PF75302B2-1B00U-A99 SUNON
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; blower; 24VDC; 75x75x30mm; 23.44m3/h; 38.6dBA; ball
Type of fan: DC
Kind of fan: blower
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Fan dimensions: 75x75x30mm
Power consumption: 1.92W
Current rating: 80mA
Fan efficiency: 23.44m3/h
Noise level: 38.6dBA
Kind of Bearing: ball
Rotational rate/speed: 3000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.295m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Current and power consumption tolerance: ±15%
| Anzahl | Privatkunde |
|---|---|
| 4+ | 22.05 EUR |
| 10+ | 20.53 EUR |
| 50+ | 19.44 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PF75302B2-1B00U-A99 SUNON
Category: DC24V Fans, Description: Fan: DC; blower; 24VDC; 75x75x30mm; 23.44m3/h; 38.6dBA; ball, Type of fan: DC, Kind of fan: blower, Supply voltage: 24V DC, Operating voltage: 10...27.6V DC, Fan dimensions: 75x75x30mm, Power consumption: 1.92W, Current rating: 80mA, Fan efficiency: 23.44m3/h, Noise level: 38.6dBA, Kind of Bearing: ball, Rotational rate/speed: 3000rpm, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: leads x2, Lead length: 0.295m, Operating temperature: -10...70°C, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Current and power consumption tolerance: ±15%.
Weitere Produktangebote PF75302B2-1B00U-A99
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
| PF75302B2-1B00U-A99 | Sunon Fans |
Description: Thermal Products Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H Power (Watts): 1.92 W Part Status: Active Static Pressure: 0.430 in H2O (107.0 Pa) Noise: 38.6dB(A) Fan Type: Blower Approval Agency: CE, CUR, TUV, UL Termination: 2 Wire Leads Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Width: 30.00mm Air Flow: 13.8 CFM (0.386m³/min) RPM: 3000 RPM Bearing Type: Ball Voltage - Rated: 24VDC Features: Auto Restart Packaging: Bulk |
Produkt ist nicht verfügbar |
Mindestbestellmenge: 150 Stücke Im Einkaufswagen Stück im Wert von UAH | |
 |
PF75302B2-1B00U-A99 | Sunon |
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 24VDC, Ball, Lead Wires, Auto Restart |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH |
| PF75302B2-1B00U-A99 |
|
Hersteller: Sunon Fans
Description: Thermal Products
Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H
Power (Watts): 1.92 W
Part Status: Active
Static Pressure: 0.430 in H2O (107.0 Pa)
Noise: 38.6dB(A)
Fan Type: Blower
Approval Agency: CE, CUR, TUV, UL
Termination: 2 Wire Leads
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Width: 30.00mm
Air Flow: 13.8 CFM (0.386m³/min)
RPM: 3000 RPM
Bearing Type: Ball
Voltage - Rated: 24VDC
Features: Auto Restart
Packaging: Bulk
Description: Thermal Products
Size / Dimension: Rectangular/Rounded - 75.7mm L x 75.6mm H
Power (Watts): 1.92 W
Part Status: Active
Static Pressure: 0.430 in H2O (107.0 Pa)
Noise: 38.6dB(A)
Fan Type: Blower
Approval Agency: CE, CUR, TUV, UL
Termination: 2 Wire Leads
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Width: 30.00mm
Air Flow: 13.8 CFM (0.386m³/min)
RPM: 3000 RPM
Bearing Type: Ball
Voltage - Rated: 24VDC
Features: Auto Restart
Packaging: Bulk
Produkt ist nicht verfügbar
Mindestbestellmenge: 150 Stücke
Im Einkaufswagen
Stück im Wert von UAH
| PF75302B2-1B00U-A99 |
|
Hersteller: Sunon
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 24VDC, Ball, Lead Wires, Auto Restart
Blowers & Centrifugal Fans DC Blower, 75x75x30mm, 24VDC, Ball, Lead Wires, Auto Restart
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
