Produkte > SUNON > EF80252S1-1000U-A99
EF80252S1-1000U-A99

EF80252S1-1000U-A99 SUNON


pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B0A0C7&compId=Product%202.pdf?ci_sign=93f4c6e9879cb81d06996d8df805f7d6a58fa216 Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.63m3/h; 33dBA; slide; 3200rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.63m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.32W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 55mA
Supply voltage: 24V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
auf Bestellung 1581 Stücke:

Lieferzeit 14-21 Tag (e)
Anzahl Preis
19+3.8 EUR
22+3.26 EUR
50+2.59 EUR
200+2.33 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details EF80252S1-1000U-A99 SUNON

Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.63m3/h; 33dBA; slide; 3200rpm, Operating temperature: -10...70°C, Impeller material: thermoplastic, Flammability rating: UL94V-0, Insulation class: A, Kind of Bearing: slide, Fan efficiency: 69.63m3/h, Noise level: 33dBA, Rotational rate/speed: 3200rpm, Current and power consumption tolerance: ±15%, Power consumption: 1.32W, Lead length: 0.315m, Additional functions: autorestart, Kind of fan: axial, Min. insulation resistance: 10MΩ, Enclosure material: thermoplastic, Current rating: 55mA, Supply voltage: 24V DC, Leads: leads x2, Operating voltage: 8...27.6V DC, Type of fan: DC, Fan dimensions: 80x80x25mm, Fan motor: brushless DC, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote EF80252S1-1000U-A99 nach Preis ab 2.33 EUR bis 4.96 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
EF80252S1-1000U-A99 EF80252S1-1000U-A99 Hersteller : SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B0A0C7&compId=Product%202.pdf?ci_sign=93f4c6e9879cb81d06996d8df805f7d6a58fa216 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.63m3/h; 33dBA; slide; 3200rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.63m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.32W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 55mA
Supply voltage: 24V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1581 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
19+3.8 EUR
22+3.26 EUR
50+2.59 EUR
200+2.33 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
EF80252S1-1000U-A99 Hersteller : Sunon sunonap.sunon_html_d_pkg.open_file?input_file_name=7264646F632F3230313730392F3236313836302F28443038303730313930472D3030292D302E706466 EF80252S1-1000U-A99
auf Bestellung 2641 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
30+4.96 EUR
50+3.78 EUR
200+3.46 EUR
Mindestbestellmenge: 30
Im Einkaufswagen  Stück im Wert von  UAH
EF80252S1-1000U-A99 Hersteller : Sunon Fan sunonap.sunon_html_d_pkg.open_file?input_file_name=7264646F632F3230313730392F3236313836302F28443038303730313930472D3030292D302E706466 EF80252S1-A99 Вентилятор: DC, 80x80x25мм, Подшипник: скольжения, 69,63м3/ч, 33дБА
auf Bestellung 1 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
EF80252S1-1000U-A99 ( EF80252S1-A99)
Produktcode: 172160
zu Favoriten hinzufügen Lieblingsprodukt

Gehäuse, Halter, Montage- und Installationselemente > Lüfter und Zubehör
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80252S1-1000U-A99 EF80252S1-1000U-A99 Hersteller : Sunon Fans sunonap.sunon_html_d_pkg.open_file?input_file_name=7264646F632F3230313730392F3236313836302F28443038303730313930472D3030292D302E706466 Description: FAN AXIAL 80X25MM 24VDC WIRE
Packaging: Bulk
Features: Auto Restart
Voltage - Rated: 24VDC
Size / Dimension: Square - 80mm L x 80mm H
Bearing Type: Sleeve
RPM: 3200 RPM
Air Flow: 41.0 CFM (1.15m³/min)
Width: 25.00mm
Weight: 0.167 lb (75.75 g)
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Tubeaxial
Noise: 33.0dB(A)
Static Pressure: 0.180 in H2O (45.0 Pa)
Part Status: Obsolete
Power (Watts): 1.32 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80252S1-1000U-A99 EF80252S1-1000U-A99 Hersteller : Sunon Sunon_10192018_EF80251S2_1000U_A99-1488844.pdf DC Fans DC Axial Fan, 80x80x25mm, 24VDC, Sleeve, Lead Wires, Auto Restart, MagLev Motor
