MRX05-1A71 Standex-Meder Electronics
Hersteller: Standex-Meder ElectronicsDescription: REED RELAY SPST-NO 5V ATEX PLAST
Packaging: Tube
Mounting Type: Through Hole
Coil Voltage: 5VDC
Operating Temperature: -40°C ~ 85°C
Termination Style: PC Pin
Coil Current: 14 mA
Coil Type: Non Latching
Seal Rating: Sealed - Fully
Contact Form: SPST-NO (1 Form A)
Contact Rating (Current): 500 mA
Switching Voltage: 200VAC, 200VDC - Max
Must Release Voltage: 1 VDC
Must Operate Voltage: 3.8 VDC
Operate Time: 0.5 ms
Release Time: 0.1 ms
Part Status: Active
auf Bestellung 78 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 47.1 EUR |
| 10+ | 40.99 EUR |
| 48+ | 37.21 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details MRX05-1A71 Standex-Meder Electronics
Category: Reed Electromagnetic Relays, Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 1A; max.200VDC; 10W; PCB, Type of relay: reed switch, Contacts configuration: SPST-NO, Rated coil voltage: 5V DC, Contact current max.: 1A, Switched voltage: max. 200V DC, Coil resistance: 360Ω, Coil power consumption: 70mW, Mounting: PCB, Manufacturer series: MRX, Contact resistance: 0.15Ω, Operating temperature: -20...85°C, Body dimensions: 30x10x10mm, Terminal pitch: 5.08mm, Release time: 0.2ms, Operate time: 0.5ms, Conform to the norm: ATEX / IECEx, Switching capacity: 10W, Min. insulation resistance: 10GΩ.
Weitere Produktangebote MRX05-1A71 nach Preis ab 12.36 EUR bis 12.36 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||
|---|---|---|---|---|---|---|---|---|---|
| MRX05-1A71 | Hersteller : Meder Electronic |
1A; 5V; SPST-NO; 110mW MRX05-1A71 reed relay P MRX05-1A71 Anzahl je Verpackung: 4 Stücke |
auf Bestellung 1 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||
| MRX05-1A71 | Hersteller : MEDER electronic (Standex) |
Reed Relays EX-APPROVED RELAY 1 Form A,SPST-NO,5V |
auf Bestellung 11 Stücke: Lieferzeit 10-14 Tag (e) |
||||||
 |
MRX05-1A71 | Hersteller : StandexMeder Electronics GmbH |
Reed Relay 5VDC 360Ohm 0.5A SPST-NO(30x10x10)mm THT Dry |
Produkt ist nicht verfügbar |
|||||
 |
MRX05-1A71 | Hersteller : MEDER |
Category: Reed Electromagnetic Relays Description: Relay: reed switch; SPST-NO; Ucoil: 5VDC; 1A; max.200VDC; 10W; PCB Type of relay: reed switch Contacts configuration: SPST-NO Rated coil voltage: 5V DC Contact current max.: 1A Switched voltage: max. 200V DC Coil resistance: 360Ω Coil power consumption: 70mW Mounting: PCB Manufacturer series: MRX Contact resistance: 0.15Ω Operating temperature: -20...85°C Body dimensions: 30x10x10mm Terminal pitch: 5.08mm Release time: 0.2ms Operate time: 0.5ms Conform to the norm: ATEX / IECEx Switching capacity: 10W Min. insulation resistance: 10GΩ |
Produkt ist nicht verfügbar |
