colour: black
Electrical life: 10000 cycles
Mechanical durability: 15000000 cycles
Contact plating: silver plated
Anzahl je Verpackung: 1 Stücke
auf Bestellung 600 Stücke:

Lieferzeit 7-14 Tag (e)
Anzahl Preis
43+1.69 EUR
57+1.26 EUR
61+1.19 EUR
Mindestbestellmenge: 43
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details DB2C-A1LC ZF

Category: Microswitches SNAP ACTION, Description: Microswitch SNAP ACTION; 10A/250VAC; 0.1A/80VDC; with lever, Type of switch: microswitch SNAP ACTION, AC contacts rating @R: 10A / 250V AC, DC contacts rating @R: 0.1A / 80V DC, Switches features: with lever, Contacts configuration: SPDT, Switching method: ON-(ON), Number of positions: 2, Manufacturer series: DB, Stable positions number: 1, Leads: for soldering, Body dimensions: 7.3x20x6.5mm, Operating temperature: -40...85°C, Body colour: black, Electrical life: 10000 cycles, Mechanical durability: 15000000 cycles, Contact plating: silver plated, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote DB2C-A1LC nach Preis ab 1.19 EUR bis 1.69 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
DB2C-A1LC DB2C-A1LC Hersteller : ZF pVersion=0046&contRep=ZT&docId=005056AB281E1EDE95F2FC7998AD80D5&compId=DB.pdf?ci_sign=66fbfd1b4cae00e054a5627e645b5795fcf03881 Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 10A/250VAC; 0.1A/80VDC; with lever
Type of switch: microswitch SNAP ACTION
AC contacts rating @R: 10A / 250V AC
DC contacts rating @R: 0.1A / 80V DC
Switches features: with lever
Contacts configuration: SPDT
Switching method: ON-(ON)
Number of positions: 2
Manufacturer series: DB
Stable positions number: 1
Leads: for soldering
Body dimensions: 7.3x20x6.5mm
Operating temperature: -40...85°C
Body colour: black
Electrical life: 10000 cycles
Mechanical durability: 15000000 cycles
Contact plating: silver plated
auf Bestellung 600 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
43+1.69 EUR
57+1.26 EUR
61+1.19 EUR
Mindestbestellmenge: 43
Im Einkaufswagen  Stück im Wert von  UAH
DB2C-A1LC DB2C-A1LC Hersteller : ZF Electronics subminiature_db_microswitch_datasheet_us_2023-11-01.pdf Switch Snap Action N.O./N.C. SPDT Straight Lever 10.1A 250VAC 80VDC 186.42VA 0.83N Screw Mount Solder
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DB2C-A1LC Hersteller : ZF Electronics Description: SWITCH SNAP ACTION SPDT 10A 125V
Packaging: Bulk
Current Rating (Amps): 10A (AC)
Mounting Type: Chassis Mount
Circuit: SPDT
Switch Function: On-Mom
Operating Temperature: -40°C ~ 120°C
Termination Style: Solder Lug
Actuator Type: Lever, Straight
Operating Force: 85gf
Ingress Protection: IP50 - Dust Protected
Pretravel: 0.197" (5.0mm)
Differential Travel: 0.040" (1.0mm)
Overtravel: 0.060" (1.5mm)
Operating Position: 0.437" (11.1mm)
Voltage Rating - AC: 125 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
DB2C-A1LC DB2C-A1LC Hersteller : ZF Subminiature_DB_Microswitch_Datasheet_US_24_10_17-1568225.pdf Basic / Snap Action Switches SPDT 10.1A 125VAC StrghtLever Actuator
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
