Technische Details HF118F/024-1HS5T Hongfa
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; 10A/250VAC, Type of relay: electromagnetic, Contacts configuration: SPST-NO, Rated coil voltage: 24V DC, Contact current max.: 10A, AC contacts rating @R: 10A / 250V AC, DC contacts rating @R: 10A / 30V DC, Switched voltage: max. 125V DC; max. 440V AC, Relay variant: miniature, Mounting: PCB, Coil resistance: 2.35kΩ, Coil voltage min.: 16.8V DC, Coil voltage max.: 36V DC, Operate time: 10ms, Body dimensions: 28.5x12.5x10.1mm, Release time: 5ms, Coil power consumption: 220mW, Operating temperature: -40...85°C, Contact resistance: 100mΩ, Contact material: AgSnO2, Terminal pitch: 5mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote HF118F/024-1HS5T
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt |
---|---|---|---|---|---|
HF118F/024-1HS5T | Hersteller : HONGFA RELAY |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; 10A/250VAC Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 10A / 30V DC Switched voltage: max. 125V DC; max. 440V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.35kΩ Coil voltage min.: 16.8V DC Coil voltage max.: 36V DC Operate time: 10ms Body dimensions: 28.5x12.5x10.1mm Release time: 5ms Coil power consumption: 220mW Operating temperature: -40...85°C Contact resistance: 100mΩ Contact material: AgSnO2 Terminal pitch: 5mm Anzahl je Verpackung: 1 Stücke |
Produkt ist nicht verfügbar |
||
HF118F/024-1HS5T | Hersteller : HONGFA RELAY |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 10A; 10A/250VAC Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 10A AC contacts rating @R: 10A / 250V AC DC contacts rating @R: 10A / 30V DC Switched voltage: max. 125V DC; max. 440V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.35kΩ Coil voltage min.: 16.8V DC Coil voltage max.: 36V DC Operate time: 10ms Body dimensions: 28.5x12.5x10.1mm Release time: 5ms Coil power consumption: 220mW Operating temperature: -40...85°C Contact resistance: 100mΩ Contact material: AgSnO2 Terminal pitch: 5mm |
Produkt ist nicht verfügbar |
