MP0045/1D1GN220S BULGIN
Hersteller: BULGIN
Category: Push Button Switches
Description: Switch: vandal resistant; DPDT; 3A/250VAC; IP67; ON-(ON); green
Type of switch: vandal resistant
Contacts configuration: DPDT
Stable positions number: 1
Switching method: ON-(ON)
AC contacts rating @R: 3A / 250V AC
Illumination: LED
Max. contact resistance:: 50mΩ
Body colour: silver
Leads: soldering lugs
Electrical life: 30000 cycles
Mounting hole diameter: Ø16.2mm
Operating temperature: -20...55°C
Illumination voltage: 230V
Test voltage: 2kV
Mechanical durability: 200000 cycles
Backlight colour: green
Contact material: silver alloy
IP rating: IP67
Body material: stainless steel
Produktrezensionen
Produktbewertung abgeben
Technische Details MP0045/1D1GN220S BULGIN
Category: Push Button Switches, Description: Switch: vandal resistant; DPDT; 3A/250VAC; IP67; ON-(ON); green, Type of switch: vandal resistant, Contacts configuration: DPDT, Stable positions number: 1, Switching method: ON-(ON), AC contacts rating @R: 3A / 250V AC, Illumination: LED, Max. contact resistance:: 50mΩ, Body colour: silver, Leads: soldering lugs, Electrical life: 30000 cycles, Mounting hole diameter: Ø16.2mm, Operating temperature: -20...55°C, Illumination voltage: 230V, Test voltage: 2kV, Mechanical durability: 200000 cycles, Backlight colour: green, Contact material: silver alloy, IP rating: IP67, Body material: stainless steel.
Weitere Produktangebote MP0045/1D1GN220S nach Preis ab 56.69 EUR bis 65.32 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MP0045/1D1GN220S | Bulgin |
Description: SWITCH PB DPST MOM ILLUM GRN Voltage Rating - AC: 250 V Part Status: Active Actuator Marking: No Marking Color - Actuator/Cap: Silver Panel Cutout Dimensions: Circular - 16.20mm Dia Ingress Protection: IP67 - Dust Tight, Waterproof Actuator Type: Round, Button, Flush Illumination Voltage (Nominal): 220 VDC Illumination Type, Color: LED, Green Termination Style: Solder Lug Operating Temperature: -20°C ~ 55°C Switch Function: On-Mom Type: Standard, Illuminated Circuit: DPDT Mounting Type: Panel Mount, Front Current Rating (Amps): 3A (AC) Features: Stainless Steel Packaging: Bulk |
auf Bestellung 48 Stücke: Lieferzeit 10-14 Tag (e) |
|
| MP0045/1D1GN220S |
|
Hersteller: Bulgin
Description: SWITCH PB DPST MOM ILLUM GRN
Voltage Rating - AC: 250 V
Part Status: Active
Actuator Marking: No Marking
Color - Actuator/Cap: Silver
Panel Cutout Dimensions: Circular - 16.20mm Dia
Ingress Protection: IP67 - Dust Tight, Waterproof
Actuator Type: Round, Button, Flush
Illumination Voltage (Nominal): 220 VDC
Illumination Type, Color: LED, Green
Termination Style: Solder Lug
Operating Temperature: -20°C ~ 55°C
Switch Function: On-Mom
Type: Standard, Illuminated
Circuit: DPDT
Mounting Type: Panel Mount, Front
Current Rating (Amps): 3A (AC)
Features: Stainless Steel
Packaging: Bulk
Description: SWITCH PB DPST MOM ILLUM GRN
Voltage Rating - AC: 250 V
Part Status: Active
Actuator Marking: No Marking
Color - Actuator/Cap: Silver
Panel Cutout Dimensions: Circular - 16.20mm Dia
Ingress Protection: IP67 - Dust Tight, Waterproof
Actuator Type: Round, Button, Flush
Illumination Voltage (Nominal): 220 VDC
Illumination Type, Color: LED, Green
Termination Style: Solder Lug
Operating Temperature: -20°C ~ 55°C
Switch Function: On-Mom
Type: Standard, Illuminated
Circuit: DPDT
Mounting Type: Panel Mount, Front
Current Rating (Amps): 3A (AC)
Features: Stainless Steel
Packaging: Bulk
auf Bestellung 48 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 65.32 EUR |
| 10+ | 59.45 EUR |
| 25+ | 56.69 EUR |
