DMP4050SSDQ-13

Hersteller: Diodes Incorporated
Description: MOSFET 2P-CH 40V 4A 8SO
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Packaging: Cut Tape (CT)
Part Status: Active
Supplier Device Package: 8-SO
Vgs(th) (Max) @ Id: 3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 13.9nC @ 10V
Rds On (Max) @ Id, Vgs: 50mOhm @ 6A, 10V
Input Capacitance (Ciss) (Max) @ Vds: 674pF @ 20V
Current - Continuous Drain (Id) @ 25°C: 4A
Drain to Source Voltage (Vdss): 40V
Power - Max: 1.25W
Technology: MOSFET (Metal Oxide)
Operating Temperature: -55°C ~ 150°C (TJ)
Configuration: 2 P-Channel (Dual)

Hersteller: Diodes Incorporated
MOSFETs 40V P-Ch Dual FET 20Vgs -4.2A 14.3

Hersteller: DIODES INC.
Description: DIODES INC. - DMP4050SSDQ-13 - Dual-MOSFET, p-Kanal, 40 V, 40 V, 4 A, 4 A
tariffCode: 85411000
rohsCompliant: YES
Dauer-Drainstrom Id, p-Kanal: 4A
hazardous: false
rohsPhthalatesCompliant: YES
Qualifikation: AEC-Q101
isCanonical: Y
Drain-Source-Spannung Vds, p-Kanal: 40V
usEccn: EAR99
Dauer-Drainstrom Id, n-Kanal: 4A
Drain-Source-Durchgangswiderstand, p-Kanal: 0.05ohm
Verlustleistung, p-Kanal: 1.25W
Drain-Source-Spannung Vds, n-Kanal: 40V
euEccn: NLR
Bauform - Transistor: SOIC
Anzahl der Pins: 8Pin(s)
Produktpalette: -
Drain-Source-Durchgangswiderstand, n-Kanal: -
productTraceability: Yes-Date/Lot Code
Kanaltyp: p-Kanal
Verlustleistung, n-Kanal: 1.25W
Betriebstemperatur, max.: 150°C
SVHC: No SVHC (25-Jun-2025)

Hersteller: DIODES INC.
Description: DIODES INC. - DMP4050SSDQ-13 - Dual-MOSFET, p-Kanal, 40 V, 40 V, 4 A, 4 A
tariffCode: 85411000
rohsCompliant: YES
Dauer-Drainstrom Id, p-Kanal: 4A
hazardous: false
rohsPhthalatesCompliant: YES
Qualifikation: AEC-Q101
isCanonical: N
Drain-Source-Spannung Vds, p-Kanal: 40V
usEccn: EAR99
Dauer-Drainstrom Id, n-Kanal: 4A
Drain-Source-Durchgangswiderstand, p-Kanal: 0.05ohm
Verlustleistung, p-Kanal: 1.25W
Drain-Source-Spannung Vds, n-Kanal: 40V
euEccn: NLR
Bauform - Transistor: SOIC
Anzahl der Pins: 8Pin(s)
Produktpalette: -
Drain-Source-Durchgangswiderstand, n-Kanal: -
productTraceability: No
Kanaltyp: p-Kanal
Verlustleistung, n-Kanal: 1.25W
Betriebstemperatur, max.: 150°C
SVHC: No SVHC (25-Jun-2025)
