NSD10-48D12

NSD10-48D12 MeanWell


nsd10-d-spec-datasheet.pdf
Produktcode: 106611
Hersteller: MeanWell
Leistung, W: 10W
Spannung. in., V: 22...72VDC
Spannung. out,VDC: 12/-12VDC
Maximaler Ausgangsstrom: 0,42A
Gehäuse, Abmessungen, mm: 50,8x25,4x10mm
Temperatur, °C: -40...+85°C
Isolierung, VDC und weitere Eigenschaften: 1kVDC
auf Bestellung 1 Stück:

Lieferzeit 21-28 Tag (e)
Anzahl Preis ohne MwSt
1+10.32 EUR
Produktrezensionen
Produktbewertung abgeben

Weitere Produktangebote NSD10-48D12

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis ohne MwSt
NSD10-48D12 NSD10-48D12 Hersteller : MEAN WELL Short_Form_dd.pdf NSD10-D-SPEC.PDF Mean_Well_Industrial-Catalog.pdf Category: DC/DC Converters
Description: Converter: DC/DC; 10.8W; Uin: 22÷72V; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 10.8W
Input voltage: 22...72V
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.42A
Output current 2: 0.42A
Case: 2"x1"
Body dimensions: 50.8x25.4x10mm
Efficiency: 77%
Operating temperature: -25...70°C
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1kV DC
Mounting: PCB
Manufacturer series: NSD10-D
Number of outputs: 2
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
NSD10-48D12 NSD10-48D12 Hersteller : MEAN WELL USA Inc. NSD10-D-spec.pdf Description: DC DC CONVERTER +/-12V 10W
Features: Remote On/Off, OCP, OVP, SCP
Packaging: Tray
Package / Case: 6-DIP Module
Size / Dimension: 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -25°C ~ 70°C (With Derating)
Applications: ITE (Commercial)
Voltage - Input (Max): 72V
Efficiency: 77%
Current - Output (Max): 420mA, 420mA
Voltage - Input (Min): 22V
Voltage - Output 1: 12V
Voltage - Output 2: -12V
Part Status: Active
Power (Watts): 10 W
Number of Outputs: 2
Voltage - Isolation: 1 kV
Produkt ist nicht verfügbar
NSD10-48D12 NSD10-48D12 Hersteller : MEAN WELL NSD10_D_SPEC-1388898.pdf Isolated DC/DC Converters - Through Hole 12V/0.42A -12V/0.42A 10W, W/EMI FILTER
Produkt ist nicht verfügbar
NSD10-48D12 NSD10-48D12 Hersteller : MEAN WELL Short_Form_dd.pdf NSD10-D-SPEC.PDF Mean_Well_Industrial-Catalog.pdf Category: DC/DC Converters
Description: Converter: DC/DC; 10.8W; Uin: 22÷72V; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 10.8W
Input voltage: 22...72V
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.42A
Output current 2: 0.42A
Case: 2"x1"
Body dimensions: 50.8x25.4x10mm
Efficiency: 77%
Operating temperature: -25...70°C
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1kV DC
Mounting: PCB
Manufacturer series: NSD10-D
Number of outputs: 2
Produkt ist nicht verfügbar
