IHLP5050FDER150MA1 Vishay Dale
Hersteller: Vishay DaleDescription: IHLP-5050FD-A1 15 20% ER E3
Tolerance: ±20%
Packaging: Tape & Reel (TR)
Package / Case: Nonstandard
Size / Dimension: 0.525" L x 0.508" W (13.34mm x 12.90mm)
Mounting Type: Surface Mount
Shielding: Shielded
Type: Molded
Operating Temperature: -55°C ~ 125°C
DC Resistance (DCR): 29.7mOhm Max
Ratings: AEC-Q200
Current - Saturation (Isat): 15A
Material - Core: Metal Composite
Inductance Frequency - Test: 100 kHz
Height - Seated (Max): 0.252" (6.40mm)
Inductance: 15 µH
Current Rating (Amps): 7.7 A
auf Bestellung 250 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 250+ | 1.06 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details IHLP5050FDER150MA1 Vishay Dale
Description: IHLP-5050FD-A1 15 20% ER E3, Tolerance: ±20%, Packaging: Tape & Reel (TR), Package / Case: Nonstandard, Size / Dimension: 0.525" L x 0.508" W (13.34mm x 12.90mm), Mounting Type: Surface Mount, Shielding: Shielded, Type: Molded, Operating Temperature: -55°C ~ 125°C, DC Resistance (DCR): 29.7mOhm Max, Ratings: AEC-Q200, Current - Saturation (Isat): 15A, Material - Core: Metal Composite, Inductance Frequency - Test: 100 kHz, Height - Seated (Max): 0.252" (6.40mm), Inductance: 15 µH, Current Rating (Amps): 7.7 A.
Weitere Produktangebote IHLP5050FDER150MA1 nach Preis ab 1.15 EUR bis 3.56 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
IHLP5050FDER150MA1 | Hersteller : Vishay Dale |
Description: IHLP-5050FD-A1 15 20% ER E3 Tolerance: ±20% Packaging: Cut Tape (CT) Package / Case: Nonstandard Size / Dimension: 0.525" L x 0.508" W (13.34mm x 12.90mm) Mounting Type: Surface Mount Shielding: Shielded Type: Molded Operating Temperature: -55°C ~ 125°C DC Resistance (DCR): 29.7mOhm Max Ratings: AEC-Q200 Current - Saturation (Isat): 15A Material - Core: Metal Composite Inductance Frequency - Test: 100 kHz Height - Seated (Max): 0.252" (6.40mm) Inductance: 15 µH Current Rating (Amps): 7.7 A |
auf Bestellung 453 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||||
 |
IHLP5050FDER150MA1 | Hersteller : Vishay / Dale |
Power Inductors - SMD 150uH 20% AEC-Q200 |
auf Bestellung 248 Stücke: Lieferzeit 10-14 Tag (e) |
|
