PF75301B3-1B00U-A99 SUNON
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 75x75x30mm; 18.35m3/h; 32.9dBA; ball
Type of fan: DC
Kind of fan: blower
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 75x75x30mm
Power consumption: 0.99W
Current rating: 0.82A
Fan efficiency: 18.35m3/h
Noise level: 32.9dBA
Kind of Bearing: ball
Rotational rate/speed: 2400rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.295m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Current and power consumption tolerance: ±15%
| Anzahl | Privatkunde |
|---|---|
| 5+ | 18.23 EUR |
| 10+ | 16.7 EUR |
| 50+ | 15.16 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PF75301B3-1B00U-A99 SUNON
Category: DC12V Fans, Description: Fan: DC; blower; 12VDC; 75x75x30mm; 18.35m3/h; 32.9dBA; ball, Type of fan: DC, Kind of fan: blower, Supply voltage: 12V DC, Operating voltage: 6...13.8V DC, Fan dimensions: 75x75x30mm, Power consumption: 0.99W, Current rating: 0.82A, Fan efficiency: 18.35m3/h, Noise level: 32.9dBA, Kind of Bearing: ball, Rotational rate/speed: 2400rpm, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: leads x2, Lead length: 0.295m, Operating temperature: -10...70°C, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Current and power consumption tolerance: ±15%.
Weitere Produktangebote PF75301B3-1B00U-A99
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
| PF75301B3-1B00U-A99 | Sunon Fans |
Description: Thermal Products Features: Auto Restart Packaging: Bulk Voltage - Rated: 12VDC Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H Bearing Type: Ball RPM: 2400 RPM Air Flow: 10.8 CFM (0.302m³/min) Width: 30.00mm Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads Approval Agency: CE, CUR, TUV, UL Fan Type: Blower Noise: 32.9dB(A) Static Pressure: 0.240 in H2O (59.8 Pa) Part Status: Active Power (Watts): 990 mW |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 150 Stücke Im Einkaufswagen Stück im Wert von UAH | |
 |
PF75301B3-1B00U-A99 | Sunon |
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 12VDC, Ball, Lead Wires, Auto Restart |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH |
| PF75301B3-1B00U-A99 |
|
Hersteller: Sunon Fans
Description: Thermal Products
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H
Bearing Type: Ball
RPM: 2400 RPM
Air Flow: 10.8 CFM (0.302m³/min)
Width: 30.00mm
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Blower
Noise: 32.9dB(A)
Static Pressure: 0.240 in H2O (59.8 Pa)
Part Status: Active
Power (Watts): 990 mW
Description: Thermal Products
Features: Auto Restart
Packaging: Bulk
Voltage - Rated: 12VDC
Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H
Bearing Type: Ball
RPM: 2400 RPM
Air Flow: 10.8 CFM (0.302m³/min)
Width: 30.00mm
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Blower
Noise: 32.9dB(A)
Static Pressure: 0.240 in H2O (59.8 Pa)
Part Status: Active
Power (Watts): 990 mW
Produkt ist nicht verfügbar
Mindestbestellmenge: 150 Stücke
Im Einkaufswagen
Stück im Wert von UAH
| PF75301B3-1B00U-A99 |
|
Hersteller: Sunon
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 12VDC, Ball, Lead Wires, Auto Restart
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 12VDC, Ball, Lead Wires, Auto Restart
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
