JV-24S-KT FUJITSU
Hersteller: FUJITSU
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Switched voltage: max. 150V DC; max. 250V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Operate time: 8ms
Body dimensions: 17.5x10x12.5mm
Release time: 4ms
Coil power consumption: 200mW
Operating temperature: -40...70°C
Relay series: JV
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 6.35mm
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; PCB
Type of relay: electromagnetic
Contacts configuration: SPST-NO
Rated coil voltage: 24V DC
Contact current max.: 5A
AC contacts rating @R: 5A / 250V AC
DC contacts rating @R: 5A / 30V DC
Switched voltage: max. 150V DC; max. 250V AC
Relay variant: miniature
Mounting: PCB
Coil resistance: 2.88kΩ
Coil voltage min.: 18V DC
Operate time: 8ms
Body dimensions: 17.5x10x12.5mm
Release time: 4ms
Coil power consumption: 200mW
Operating temperature: -40...70°C
Relay series: JV
Contact resistance: 70mΩ
Contact material: AgNi + Au
Terminal pitch: 6.35mm
auf Bestellung 13228 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
39+ | 1.87 EUR |
42+ | 1.73 EUR |
59+ | 1.22 EUR |
63+ | 1.14 EUR |
500+ | 1.13 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details JV-24S-KT FUJITSU
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; PCB, Type of relay: electromagnetic, Contacts configuration: SPST-NO, Rated coil voltage: 24V DC, Contact current max.: 5A, AC contacts rating @R: 5A / 250V AC, DC contacts rating @R: 5A / 30V DC, Switched voltage: max. 150V DC; max. 250V AC, Relay variant: miniature, Mounting: PCB, Coil resistance: 2.88kΩ, Coil voltage min.: 18V DC, Operate time: 8ms, Body dimensions: 17.5x10x12.5mm, Release time: 4ms, Coil power consumption: 200mW, Operating temperature: -40...70°C, Relay series: JV, Contact resistance: 70mΩ, Contact material: AgNi + Au, Terminal pitch: 6.35mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote JV-24S-KT nach Preis ab 1.13 EUR bis 7.51 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
JV-24S-KT | Hersteller : FUJITSU |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPST-NO; Ucoil: 24VDC; 5A; 5A/250VAC; PCB Type of relay: electromagnetic Contacts configuration: SPST-NO Rated coil voltage: 24V DC Contact current max.: 5A AC contacts rating @R: 5A / 250V AC DC contacts rating @R: 5A / 30V DC Switched voltage: max. 150V DC; max. 250V AC Relay variant: miniature Mounting: PCB Coil resistance: 2.88kΩ Coil voltage min.: 18V DC Operate time: 8ms Body dimensions: 17.5x10x12.5mm Release time: 4ms Coil power consumption: 200mW Operating temperature: -40...70°C Relay series: JV Contact resistance: 70mΩ Contact material: AgNi + Au Terminal pitch: 6.35mm Anzahl je Verpackung: 1 Stücke |
auf Bestellung 13228 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 13238 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 37832 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 37828 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 3456 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 1375 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : FCL Components | General Purpose Relays Power 5A 24VDC |
auf Bestellung 90 Stücke: Lieferzeit 14-28 Tag (e) |
|
|||||||||||||||||||
JV-24S-KT | Hersteller : Fujitsu | Power Relay 24VDC 5A SPST-NO(17.5x10x12.5)mm THT |
auf Bestellung 37832 Stücke: Lieferzeit 14-21 Tag (e) |
||||||||||||||||||||
JV24S-KT | Hersteller : Takamisawa |
5A; 24V; SPST-NO; 17,5 x 10 x 12,5mm PCB JV-24S-KT power relay P JV24SKT Anzahl je Verpackung: 5 Stücke |
auf Bestellung 3 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||||||||||||
JV24S-KT | Hersteller : Takamisawa |
5A; 24V; SPST-NO; 17,5 x 10 x 12,5mm PCB JV-24S-KT power relay P JV24SKT Anzahl je Verpackung: 5 Stücke |
auf Bestellung 10 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||||||||||||
JV24S-KT | Hersteller : Takamisawa |
5A; 24V; SPST-NO; 17,5 x 10 x 12,5mm PCB JV-24S-KT power relay P JV24SKT Anzahl je Verpackung: 5 Stücke |
auf Bestellung 5 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||||||||||||
JV24S-KT | Hersteller : Takamisawa |
5A; 24V; SPST-NO; 17,5 x 10 x 12,5mm PCB JV-24S-KT power relay P JV24SKT Anzahl je Verpackung: 25 Stücke |
auf Bestellung 65 Stücke: Lieferzeit 7-14 Tag (e) |
|
