DCW08B-15 MEAN WELL
Hersteller: MEAN WELLCategory: DC/DC Converters
Description: Converter: DC/DC; 8W; Uin: 18÷36VDC; Uout: 15VDC; Uout2: -15VDC; THT
Operating temperature: -40...71°C
Type of converter: DC/DC
Mounting: THT
Output voltage 2: -15V DC
Body dimensions: 31.8x20.3x12.2mm
Output current: 0.267A
Output current 2: 267mA
Number of outputs: 2
Power: 8W
Output voltage: 15V DC
Input voltage: 18...36V DC
Efficiency: 80%
Insulation voltage: 1kV DC
Case: 1,2"x0,8"
Switching frequency: 50kHz
Manufacturer series: DCW08
Protection: anti-overload OPP; short circuit protection SCP
Anzahl je Verpackung: 1 Stücke
auf Bestellung 26 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 5+ | 15.82 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details DCW08B-15 MEAN WELL
Category: DC/DC Converters, Description: Converter: DC/DC; 8W; Uin: 18÷36VDC; Uout: 15VDC; Uout2: -15VDC; THT, Operating temperature: -40...71°C, Type of converter: DC/DC, Mounting: THT, Output voltage 2: -15V DC, Body dimensions: 31.8x20.3x12.2mm, Output current: 0.267A, Output current 2: 267mA, Number of outputs: 2, Power: 8W, Output voltage: 15V DC, Input voltage: 18...36V DC, Efficiency: 80%, Insulation voltage: 1kV DC, Case: 1,2"x0,8", Switching frequency: 50kHz, Manufacturer series: DCW08, Protection: anti-overload OPP; short circuit protection SCP, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote DCW08B-15 nach Preis ab 15.82 EUR bis 40.89 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
DCW08B-15 | Hersteller : MEAN WELL |
Category: DC/DC Converters Description: Converter: DC/DC; 8W; Uin: 18÷36VDC; Uout: 15VDC; Uout2: -15VDC; THT Operating temperature: -40...71°C Type of converter: DC/DC Mounting: THT Output voltage 2: -15V DC Body dimensions: 31.8x20.3x12.2mm Output current: 0.267A Output current 2: 267mA Number of outputs: 2 Power: 8W Output voltage: 15V DC Input voltage: 18...36V DC Efficiency: 80% Insulation voltage: 1kV DC Case: 1,2"x0,8" Switching frequency: 50kHz Manufacturer series: DCW08 Protection: anti-overload OPP; short circuit protection SCP |
auf Bestellung 26 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
 |
DCW08B-15 | Hersteller : MEAN WELL USA Inc. |
Description: DC DC CONVERTER +/-15V 8W Packaging: Tube Features: OCP, SCP Package / Case: 24-DIP Module, 8 Leads Size / Dimension: 1.25" L x 0.80" W x 0.48" H (31.8mm x 20.3mm x 12.2mm) Mounting Type: Through Hole Type: Isolated Module Operating Temperature: -40°C ~ 71°C (With Derating) Applications: ITE (Commercial) Voltage - Input (Max): 36V Efficiency: 80% Current - Output (Max): 267mA, 267mA Voltage - Input (Min): 18V Voltage - Output 1: 15V Voltage - Output 2: -15V Power (Watts): 8 W Number of Outputs: 2 Voltage - Isolation: 1 kV |
auf Bestellung 196 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
 |
DCW08B-15 | Hersteller : Mean-Well USA, Inc. |
Module DC-DC 24VIN 2-OUT -15V/15V -0.267A/0.267A 8W 8-Pin Tube |
auf Bestellung 84 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
|
|
DCW08B-15 | Hersteller : Mean-Well USA, Inc. |
Module DC-DC 24VIN 2-OUT -15V/15V -0.267A/0.267A 8W 8-Pin Tube |
auf Bestellung 27 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||
|
|
DCW08B-15 | Hersteller : Mean-Well USA, Inc. |
Module DC-DC 24VIN 2-OUT -15V/15V -0.267A/0.267A 8W 8-Pin Tube |
Produkt ist nicht verfügbar |
|||||||||||
 |
DCW08B-15 | Hersteller : MEAN WELL |
Module DC-DC 24VIN 2-OUT 15V/-15V 0.267A/-0.267A 8W 8-Pin Tube |
Produkt ist nicht verfügbar |
|||||||||||
 |
DCW08B-15 | Hersteller : MEAN WELL |
Isolated DC/DC Converters - Through Hole 8W +/-15VOUT 18-36VIN |
Produkt ist nicht verfügbar |
