M2015BB1W03 NKK SWITCHES
Hersteller: NKK SWITCHES
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 3A/250VAC; 3A/30VDC; -30÷85°C
Mounting: on panel
Contact material: silver
Contact plating: silver plated
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Manufacturer series: M20
Poles number: 1
Conform to the norm: CSA; UL
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Switching method: ON-(ON)
Stable positions number: 1
Actuator material: brass
Illumination: none
Kind of toggle: round
Lever length: 11.5mm
Lever plating: chromium
Number of positions: 2
Mechanical durability: 100000 cycles
Min. insulation resistance: 1GΩ
Body dimensions: 7.9x13x9.4mm
Leads: for soldering; straight
Number of terminals: 3
Electrical life: 25000 cycles
Anzahl je Verpackung: 1 Stücke
Category: Toggle Switches
Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 3A/250VAC; 3A/30VDC; -30÷85°C
Mounting: on panel
Contact material: silver
Contact plating: silver plated
Operating temperature: -30...85°C
Max. contact resistance:: 10mΩ
Manufacturer series: M20
Poles number: 1
Conform to the norm: CSA; UL
Type of switch: toggle
Contacts configuration: SPDT
AC contacts rating @R: 3A / 250V AC
DC contacts rating @R: 3A / 30V DC
Switching method: ON-(ON)
Stable positions number: 1
Actuator material: brass
Illumination: none
Kind of toggle: round
Lever length: 11.5mm
Lever plating: chromium
Number of positions: 2
Mechanical durability: 100000 cycles
Min. insulation resistance: 1GΩ
Body dimensions: 7.9x13x9.4mm
Leads: for soldering; straight
Number of terminals: 3
Electrical life: 25000 cycles
Anzahl je Verpackung: 1 Stücke
auf Bestellung 25 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
8+ | 10.02 EUR |
9+ | 8.05 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details M2015BB1W03 NKK SWITCHES
Category: Toggle Switches, Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 3A/250VAC; 3A/30VDC; -30÷85°C, Mounting: on panel, Contact material: silver, Contact plating: silver plated, Operating temperature: -30...85°C, Max. contact resistance:: 10mΩ, Manufacturer series: M20, Poles number: 1, Conform to the norm: CSA; UL, Type of switch: toggle, Contacts configuration: SPDT, AC contacts rating @R: 3A / 250V AC, DC contacts rating @R: 3A / 30V DC, Switching method: ON-(ON), Stable positions number: 1, Actuator material: brass, Illumination: none, Kind of toggle: round, Lever length: 11.5mm, Lever plating: chromium, Number of positions: 2, Mechanical durability: 100000 cycles, Min. insulation resistance: 1GΩ, Body dimensions: 7.9x13x9.4mm, Leads: for soldering; straight, Number of terminals: 3, Electrical life: 25000 cycles, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote M2015BB1W03 nach Preis ab 8.05 EUR bis 16.09 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
M2015BB1W03 | Hersteller : NKK SWITCHES |
Category: Toggle Switches Description: Switch: toggle; Pos: 2; SPDT; ON-(ON); 3A/250VAC; 3A/30VDC; -30÷85°C Mounting: on panel Contact material: silver Contact plating: silver plated Operating temperature: -30...85°C Max. contact resistance:: 10mΩ Manufacturer series: M20 Poles number: 1 Conform to the norm: CSA; UL Type of switch: toggle Contacts configuration: SPDT AC contacts rating @R: 3A / 250V AC DC contacts rating @R: 3A / 30V DC Switching method: ON-(ON) Stable positions number: 1 Actuator material: brass Illumination: none Kind of toggle: round Lever length: 11.5mm Lever plating: chromium Number of positions: 2 Mechanical durability: 100000 cycles Min. insulation resistance: 1GΩ Body dimensions: 7.9x13x9.4mm Leads: for soldering; straight Number of terminals: 3 Electrical life: 25000 cycles |
auf Bestellung 25 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||
M2015BB1W03 | Hersteller : NKK Switches |
Description: SWITCH TOGGLE SPDT 6A 125V Packaging: Bulk Features: Epoxy Sealed Terminals Current Rating (Amps): 6A (AC), 3A (DC) Mounting Type: Panel Mount Circuit: SPDT Switch Function: On-Mom Operating Temperature: -30°C ~ 85°C Termination Style: PC Pin Illumination: Non-Illuminated Bushing Thread: M12 x 1 Actuator Length: 11.50mm Actuator Type: Standard Round Panel Cutout Dimensions: Circular - 12.50mm Dia Voltage Rating - AC: 125 V Voltage Rating - DC: 30 V |
auf Bestellung 71 Stücke: Lieferzeit 21-28 Tag (e) |
|
|||||||||||
M2015BB1W03 | Hersteller : NKK Switches | Toggle Switches Series M20 Miniature Bushing Mount |
Produkt ist nicht verfügbar |
