PF80801B1-000U-A9H SUNON
Hersteller: SUNONCategory: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x80mm; 207.28m3/h; 81.1dBA; ball; 24AWG
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Min. insulation resistance: 10MΩ
Current rating: 4025mA
Supply voltage: 12V DC
Leads: lead x4
Operating voltage: 6...13.2V DC
Type of fan: DC
Fan dimensions: 80x80x80mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 207.28m3/h
Static pressure: 92.96mm H2O
Noise level: 81.1dBA
Rotational rate/speed: 11300 (±10%)rpm; 12600 (±10%)rpm
Power consumption: 48.3W
Wire size: 24AWG
Additional functions: autorestart
Kind of fan: axial
Anzahl je Verpackung: 1008 Stücke
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details PF80801B1-000U-A9H SUNON
Category: DC12V Fans, Description: Fan: DC; axial; 12VDC; 80x80x80mm; 207.28m3/h; 81.1dBA; ball; 24AWG, Operating temperature: -10...70°C, Enclosure material: thermoplastic, Min. insulation resistance: 10MΩ, Current rating: 4025mA, Supply voltage: 12V DC, Leads: lead x4, Operating voltage: 6...13.2V DC, Type of fan: DC, Fan dimensions: 80x80x80mm, Fan motor: brushless DC, Impeller material: thermoplastic, Flammability rating: UL94V-0, Insulation class: A, Kind of Bearing: ball, Fan efficiency: 207.28m3/h, Static pressure: 92.96mm H2O, Noise level: 81.1dBA, Rotational rate/speed: 11300 (±10%)rpm; 12600 (±10%)rpm, Power consumption: 48.3W, Wire size: 24AWG, Additional functions: autorestart, Kind of fan: axial, Anzahl je Verpackung: 1008 Stücke.
Weitere Produktangebote PF80801B1-000U-A9H
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
|---|---|---|---|---|---|
| PF80801B1-000U-A9H | Hersteller : Sunon Fans |
Description: Thermal Products Packaging: Bulk Features: Auto Restart Voltage - Rated: 12VDC Size / Dimension: Square - 80mm L x 80mm H Bearing Type: Ball RPM: 12600 RPM Front, 11300 RPM Rear Air Flow: 122.0 CFM (3.42m³/min) Width: 80.00mm Operating Temperature: 14 ~ 158°F (-10 ~ 70°C) Termination: 2 Wire Leads per Fan Approval Agency: CE, CUR, TUV, UL Fan Type: Tubeaxial (Dual) Noise: 75.1dB(A) Static Pressure: 3.660 in H2O (911.7 Pa) Power (Watts): 42 W |
Produkt ist nicht verfügbar |
||
 |
PF80801B1-000U-A9H | Hersteller : Sunon |
DC Fans Axial Fan, 80x80x80mm, 12VDC, 3.66"H2O, Auto Restart, Low Vibration/High Airflow |
Produkt ist nicht verfügbar |
|
| PF80801B1-000U-A9H | Hersteller : SUNON |
Category: DC12V Fans Description: Fan: DC; axial; 12VDC; 80x80x80mm; 207.28m3/h; 81.1dBA; ball; 24AWG Operating temperature: -10...70°C Enclosure material: thermoplastic Min. insulation resistance: 10MΩ Current rating: 4025mA Supply voltage: 12V DC Leads: lead x4 Operating voltage: 6...13.2V DC Type of fan: DC Fan dimensions: 80x80x80mm Fan motor: brushless DC Impeller material: thermoplastic Flammability rating: UL94V-0 Insulation class: A Kind of Bearing: ball Fan efficiency: 207.28m3/h Static pressure: 92.96mm H2O Noise level: 81.1dBA Rotational rate/speed: 11300 (±10%)rpm; 12600 (±10%)rpm Power consumption: 48.3W Wire size: 24AWG Additional functions: autorestart Kind of fan: axial |
Produkt ist nicht verfügbar |
