PMD2407PTB1-A.(2).F.GN SUNON
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 70x70x25mm
Power consumption: 4.8W
Current rating: 0.19A
Fan efficiency: 83.25m3/h
Noise level: 45dBA
Kind of Bearing: ball bearing
Signal output: F type
Rotational rate/speed: 5100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x3
Operating temperature: -10...70°C
Cable length: 0.3m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V
Fan dimensions: 70x70x25mm
Power consumption: 4.8W
Current rating: 0.19A
Fan efficiency: 83.25m3/h
Noise level: 45dBA
Kind of Bearing: ball bearing
Signal output: F type
Rotational rate/speed: 5100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: lead x3
Operating temperature: -10...70°C
Cable length: 0.3m
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 169 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
5+ | 16.3 EUR |
10+ | 13.58 EUR |
50+ | 12.83 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PMD2407PTB1-A.(2).F.GN SUNON
Category: DC24V Fans, Description: Fan: DC; axial; 24VDC; 70x70x25mm; 83.25m3/h; 45dBA; ball bearing, Type of fan: DC, Kind of fan: axial, Supply voltage: 24V DC, Operating voltage: 10...27.6V, Fan dimensions: 70x70x25mm, Power consumption: 4.8W, Current rating: 0.19A, Fan efficiency: 83.25m3/h, Noise level: 45dBA, Kind of Bearing: ball bearing, Signal output: F type, Rotational rate/speed: 5100 (±10%)rpm, Current and power consumption tolerance: ±15%, Min. insulation resistance: 10MΩ, Impeller material: thermoplastic, Enclosure material: thermoplastic, Insulation class: A, Leads: lead x3, Operating temperature: -10...70°C, Cable length: 0.3m, Flammability rating: UL94V-0, Additional functions: autorestart, Fan motor: brushless DC, Static pressure: 9.14mm H2O, Wire size: 24AWG, Anzahl je Verpackung: 1 Stücke.
